Life Span Dash User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au
Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for
future reference.
DASH OWNER’S MANUAL

2
DASH
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 3
2. IMPORTANT ELECTRICAL INFORMATION 4
3. IMPORTANT OPERATING INSTRUCTIONS 5
4. ASSEMBLY INSTRUCTIONS 6
5. FOLDING INSTRUCTIONS 10
6. OPERATION GUIDE WITH PROGRAM CHART 11
7. EXERCISE GUIDE 16
8. MAINTENANCE INSTRUCTIONS 18
9. EXPLODED DIAGRAM 26
10. PARTS LIST 27
11. WARRANTY 28

3
DASH
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING - Read all instructions before using this treadmill.
It is important your treadmill receives regular maintenance to prolong its useful life. Failing to
regularly maintain your treadmill may void your warranty.
Danger – To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to
cleaning and/or service work.
DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY
USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.
•Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.
•Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and
treadmill may result.
•Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of
the treadmill and any fixed object.
•Place your unit on a solid, level surface when in use
•Never allow children on or near the treadmill.
•When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should
you fall or move too far back on the treadmill.
•Keep hands away from all moving parts.
•Never operate the treadmill if it has a damaged cord or plug.
•Keep the cord away from heated surfaces.
•Do not operate where aerosol spray products are being used or where oxygen is being administered.
Sparks from the motor may ignite a highly gaseous environment.
•Never drop or insert any object into any openings.
•The treadmill is intended for in-home use only and not suitable for long time running.

4
DASH
•To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug
from the outlet.
•The pulse sensors are not medical devices. Various factors, including the user’s movement, may
affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in
determining heart rate trends in general.
•Use the handrails provided; they are for your safety.
•Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your
treadmill. Quality athletic shoes are recommended to avoid leg fatigue.
•Allowed temperature: 5 to 40 degrees.
Remove the safety key after use to prevent unauthorized treadmill operation.
2. IMPORTANT ELECTRICAL INFORMATION
WARNING!
•NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power
cord away from any moving part of the treadmill including the elevation mechanism and transport
wheels.
•NEVER remove any cover without first disconnecting AC power.
•NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,
near a pool, or in any other high humidity environment.
•This is high-power item; please do not share the same outlet with other high power machines such
as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and make sure
the fuse is 10A.

5
DASH
3. IMPORTANT OPERATING INSTRUCTIONS
•Be sure to read the entire manual before operating your machine.
•Understand that changes in speed and incline do not occur immediately. Set your desired speed on
the computer console and release the adjustment key. The computer will obey the command
gradually.
•Use caution while participating in other activities while walking on your treadmill, such as watching
television, reading, etc. These distractions may cause you to lose balance or stray from walking in
the centre of the belt; which may result in serious injury.
•In order to prevent losing balance and suffering unexpected injury, NEVER mount or dismount the
treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the
belt during slow acceleration is proper after you have learned to operate this machine.
•Always hold on to handrail while making control changes.
•A safety key is provided with this machine. Remove the safety key will stop the walking belt
immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.
•Do not use excessive pressure on console control keys. They are precision set to function properly
with little finger pressure.

6
DASH
4. ASSEMBLY INSTRUCTIONS
PART LIST
NO.
DES.
Specification
Nos.
NO.
DES.
Specification
Nos.
1 Main Frame 1 55 washer 8 8
39
Allen M8*15 8
12
5# Allen Wrench
5mm
1
11
Wrench w/screw driver
S=13
、
14
、
15
1
75
Bolt with washer
M5*12
6
33
Left Upright Tube Cover
1
34
Right Upright Tube cover
1
TOOLS:
5# Allen Wrench 5mm 1pc
Wrench s/screw Driver S=13, 14, 15 1pcs
Note: Do not connect power before completing assembly.

7
DASH
STEP 1:
STEP 2:
1. Open the carton
2. Extract the parts
3. Place the Main Frame onto level
ground
1. Erect the Console A and Upright tube B
towards the direction of the arrow.
Note: Whilst erecting the display ensure the
upright does not damage the wiring inside.
Support the uprights and display with your
hand to avoid it falling down and causing
injury.
A
B

8
DASH
STEP 3:
STEP 4:
1. Attach the upright tube (B) to the main
frame with M8*15 bolt (39), Lock
Washer (55). Use the 5# Allen wrench.
Note: Support the Upright Tube with hand
to avoid it falling down and causing injury
1. Attach the console tube (A) to the main
frame with M8*15 bolt (39) and Lock
Washer (55). Use the 5# Allen wrench.
Note: Support the Upright Tube with hand to
avoid it falling down and causing injury

9
DASH
STEP 5:
1. Attach the Left & Right Upright Tube
Covers (33,34) to the base frame with
M5*12 bolt (75). Use the Wrench w/ screw
driver(11).
ATTENTION：Please double check that assembly has been completed correctly and all
nuts and bolts have been correctly tightened.

