LEGO® LOOP COASTER #10303
LIGHT KIT
INSTALLATION GUIDE

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO LOOP COASTER 10303
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO
Loop Coaster 10303 Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
21 x White 30cm Bit Light*
1 x Cool White 30cm Bit Light
1 x Red & Blue 15cm Bit Light
1 x Orange & Green 15cm Bit Light
2 x Rotating Bit Light
12 x Warm White 30cm Large Bit Light*
3 x Cool White 30cm Large Bit Light
2 x 2-Port Expansion Board
8 x 6-Port Expansion Board
2 x 8-Port Expansion Board*
1 x Gun Eects Board
2 x Rotating Sequence Eects Board
20 x Adhesive Squares
• 15 x Round Plate 1x1 w/ Open Stud – Black
• 13 x Mod Plate 1x1 w/ Handle – Black
• 10 x Arm Skeleton, Bent with Clips (Horizontal Grip) - Black
• 13 x Plate 1x2 MW Handle On End - Black
• 3 x Arm Skeleton, Bent with Clips at 90 degrees - Black
• 1 x Round Brick 1x1 - Trans Red
• 2 x Round Plate 1x1 - Trans Red
• 1 x Round Plate 1x1 - Trans Dark Blue
• 1 x Round Plate 1x1 - Trans Green
• 1 x Round Plate 1x1 - Trans Pink
• 1 x Round Plate 1x1 - Trans Clear
• 2 x Plate 2x8 - Black
• 1 x Plate 2x2 W Rounded Bottom - Trans Clear
• 1 x Cone 1 x 1 w/ Top Groove - Trans Orange
• 1 x Bracket 1x1 - Light Grey
4 x 5cm Connecting Cable*
2 x 15cm Connecting Cable
7 x 30cm Connecting Cable
3 x 50cm Connecting Cable*
1x USB Power Cable
(Power Source not Included)
* Indicates components which include spares

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
10
59
60
65

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
BLUEPRINT 8
BLUEPRINT

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
BLUEPRINT 9
BLUEPRINT

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
1
Warm White 30cm Large Bit Light
Black Round Plate 1x1
w/ Open Stud
2

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
3
Plate 1x2 MW Handle On End
- Black
Black 1x1 Plate Modified Plate
Rounded w/ Handle
Black Arm Skeleton, Bent w
Clips (Horizontal Grips)

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6-Port Expansion Board

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
4 5 Warm White 30cm Large Bit Light
Black Round Plate 1x1
w/ Open Stud
2 x Black 1x1 Plate Modified
Plate Rounded w/ Handle
Black Arm Skeleton,Bent w/
Clips at 90 Degrees

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
62-Port Expansion Board
30cm Connecting Cable
Adhesive Square

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
7
Thread the cable
in between the gap
of the pole and rings

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
8
x8
White 30cm Bit Light
Repeat this for
the rest of the pillar
as shown

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Connect all the
lights underneath
the Orange plates
to Output 1 starting
from the bottom of
the pillar (e.g. first
Orange to port 1-1,
second Orange to
port 1-2)
Rotating Sequence Eects
Board
Connect all the
lights underneath the
Blue plates to Output
2 starting from the
bottom of the pillar
(e.g. first Blue to port
2-1, second Blue to
port 2-2)
5cm Connecting Cable
8-Port Expansion Board

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
10
White 30cm Bit Light
11
Connect all the
lights underneath
the Orange plates
to Output 1 starting
from the bottom of
the pillar (e.g. first
orange to port 1-1,
second orange to
port 1-2)
Rotating Sequence Eects
Board
Connect all the
lights underneath the
Blue plates to Output
2 starting from the
bottom of the pillar
(e.g. first Blue to port
2-1, second Blue to
port 2-2)
Repeat this for
the rest of the pillar
as shown
The same process
is repeated on the
right side

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
12
5cm Connecting Cable
White 30cm Bit Light
Round Plate 1x1 - Trans Red
