LEGO®UCS RAZOR CREST #75331
LIGHT KIT
INSTALLATION GUIDE

2
Light My Bricks
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
LEGO®UCS RAZOR CREST 75331
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
UCS Razor Crest 75331 Light Kit.
This PDF details the instructions for the LED light kit only.
If you run into any issues, please refer to the
troubleshooting section towards the end of this guide.
Have fun and enjoy!
INSTALLATION GUIDE

v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
2 x Rotating 8x8 Light Ring - Orange
2 x Light Ring 3x3 - Warm white
11 x Orange Large Bit Light - 30cm *
10 x Red Bit Light - 30cm *
8 x Cool White Bit Light - 15cm
4 x Cool White Bit Light - 30cm *
2 x White Bit Light - 30cm
2 x Green Bit Light - 30cm
1 x Blue to Red Bit Light - 15cm
3 x 6-Port Expansion Board
2 x 12-Port Expansion Board
2 x 8-Port Expansion Board *
3 x 2-Port Expansion Board
1 x Gun Eects Board
•8 x 1x2 Plate - Trans Clear
•2 x1x2 Plate - Black
•1 x 1x2 Tile - Trans Clear
•2 x 1x1 Plate - Black
•3 x 1x1 Round Plate - Trans Red
•1 x 1x1 Round Plate - Trans Clear
•2 x 2x2 Round Brick - Trans Clear
•27 x 1x1 Round Plate w/Open Stud - Black *
•4 x Plate 1x1 Mod Rounded w Handle - Black
•4 x Tile 1x1 W Clip Round Edges - Black
•1 x 1x4 Brick - Light Grey
•2 x 1x1 Technic Brick - Black
•1 x 1x2 Bracket - Black
2 x Connecting Cable - 5cm
3 x Connecting Cable - 50cm
4 x Connecting Cable - 15cm
2 x Wireless Power Connectors
1x USB Power Cable
(Power Source not Included)
* Indicates components which include spares

CONTENTS 4
Contents
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
Before You Begin 5
Blueprint 10
Instructions 11
Final Product 79
Troubleshooting 80
Contact 84

BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO®bricks, plates, and tiles providing
they are laid correctly between the LEGO®
studs. Do NOT forcefully join LEGO®
together around cables; instead ensure
they are laying comfortably in between
each stud.
CAUTION: Forcing LEGO®to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO®studs or in between.
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 8
Before You Begin
Disconnect
Used when you need to
remove a LEGO piece/ section
or LMB component.
Twist/ Braid
Seen when a set of cables
need to be grouped and
twisted together.
Directional
Used to show where to route
cables, place components, or
move them.
Power On Test
Found at the end of a major
step to test the lights. Will be
located in the top left corner.
Bend/Pivot
Used when a component
needs to be bent, or part
folded or pivoted.
Note
Notes will be found alongside
the instruction photos and
explain what to do.
Connect
Used when you need to
connect a LEGO piece or LMB
component.
Turn/ Flip
Will be found in the top left
corner when the set needs to
be rotated or flipped.
Light Kit Component
This is the most important image
format as it indicates which part
to use from the Light Kit. Make
sure you pay close attention to
which part is shown.
The Symbols Used In This Guide
When going through the following guide you will
come across symbols and formats that will assist
with the installation of your light kit. Take notice of
them as each has a specific purpose.
White 30cm Bit Light
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 9
Before You Begin
Disconnect Note
The red coloured note is
used when the topic focuses
on a component being
disconnected or like here, the
removed pieces.
Connect Note
The green coloured note is
used when the topic focuses
on a component being
connected, like the shown
Power Bank.
General Note
This is a sample note that is
used anywhere in this guide. It
will explain a dicult section
where photos are hard to
illustrate or easily confused.
NOTE
Connect to a 5V USB Power Bank,
5V USB Wall Adaptor, or USB to AA
Battery Pack (sold separately)
NOTE
You should have these parts left
over that were removed from the
LEGO set
NOTE
Take the 5cm Connecting Cable
from the 4-Port Micro Expansion
Board and route it into the “IN”
port of the Flicker Eects Board
x2
Connect Focus
Used to highlight a hard to
see area where a component
is being connected.
Disconnect Focus
Used to highlight a hard to
see area where a component
is being disconnected.
General Focus
Used to highlight a hard to
see area where a component
needs to be acted on.
Repeat Step
Repeat the previous step eg.
Make a spotlight, then make a
second spotlight.
Removed Pieces
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE

BLUEPRINT 10
BLUEPRINT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
12-Port
Expansion Board
Engine Section Main Body
Gun Eects Board
2-Port
6-Port
Expansion Board
50cm
5cm
5cm
2 x Rotating Light Ring 8x8
Orange
6-Port
Expansion Board
6-Port
Expansion Board
8-Port
Expansion Board
Light Ring 3x3
White
5 x Orange Large
Bit Light - 30cm
5 x Orange Large
Bit Light - 30cm
Cool White
Bit Light - 15cm
12-Port
Expansion Board
5x Red 30cm Bit Light
2 x Red Bit Light - 30cm
15cm
15cm
2x Cool White
30cm Bit Light
Cool White
15cm Bit Light
Red to Blue
15cm Bit Light
2-Port
Cool White
30cm Bit Light 4x Cool White 15cm Bit Light
2 x Green
30cm Bit Light
2 x White
30cm Bit Light
2-Port
Cool White
Bit Light - 15cm
Red Bit Light 30cm
Red Bit Light 30cm
15cm
Light Ring 3x3
White
Cockpit
50cm
2-Port
Cool White
15cm Bit Light
USB Power Cable
15cm
15cm

INSTRUCTIONS 11
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
Wenn Sie Probleme mit Ihrem Light My Bricks-Set haben, sehen Sie sich unser Video zur Fehlerbehebung an oder lesen
Sie die Auflistung der häufigsten Ursachen, die Ihnen bei der Fehlersuche helfen hier.
Si vous rencontrez des problèmes avec votre kit Light My Bricks, regardez notre vidéo de dépannage ou consultez la
liste des causes les plus fréquentes pour vous aider à les résoudre ici.
Se si verificano problemi con il set Light My Bricks, guardare il nostro video per la risoluzione dei problemi o leggere
l'elenco delle cause più comuni per la risoluzione dei problemi qui.

INSTRUCTIONS 12
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
1

INSTRUCTIONS 13
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
2

INSTRUCTIONS 14
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
3

INSTRUCTIONS 15
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
4Orange 30cm Large Bit Light Round Plate 1x1 Open Stud - Black

INSTRUCTIONS 16
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
x3
NOTE
Ensure the cables run through
this small opening in the
Curved Tiles.
5

INSTRUCTIONS 17
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
Orange 30cm Large Bit Light Brick Round 2x2 - Trans Clear
NOTE
Ensure the LED is facing down
inside the 2x2 Round Brick
(away from the Trans Orange
Round Plate 2x2 w/ Rounded
Bottom).
NOTE
Ensure to only slide the Yellow
Round Plate half way on the
Black Technic Rod.

INSTRUCTIONS 18
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
6
74 x Plate 1x2 - Trans Clear

INSTRUCTIONS 19
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
15cm Connecting Cable
Rotating Light Ring 8x8 - Orange 8

INSTRUCTIONS 20
DIRECTIONAL
CONNECT
DISCONNECT TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO®UCS RAZOR CREST 75331 LIGHT KIT INSTALL GUIDE
NOTE
Repeat Steps 3 - 8 for the other
Booster.
x2
9
