OWNER’S MANUAL
IMPORTANT!
PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THE BIKE

Important Safety Information
Please ensure that you read this entire manual and keep this manual
in a safe place for easy reference.
1. It is important to read this entire manual before assembling and using the
equipment. Safe and effective use can only be achieved if the equipment is
assembled, maintained and used properly. It is your responsibility to ensure
that all users of the equipment are informed of all warnings and precautions.
2. Before starting any exercise program you should consult your doctor to
determine if you have any medical or physical conditions that could put your
health and safety at risk, or prevent you from using the equipment properly.
Your doctor’s advice is essential if you are taking medication that affects
your heart rate, blood pressure or cholesterol level.
3. Be aware of your body’s signals. Incorrect or excessive exercise can
damage your health. Stop exercising if you experience any of the following
symptoms: pain, tightness in your chest, irregular heartbeat, and extreme
shortness of breath, lightheadedness, dizziness or feelings of nausea. If you
do experience any of these conditions you should consult your doctor before
continuing with your exercise program.
4. Keep children and pets away from the equipment. The equipment is
designed for adult use only.
5. Use the equipment on a solid, flat level surface with a protective cover for
your floor or carpet. To ensure safety, the equipment should have at least
0.5 meters of free space all around it.
6. Before using the equipment, check that the nuts and bolts are securely
tightened.
7. The safety of the equipment can only be maintained if it is regularly
examined for damage and/or wear and tear.
8. Dress up with suitable clothing while using the equipment. Avoid wearing
loose clothing that may get caught in the equipment or that may restrict or
prevent movement.
9. The equipment has been tested under class H.C.
10. Care must be taken when lifting or moving the equipment so as not to injure
your back. Always use proper lifting techniques and/or seek assistance if
necessary.

EXPLODE-VIEW:

PARTS LIST
NO NAME QTY
NO NAME QTY
1 SADDLE 1
20 WASHER d5*Φ10*1 2
2 SADDLE POST 1
21 WATER BOTTLE HOLDER 1
3 SADDLE POST JOIN 1
22 WATER BOTTLE 1
4 WASHER d10*Φ20*1.5 1
23 HANDLE POST JOIN 1
5 KNOB M10 1
24 HANDLE POST 1
6 BUSHING PT80*40*1.5 2
25 BELT B3*300 2
7 PEDAL 2
26 MAIN FRAME 1
8 CRANK 2
27 U SEAT JOIN M10 1
9 BOLT M8*65 4
28 END CAP F38*38*1.5 2
10 WASHER d8*Φ20*1.5 4
29 BRAKE JOIN 1
11 END CAP J100*50*1.5 4
30 BOLT M5 1
12 FOOT 4
31 BOLT M4*10 1
13 BACK BOTTOM TUBE 1
32 MAGNET 1
14 FRON BOTTOM TUBE 1
33 SENSOR 1
15 TRANSPORTATION WHEEL 2
34 COMPUTER HOLDER 1
16 BOLT M6*15 2
35 COMPUTER 1
17 WASHER d6*Φ12*1.5 4
36 L SHAPE LOCKING BAR M10*18
2
18 NUT M6 2
37 WASHER d10*Φ40*4 1
19 BOLT M5*15 2
38 L SHAPE LOCKING BAR M10*25 1

TOOL KIT:

Step 1:
a. Secure the front bottom tube (14) and back bottom tube (13) to the main frame (26)
with bolt (9) and washer (10).
Step 2:

a. Secure the saddle post join (3) to the main frame (26) with L shape locking
bar (36).
b. Secure the saddle post (2) to the saddle post join (3) with knob (5) and
washer (4).
C. Secure the saddle (1) to the saddle post (2).
Step 3:

a. Secure handle post join (23) to the main frame (26) with L shape locking bar
(36).
b. Secure handle post (24) to the handle post join (23) with L shape locking
bar (38) and washer (37)
b. Secure the brake join (29) to handle post (24) with bolt (30).
Step 4:

a. Secure the pedal (7L/R) to the crank (8L/R).
b. Secure water bottle holder (21) to the main frame (26) with bolt (20) and
washer (19), put on the water bottle (22).
b. Put the computer (35) on the computer holder (34).
Please Note: ensure all the parts are well fastened to avoid any injury before use.

WARRANTY REGISTRATION
Please visit the following link to complete the product warranty form online. Please visit
http://warrantyform.lifespanfitness.com.au/
PLEASE NOTE: YOUR WARRANTY IS ONLY VALID IF YOU CAN PROVE YOU ARE
THE ORIGINAL PURCHASER ON THIS ITEM (i.e. A copy of the receipt, invoice,
delivery date or internet confirmation).
SERVICING: IF YOU FAIL TO COMPLY WITH LIFESPAN’S MAINTENANCE AND
SERVICING STEPS ABOVE, YOU MAY VOID YOUR WARRANTY. IF YOU REQUIRE A
SKILLED LIFESPAN REPRESENTATIVE TO UNDERTAKE ONE OF THE STEPS ABOVE,
PLEASE EMAIL US AT [e-mail].
