Lightmybricks 10292 User manual

LEGO® THE FRIENDS APARTMENTS
#10292 LIGHT KIT
INSTALLATION GUIDE

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
2
Light My Bricks
LEGO® THE FRIENDS APARTMENTS #10292
LIGHT KIT
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
The Friends Apartments (10292) Light Kit.
This PDF details the instructions for the LED light kit only. .
Have fun and enjoy!
INSTALLATION GUIDE

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
PACKAGE CONTENTS 3
PACKAGE CONTENTS: LEGO PIECES:
8 x White 30cm Micro Bit Light*
5 x Warm White 30cm Large Bit Light
9 x White 30cm Bit Light*
2 x Warm White Strip Light
2 x Micro 8-Port Expansion Board*
2 x 6-Port Expansion Board
2 x 8-Port Expansion Board*
1 x 2-Port Expansion Board
•1 x Trans Clear 1x1 Round Plate
•1 x Red 1x1 Round Plate
•2 x White 1x1 Round Plate w Open Stud
•1 × Black Arm Skeleton, Bent w Clips (Horizontal Grips)
•1 × Black Plate 1x1 Modified Rounded w Handle
•1 × Black Plate 1x2 Modified w/ Handle on End
•1 × Black Round Plate 1x1 w Open Stud
1 x Flicker Eects Board
10 x Adhesive Squares
5 x 30cm Connecting Cable
1 x 15cm Connecting Cable
1 x 5cm Connecting Cable
1 x USB Power Cable
(Power Source not Included)
* Indicates 1 extra component has been included just in case!

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin 5
Instructions 8
Final Product 36
Troubleshooting 37
Contact 42

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can
can result in bent pins inside the port or
possible overheating of the expansion
board when connected.

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
88INSINSINSTRUCTIONSTRUCTIONSTRUCTIONS
LEGEND:DISCONNECT DIRECTIONAL
LEGENDE:TRENNEN DIRECTIONAL
LÉGENDE:DÉCONNECTER DIRECTIONNEL
LEGGENDA: SCOLLEGARE
CONNECT / RECONNECT
VERNINDEN / WIEDERVERBINDEN
CONNECTER / RECONNECTER
CONNETTI / RICONNETTI
TURN / FLIP
WENDEN / KIPPEN
TOUR / INCLINAISON
ROTARE / INCLINARE DIREZIONALE
TWIST / BRAID
DREHEN / VERDREHEN
TORSION / TRESSER
TWIST / TRECCIA
POWER ON / TEST
EINSCHALTEN / TESTEN
POWER ON / TEST
POWER ON / TEST

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
1
2
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2x White 30cm Micro Bit Light
Lay 2x White
30cm Micro Bit Light
overlapping each other
as shown ensuring the
LEDs are both facing
upwards

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Micro 8-Port Expansion Board
Connect the Micro
Bit Lights to the Micro
8-Port Expansion
Board.
Refer to page 6 “Before
you begin” for correct
insertion.
Micro Bit Lights can
ONLY be connected to
Micro ports. Connecting
Micro Bit Lights to the
larger ports will result in
a short circuit and void
of warranty
3

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
4
5
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 30cm Micro Bit Light

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
6
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 30cm Micro Bit Light

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
7
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2x White 30cm Micro Bit Light
8
Ensure the 3
Micro Bit Lights are
connected to the
Micro Ports

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 30cm Micro Bit Light

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
9 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect to a
USB Power Bank,
USB to AA Battery
Pack or USB Wall
Adaptor (each sold
separately)
USB Power Cable

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Warm White 30cm Large Bit Light
6-Port Expansion Board
30cm Connecting Cable
11
Connect the
Large Bit Light to
the regular port on
the far side of the
Expansion Board.
Connect the
30cm Connecting
Cable to the regular
port on the far side
of the Micro
Expansion Board

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
12
Warm White 30cm Large Bit

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
14
Reconnect USB
Power Cable to
6-Port Expansion
Board

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2x Adhesive Squares
Pull the 30cm
Connecting Cable
to the left side of the
set before securing
it with the Black
1x8 Plate you just
disconnected
30cm Connecting Cable
2x Adhesive Squares
Warm White Strip Light

LEGO THE FRIENDS APARTMENTS 10292 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Reconnect the
USB Power Cable to
the 6-Port Expansion
board
30cm Connecting Cable