10
DASH
5. FOLDING INSTRUCTIONS
Folding:
Unfolding:
Place your hand on position (A), then pull
up the base frame until you hear the click
sound emitted when the air pressure bar
(B) is locked into the round tube.
Whilst supporting position (A) with our
hand, gently push position (B), the marked
area on the air pressure bar, with your foot.
The base frame will descend automatically.
(Please keep people and any pets away
from the machine during descent)
Video Tutorial Available at:
http://youtu.be/TcuPbJ7KuxQ
Lifespan Fitness YouTube Channel:
http://www.youtube.com/user/treadmillsvideos
A
B
A
B

11
DASH
6. OPERATION GUIDE
1. OVERVIEW
2. LCD WINDOW DISPLAY
1. SPEED: Shows speed. The speed range is 0.8 – 14km/h.
2. TIME: displays total running time.
a. Counts from 0:00 to 99:59 (hr:min). After reaching 99:59 the machine will stop
smoothly and show ‘End’. It will then enter into start mode after 5 seconds.
b. In countdown mode the machine will count down from the pre-set time to 0:00. After
reaching 0:00 , the machine will stop smoothly and show ‘End’. It will then enter into
start mode.
3. DISTANCE/PULSE: shows the running distance and pulse.

12
DASH
a. Counts from 00.0 to 99.9 (km).After reaching 99:9 the machine will start counting
again form 00.0.
b. In countdown mode the machine will count down from the pre-set distance to 00.0.
After reaching 00.0, the machine will stop smoothly and show ‘End’. It will then
enter into start mode after 5 seconds.
c. Pulse displays the users estimated heart rate. Holding the hand pulse sensors with
both hands will allow the system to estimate heart rate. The range is between 50-
200 beats/min (this data is for reference only and must not be used as medical
data).
4. CALORES: shows calories burnt. This is an estimate only. This is not intended to be used as medical
data.
a. Counts from 000 to 999 (CAL). After reaching 999 the machine will start counting
again form 000.
b. In countdown mode the machine will count down from the pre-set calories to 000.
After reaching 000, the machine will stop smoothly and show ‘End’. It will then enter
into start mode after 5 seconds.
5. STEPS: displays the total number of steps the user has walked on the machine, ranges from 0 to
99,999 steps.
6. MATRIX WINDOW: during operation, the display will show a 400m running track. The machine will
beep after every lap is completed.
3. BUTTON FUNCTIONS
1. “PROG”: choose the program, cycles between manual mode and “P01 – P9”.
2. “MODE”: mode selection button. Press this button to cycle through the modes: “0.0” (manual mode),
“10:00” (time countdown mode), “1.0” (distance countdown mode), “50” (calories countdown mode).
When selecting the mode, use the speed buttons (+\-) to set the data for the mode and the START
button to start the workout.
3. “START”: begins workout. When the power is on and safety key correctly placed on the computer,
press this button to start the treadmill after a 3 second countdown.

13
DASH
4. “STOP”: press button to stop the motor running and to stop the machine. Pressing STOP once
during your workout will pause the workout and data on the LCD will remain. Press the START
button to resume your workout. Instead of pressing START, you may clear the workout data by
pressing the STOP button a second time.
5. SPEED+\SPEED-: Increase or decrease speed when exercising. Sets parameter when stopped.
6. “SPEED: 2, 4, 6, 8, 10, 12” Speed adjustment quick buttons. Use these buttons to jump to a specific
speed
7. “FAT”: press this button to enter body fat mode test.
8. : mute button (if applicable)
4. MAIN FUNCTIONS
4.1. Quick Start-up (Manual):
Ensure the safety key is attached. After a 3 second countdown, the treadmill will starting and running from
the lowest speed, add and subtract to the speed using the SPEED +/- button.
4.2. Countdown mode:
Press the MODE button to cycle options: timer countdown, distance countdown, calories countdown. The
default value corresponds to the window and flashing display. At this point the SPEED buttons serve as a
plus and minus functions to adjust to the desired value. Press the START, add and subtract speed by using
SPEED buttons once again. When the countdown reaches 0, the machine will stop. You can also directly
press the STOP button or disconnect safety lock to stop.
4.3. Preset programs:
Press the program button; programs from P1 to P9 are built-in programs. The time window displays the
default value of TIME. When flashing, press the SPEED buttons to adjust to your desired time. Built-in
program are divided into 10 equal segments. After pressing the START button, the treadmill will
automatically cycle through the time segments. Speed will automatically adjust to the preset value for the
segment. Upon completion of the segments, the program will end, slowing the treadmill down to a stop.
During the operation speed can be adjusted but the next segment will be automatically adjusted to the
program defaults. Built-in program data is listed on the table.

