Life Fitness Muti Jungle Handle Accessory Rack MJHAR User manual

CABLE MOTION SERIES
MJHAR
Customer Support Services
PARTS LIST
Page 1
MULTI JUNGLE HANDLE ACCESSORY RACK

Page 2
CONTENTS
________________________________________
MJHAR HANDLE ACCESSORY RACK
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
INSTALLATION ASSEMBLY 5
INSTALLATION ASSEMBLY LEGEND 6
IMAGE 7

1
3
12
13
10
6
7
9
5
12
14
15 16
18
17
14
2
8
4
11
7
15
Page 3
________________________________________
COMPONENT ASSEMBLY
SEE PAGE 4 FOR LEGEND
MJHAR HANDLE ACCESSORY RACK

Page 4
________________________________________
COMPONENT ASSEMBLY LEGEND
MJHAR HANDLE ACCESSORY RACK
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 8033801 WLDMT, MJHAR FRAME
2 1 8034101 WLDMT, MJHAR CONNECTOR
3 1 8038201 WLDMT, MJHAR HOOK
4 2 8047801 SHAFT, MJHAR BAR HOLDER
5 1 7334001 FOOT, 2.50 X 4.49 FLOV
6 1 7419701 COVER, FOOT 10 DEG
7 4 3232403 RING, RETAINING, EXTERNAL
8 2 3251202 SCREW, M10 X1.5 X 25MM UNS HEX CS ST ZN
9 2 3254703 NUT, M10 X 1.5 HEX ZINC
10 3 3238601 M10X1.5 BLIND THREADED INSERT (HEX)
11 1 7571301 LABEL, SERIAL NUMBER
12 5 3236601 WASHER, 3/8 SAE SS
13 3 3236202 SCREW, M10 X1.5 25MM
14 4 7630101 RETAINER, CM/MJ, PULLEY
15 4 7335401 NUT, M10 X 1.5 SOCKET HEAD
16 2 3236213 SCREW, M10 X1.5 80MM
17 2 3236220 SCREW, M10 X1.5 130MM
18 2 7634701 SPACER, CM/MJ, .565 X .815

Page 5
________________________________________
INSTALLATION ASSEMBLY
MJHAR HANDLE ACCESSORY RACK
1
2
3
3
4
5
5
67
WELDMENT SHOWN
FOR REFERENCE
CONNECTOR WELDMENT ALLOWS
INSTALLATION TO EITHER SIDE OF A
STATION THAT SHARES THE SAME HOLES
SPACER NOT
REQUIRED IF
INSTALLED NEXT
TO A STATION
THAT SHARES
THE SAME HOLES
SEE PAGE 6 FOR LEGEND

________________________________________
INSTALLATION ASSEMBLY LEGEND
MJHAR HANDLE ACCESSORY RACK
Page 6
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 MJCORE-ASSY ASSY, COMPONENTS MJCORE
3 2 8034101 WLDMT, MJHAR CONNECTOR
9 4 7630101 RETAINER, CM/MJ, PULLEY
10 2 7634701 SPACER, CM/MJ, .565 X .815
11 4 7335401 NUT, M10 X 1.5 SOCKET HEAD
12 2 3236220 SCREW, M10 X1.5 130MM
13 2 3236213 SCREW, M10 X1.5 80MM

Page 7
________________________________________
MJHAR HANDLE ACCESSORY RACK
