Lightmybricks 21057 User manual

LEGO® SINGAPORE #21057
LIGHT KIT
INSTALLATION GUIDE

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO SINGAPORE 21057
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO
Singapore 21057 Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
8x Micro Blue 15cm Bit Light *
6x Micro White 15cm Bit Light *
3x Cool White 15cm Bit Light
6x Pink 30cm Bit Light
2x 6-Port Expansion Board
1x 4-Port Micro Expansion Board
2x 8-Port Micro Expansion Board *
• 6x 1x1 Round Plate - Trans Clear
1x 5cm Connecting Cable
2x 15cm Connecting Cable
4x Adhesive Squares
1x USB Power Cable
(Power Source not Included)
* Indicates components which include spares

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
10
36
37
42

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
1
2
For the following
steps, use a LEGO
Brick Separator or
similar pry tool to
help you remove
bricks

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
3
Micro Blue 15cm Bit Light
Lay all of the
parts in order like
shown to easily
organise them

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Micro Blue 15cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
4
Micro Blue 15cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
5
Micro Blue 15cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6
Micro Blue 15cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
7
Micro Blue 15cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
8
Micro Blue 15cm Bit Light 8-Port Micro Expansion Board
5cm Connecting Cable
Grab all the
cables aside from the
far left one and plug
them into the 8-Port
Micro Expansion
Board as shown

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Connect the
remaining Micro
Blue Bit Light into
the Micro 4-Port
Expansion Board
4-Port Micro Expansion Board
Pink 30cm Bit LightUSB Power Cable
Connect the other
end to a 5V USB
Power Bank, 5V USB
Wall Adaptor, or USB
to AA Battery Pack
(sold separately)
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
10
1x1 Round Plate - Trans Clear
1x1 Round Plate - Trans Clear
Pink 30cm Bit Light

LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
11
12
Pink 30cm Bit Light
Pink 30cm Bit Light
1x1 Round Plate - Trans Clear
x2