14
DASH
Program Chart
EACH TIME INTERVAL= 1/10th OF THE TOTAL SET TIME
1
2
3
4
5
6
7
8
9
10
P1
SPEED
3
3
6
5
5
5
4
4
4
3
P2
SPEED
3
3
4
4
5
5
5
6
6
4
P3
SPEED
3
3
5
6
7
8
6
4
3
3
P4
SPEED
3
6
6
6
8
8
8
3
3
3
P5
SPEED
2
5
6
7
8
8
7
7
3
3
P6
SPEED
2
10
10
8
8
7
6
3
2
2
P7
SPEED
3
4
5
6
7
8
7
6
4
3
P8
SPEED
3
8
6
9
8
8
8
3
10
3
P9
SPEED
2
4
6
8
8
8
7
7
3
3
4.4. Heart Rate:
When holding the hand pulse with two hands, the pulse window will show your heart rate after 5 seconds.
To increase accuracy please check heart rate with the machine stopped and after keeping your hands on
the sensors for more than 30 seconds.
The heart rate data is for reference purposes ONLY and should not be used for medical purposes.
4.5. Sleep function:
The treadmill automatically enters sleep mode after 10 minutes of inactivity. Press any key on the display to
wake the treadmill.
4.6. Data display and set range:
Initial
Initial Data
Set Range
Display Range
TIME(MIN:SECOND)
0:00
10:00
5:00-99:00 0:00－99:59
SPEED(km/h)
0.8
0.8
0.8-14
0.8-14
DISTANCE(km) 0.00
1.00
0.50-99.9 0.00－99.9
PULSE(beats/min)
P
N/A
N/A
50-200
CALORIES 0
50
10-999 0－999

15
DASH
4.7. Body Fat Test Function
1. Press the “PROGRAM” button under ready condition until the letters “FAT” show in the speed
window. “FAT” is body fat test mode.
2. Press the “MODE” button to input data into parameters “GENDER / AGE / HEIGHT / WEIGHT”.
The “TIME/DIST” window will show “-1-”, “-2-”, “-3-”, “-4-“, which corresponds to “GENDER /
AGE / HEIGHT / WEIGHT” respectively. 01 is MALE, whilst 02 is FEMALE.
3. When setting each parameter, press SPEED ▲/▼ to adjust the data, and CAL/PULSE window
will show the data. Press the “MODE” button to finish, and the window will show“-5-” and “---”
then it will enter into ready condition. Hold the hand pulse sensors with both hands and it will
show your BMI data after 5 seconds.
F-1
Gender
01MALE
02FEMALE
F-2
Age
10------99
F-3
Height
100----200
F-4
Weight
20-----150
F-5
FAT
≤19
Underweight
FAT
=(20---25)
Healthy
FAT
=(25---29)
Overweight
FAT
≥30
Obese
4.8. Safety Key Function (if applicable)
Pulling out the safety key during operation will make the treadmill stop immediately. All windows will display
“---“ and the machine will beep 3 times. Reconnecting the magnet will allow the treadmill to operate again.
4.9. MP3 Function (if applicable)
Plug the 3.5mm jack audio cable into any 3.5mm headphone jack slot. Music can be controlled via the MP3
device.
Please keep the volume at appropriate levels to prevent the speakers from damage

