Life Fitness 95T-XXXXX-01 User manual

95T-XXXXX-01 Treadmill
Customer Support Services
PARTS MANUALrev 22 May 2008

2
Miscellaneous ........................................................................................................ 3
Rear End Caps........................................................................................................ 4
Anti-slip Pad and Extrusions....................................................................................... 5
Console Assembly ................................................................................................... 6
Uprights and Covers ................................................................................................ 7
Bridge Covers and Activity Zone.................................................................................. 8
Handrails and Covers ............................................................................................... 9
Console Bracket and Covers ......................................................................................10
Ergo Bar Components..............................................................................................11
Motor Pan Covers...................................................................................................12
Motor Pan Brackets ................................................................................................13
Belt, Deck, and Rollers............................................................................................14
Deck Springs, Stride Sensor, and Roller Guards ...............................................................15
Lift Motor and Hardware..........................................................................................16
Lift Frame and Wheels ............................................................................................17
DSP Motor Controller and Comm Port Plate Assembly .......................................................18
On/Off Switch, Home Switch, and Line Filter.................................................................19
Drive Motor Assembly..............................................................................................20
Idler Assembly and Drive Belt....................................................................................21
Leg Leveler Assembly..............................................................................................22
Cables................................................................................................................23
COMMERCIAL TREADMILL 95T-XXXXX-01
CONTENTS S/N TWT100000 and up

3
COMMERCIAL TREADMILL 95T-XXXXX-01
Miscellaneous S/N TWT100000 and up
Description Part No.
OPERATION MANUAL M051-00K65-A001
HARDWARE BAG
BAG CONSISTS OF:
C-SAFE Splitter
SCREW – 8-18x12
SCREW – M6x1.00-6G6Gx20
SCREW – M6x1.00-6G6Gx35
SCREW – M12x1.75-6G6Gx30
SCREW – M6x1.00-6G6Gx14
SCREW – 10-16X8
SCREW – M3x.8-6G6Gx10
WASHER – M006.50
WASHER – M012.70
AK65-00025-0000
0017-00021-2740
0017-00101-1769 – 2 PCS.
0017-00101-1902 – 7 PCS.
0017-00101-1954 - 6 PCS.
0017-00101-1984 – 16 PCS.
0017-00101-1953 – 68 PCS.
0017-00101-1776 – 8 PCS.
0017-00101-1995 – 4 PCS.
0017-00104-0488 – 19 PCS.
0017-00104-0489 – 16 PCS.
TOUCH UP PAINT:
SPRAY CAN
.5 OZ BOTTLE W/APPLICATOR
.33 OZ PEN
0017-00008-0204
0017-00008-0205
0017-00008-0206
LINE CORDS:
Domestic Low Voltage
Domestic High Voltage
International High Voltage (Cont.)
UK*
Australia*
China*
Line cord Bracket – (INT only)
SCREW – M4x.07-6G6Gx10 (INT only)
0017-00003-0980
0017-00003-0781
0017-00003-0696
0017-00003-0890
0017-00003-0996
0017-00003-1014
0K65-01131-0000
0017-00101-1968 – 2 PCS.
This treadmill has both Lifepulse hand sensors and telemetry and is pre-wired for attachable TV.
* The UK, Australia, and Chinese line cords are included in the 95T-INTHX-01 ship kit.

4
COMMERCIAL TREADMILL 95T-XXXXX-01
Rear End Caps S/N TWT100000 and up
Right Rear End Cap
0K65-01065-0001
Left Rear End Cap
0K65-01065-0002 Rear End Cap
Mounting Screws (4)
0017-00101-177
6
Grommets
0017-00042-1147

5
COMMERCIAL TREADMILL 95T-XXXXX-01
Anti-slip Pad and Extrusions S/N TWT100000 and up
RH Lower Frame Extrusion Assembly
LH Lower Frame Extrusion Assembly
(Assemblies Include Dual-Lock tape)
AK65-00093-0001
AK65-00093-0002
Lower Extrusion Spacer
(1 per side)
0K65-01259-0000
Right Anti-slip Pa
d
0K65-01190-0001
Left Anti-slip Pad
0K65-01190-0002
Right Upper Extrusion/Ant-slip Pad Kit
GK65-00002-0003
Left Upper Extrusion/Anti-slip Pad Kit
GK65-00002-0004
