Lightmybricks 10317 User manual

LEGO®LAND ROVER CLASSIC DEFENDER
90 #10317 LIGHT KIT
INSTALLATION GUIDE

INSTALLATION GUIDE 2
Light My Bricks
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
LEGO®LAND ROVER CLASSIC DEFENDER 90 
10317 INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
Land Rover Classic Defender 90 10317 Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshooting
section towards the end of this guide.
Have fun and enjoy!

PACKAGE CONTENTS 3
PACKAGE CONTENTS:
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
• 8x White 15cm Bit Light
• 9x Cool White 15cm Bit Light *
• 7x White 30cm Bit Light *
2x 2-Port Expansion Board
5x 6-Port Expansion Board
2x 8-Port Expansion Board
2x NC Push Board
10x Adhesive Square
5x Plate, Round 1x1 - Trans-Clear
4x Plate, Round 1x1 - Trans-Orange
3x Plate, Round 1x1 - Trans-Red
4x Plate, Round 1x1 with Open Stud - Black
1x Tile 1x1 with Groove - Black
1x Tile 1x2 with Groove - Trans-Clear
1x Plate, Round 2x2 with Rounded Bottom (Boat Stud) - Trans-Clear
1x Plate 2x2 - Dark Bluish Gray
1x Plate 2x4 - Black
4x 5cm Connecting Cable
5x 15cm Connecting Cable
2x 30cm Connecting Cable *
* Indicates components which include spares
Mixed Components 1
Individual Bags Mixed Components 2
Mixed Components 3
Connecting Cables
USB Power Cable
1x USB Power Cable
(Power Source not Included)

CONTENTS 4
Contents
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
Before You Begin 5
Blueprint 10
Instructions 12
Final Product 49
Troubleshooting 50
Contact 54

BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO®bricks, plates, and tiles providing
they are laid correctly between the LEGO®
studs. Do NOT forcefully join LEGO®
together around cables; instead ensure
they are laying comfortably in between
each stud.
CAUTION: Forcing LEGO®to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO®studs or in between.
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 8
Before You Begin
Disconnect
Used when you need to
remove a LEGO piece/ section
or LMB component.
Twist/ Braid
Seen when a set of cables
need to be grouped and
twisted together.
Directional
Used to show where to route
cables, place components, or
move them.
Power On Test
Found at the end of a major
step to test the lights. Will be
located in the top left corner.
Bend/Pivot
Used when a component
needs to be bent, or part
folded or pivoted.
Note
Notes will be found alongside
the instruction photos and
explain what to do.
Connect
Used when you need to
connect a LEGO piece or LMB
component.
Turn/ Flip
Will be found in the top left
corner when the set needs to
be rotated or flipped.
Light Kit Component
This is the most important image
format as it indicates which part
to use from the Light Kit. Make
sure you pay close attention to
which part is shown.
The Symbols Used In This Guide
When going through the following guide you will
come across symbols and formats that will assist
with the installation of your light kit. Take notice of
them as each has a specific purpose.
White 30cm Bit Light
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 9
Before You Begin
Disconnect Note
The red coloured note is
used when the topic focuses
on a component being
disconnected or like here, the
removed pieces.
Connect Note
The green coloured note is
used when the topic focuses
on a component being
connected, like the shown
Power Bank.
General Note
This is a sample note that is
used anywhere in this guide. It
will explain a dicult section
where photos are hard to
illustrate or easily confused.
NOTE
Connect to a 5V USB Power Bank,
5V USB Wall Adaptor, or USB to AA
Battery Pack (sold separately)
NOTE
You should have these parts left
over that were removed from the
LEGO set
NOTE
Take the 5cm Connecting Cable
from the 4-Port Micro Expansion
Board and route it into the “IN”
port of the Flicker Eects Board
x2
Connect Focus
Used to highlight a hard to
see area where a component
is being connected.
Disconnect Focus
Used to highlight a hard to
see area where a component
is being disconnected.
General Focus
Used to highlight a hard to
see area where a component
needs to be acted on.
Repeat Step
Repeat the previous step eg.
Make a spotlight, then make a
second spotlight.
Removed Pieces
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BLUEPRINT 10
BLUEPRINT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

BLUEPRINT 11
BLUEPRINT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 12
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 13
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
1
2

INSTRUCTIONS 14
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
3

INSTRUCTIONS 15
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
4White 30cm Bit Light
Round Plate 1x1 - Trans Red Round Plate 1x1 Open Stud - Trans
Orange
White 30cm Bit Light

INSTRUCTIONS 16
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
5
White 30cm Bit Light
Round Plate 1x1 - Trans Red
White 30cm Bit Light
Round Plate 1x1 - Trans Red

INSTRUCTIONS 17
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
1
Round Plate 1x1 Open Stud - Trans
Orange
White 30cm Bit Light
White 30cm Bit Light
Round Plate 1x1 - Trans Clear

INSTRUCTIONS 18
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
6

INSTRUCTIONS 19
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
7
7
NOTE
Thread the bundled cables
through the following gap

INSTRUCTIONS 20
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
8
5cm Connecting Cable2 x 6-Port Expansion Board
NOTE
Connect the White 30cm Bit
Lights to either Expansion
Board