16
DASH
7. EXERCISE GUIDE
PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important
especially if you are over the age of 45 or individuals with pre-existing health problems.
The pulse sensors are not medical devices. Various factors, including the user’s movement, may
affect the accuracy of heart rate readings. The pulse sensors are intended only as an exercise aid in
determining heart rate trends in general.
Exercising is great way to control your weight, improving your fitness and reduce the effect of aging and
stress. The key to success is to make exercise a regular and enjoyable part of your everyday life.
The condition of your heart and lungs and how efficient they are in delivering oxygen via your blood to your
muscles is an important factor to your fitness. Your muscles use this oxygen to provide enough energy for
daily activity. This is called aerobic activity. When you are fit, your heart will not have to work so hard. It will
pump a lot fewer times per minute, reducing the wear and tear of your heart.
So as you can see, the fitter you are, the healthier and greater you will feel.
Warm-up
Start each workout with 5 to 10 minutes of stretching and some light exercises. A proper warm-up increases
your body temperature, heart rate and circulation in preparation for exercise. Ease into your exercise.

17
DASH
Training Zone Exercise
After warming up, increase the intensity to your desired exercise program. Be sure to maintain your intensity
for maximum performance. Breathe regularly and deeply as you exercise.
Cool Down
Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of
stretching to cool down. This will increase the flexibility of your muscles and will help prevent post-exercise
problems.
Workout Guidelines
TARGET ZONE
THIS IS HOW YOUR PULSE SHOULD BEHAVE DURING GENERAL FITNESS EXERCISE.
REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES.
The most important factor here is the amount of effort you put in. The harder and longer you work, the more
calories you will burn. Effectively this is the same as if you were training to improve your fitness, the
difference is the goal.

18
DASH
8. MAINTENANCE INSTRUCTIONS
Reasonable cleaning/lubricating should be made to extend the life time of this unit. Performance is
maximized when the belt and mat are kept as clean as possible.
WARNING: THE MAT/DECK FRICTION MAY PLAY A MAJOR ROLE IN THE FUNCTION AND LIFE OF
YOUR TREADMILL AND THAT IS WHY WE RECOMMEND YOU CONSTANTLY LUBRICATE THIS
FRICTION POINT TO PROLONG THE USEFUL LIFE OF YOUR TREADMILL. FAILING TO DO THIS
MAY VOID YOUR WARRANTY.
WARNING: UNPLUG POWER CORD BEFORE MAINTENANCE
WARNING: STOP TREADMILL BEFORE FOLDING
1. General Cleaning
•Use a soft, damp cloth to wipe the edge of the belt and the area between the belt edge and frame. A
mild soap and water solution along with a nylon scrub brush will clean the top of the textured belt.
This task should be done once a month. Allow to dry before using.
•On a monthly basis, vacuum underneath your treadmill to prevent dust build up. Once a year, you
should remove the black motor shield and vacuum out dirt that may accumulate.
2. General Care
•Check parts for wear before use.
•Pay particular attention to the fixing knobs and make sure they are tight.
•Always replace the mat if worn and any other defective parts.

19
DASH
•If in doubt do not use the treadmill and contact us.
TAKE CARE TO PROTECT CARPETS AND FLOOR in case of leakages. This product is a machine that
contains moving parts which have been greased / lubricated and could leak.
3. Belt/Deck/Roller Lubrication
The mat/deck friction may play a major role in the function and life of your treadmill and that is why we
recommend you constantly lubricate this friction point to prolong the useful life of your treadmill. You should
apply lubrication after approximately the first 30 hours of operation. We recommend lubrication of the deck
according to the following timetable:
oLight use (less than 3 hours per week) every 6 months
oMedium use (3-5 hours a week) every 3 months
oHeavy use (more than 5 hours per week) every 6-8 weeks
See below procedures for lubricating:
1. Use a soft, dry cloth to wipe the area between the belt and deck.
2. Spread lubricant onto the inside surface of belt and deck evenly (make sure the machine is turned
off and power is disconnected).
3. Periodically lubricate the front and rear rollers to keep them at their peak performance. If the
treadmill belt/deck/roller is kept reasonably clean it is possible to expect over 1200 hours before
relubricating is necessary.
Video Tutorial Available at:
http://youtu.be/cP9NtFHfWlc
Lifespan Fitness Channel:
http://www.youtube.com/user/treadmillsvideos

20
DASH
4. How to check the running mat for proper lubrication:
1. Disconnect the main power supply.
2. Fold the treadmill up into the storage position.
3. Feel the underside surface of the running mat.
If the surface is slick when touched, then no further lubrication is needed.
If the surface is dry to the touch, apply a suitable silicone lubricant.
We recommend that you use a silicone based spray to lubricate your Lifespan treadmill. This can be
purchased directly from us or any hardware store.
