LEGO® STAR WARS UCS LUKE
SKYWALKER’S LANDSPEEDER #75341
LIGHT KIT
INSTALLATION GUIDE

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
2
Light My Bricks
LEGO STAR WARS UCS LUKE SKYWALKER’S
LANDSPEEDER 75341 INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO
Star Wars UCS Luke Skywalker’s Landspeeder 75341 Light Kit.
This PDF details the instructions for the LED light kit only
If you run into any issues, please refer to the troubleshooting
section towards the end of this guide.
Have fun and enjoy!
INSTALLATION GUIDE

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
1 x Blue Lightsaber
2 x Cool White 30cm Bit Light
3 x Orange 30cm Bit Light
3 x Orange 30cm Large Bit Light
2 x Warm White 30cm Large Bit Light
3 x 6-Port Expansion Board
1 x Scary Eects Board
2 x Adhesive Squares
•5 x Round Plate 1x1 w/ Open Stud – Black
•4 x Mod Plate 1x1 w/ Handle – Black
•2 x Arm Skeleton, Bent with Clips (Horizontal Grip) - Black
•2 x Round Plate 1x1 – Trans Clear
•1 x Plate 2x8 – Black
•4 x Brick 1x2 - Black
•3 x Plate 2x2 w/ Rounded Bottom – Trans Clear
1 x 5cm Connecting Cable
2 x 30cm Connecting Cable
1x USB Power Cable
(Power Source not Included)

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
9
31
32
37

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
LEGENDLEGEND:: DISCONNECTDISCONNECT DIRECTIONALDIRECTIONAL
LEGENDELEGENDE:: TRENNENTRENNEN DIRECTIONALDIRECTIONAL
LÉGENDELÉGENDE:: DÉCONNECTERDÉCONNECTER DIRECTIONNELDIRECTIONNEL
LEGGENDALEGGENDA:: SCOLLEGARESCOLLEGARE
CONNECT / CONNECT / RECONNECTRECONNECT
VERNINDEN VERNINDEN / WIEDERVERBINDEN/ WIEDERVERBINDEN
CONNECTER CONNECTER / RECONNECTER/ RECONNECTER
CONNETTI / RICONNETTICONNETTI / RICONNETTI
TURN TURN / / FLIPFLIP
WENDEN WENDEN / KIPPEN/ KIPPEN
TOUR TOUR / INCLINAISON/ INCLINAISON
ROTARE ROTARE / INCLINARE/ INCLINARE DIREZIONALEDIREZIONALE
TWIST TWIST / BRAID/ BRAID
DREHEN DREHEN / VERDREHEN/ VERDREHEN
TORSION TORSION / TRESSER/ TRESSER
TWIST TWIST / / TRECCIATRECCIA
POWER POWER ON ON / TEST/ TEST
EINSCHALTEN EINSCHALTEN / TESTEN/ TESTEN
POWER POWER ON ON / / TESTTEST
POWER POWER ON ON / / TESTTEST

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
1

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
3
Orange 30cm Bit Light
Round Plate 1x1 - Trans Clear

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
4Orange 30cm Bit Light
Black Round Plate 1x1
w/ Open Stud

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
5

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6
Connect the two
Orange 30cm Bit
Lights to the ‘OUT’
port of the Scary
Eects Board.
Scary Eects Board
Orange 30cm Bit Light Round Plate 1x1 - Trans Clear
5cm Connecting Cable
Connect the
Orange 30cm Bit
Light to the ‘OUT’
port of the Scary
Eects Board.
Connect the 5cm
Connecting Cable
to the ‘IN’ port of the
Scary Eects Board.

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
7Connect the
other end of the 5cm
Connecting Cable to
the 6-Port Expansion
Board.
6-Port Expansion Board
8
Large Warm White 30cm Bit Light
Black Round Plate 1x1
w/ Open Stud

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Leave the front
section from step 8
on the driver seat
while we thread the
Bit Light to the front.

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
10
Black Round Plate 1x1
w/ Open Stud
Large Warm White 30cm Bit Light

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
11
Leave the front
section on the
Landspeeder to
thread the White Bit
Light as shown.
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
USB Power Cable
Connect the other
end to a 5V USB
Power Bank, 5V USB
Wall Adaptor, or USB
to AA Battery Pack
(sold separately)

LEGO STAR WARS UCS LUKE SKYWALKER’S LANDSPEEDER 75341 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
12
30cm Connecting Cable
