LEGO® ASSEMBLY SQUARE
#10255 LIGHT KIT
INSTALLATION GUIDE

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO® ASSEMBLY SQUARE #10255 LIGHT KIT
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
Assembly Square (10255) Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
PACKAGE CONTENTS 3
PACKAGE CONTENTS:
ADDITIONAL COMPONENTS TO USE
WIRELESS POWER CONNECTORS
(SOLD SEPERATELY)
ASSORTED BRICKS:
2 x Lamp Posts with Bit Light installed
7 x White Bit Light 15cm
1 x White Bit Light 30 cm
1 x Blue Bit Light 30 cm
8 x White Strip Light
1x 8-port Expansion Board
2x 6-port Expansion Board
• 8 x Plate 1×6 (any colour)
• 6x Wireless Power Connectors sets (available to purchase in a 2pk)
• 3x 2-Port Expansion Board (available to purchase in a 4pk)
• 1x 6-Port Expansion Board (available to purchase in a 2pk)
• 1x 30cm Connecting Cable (available to purchase in a 4pk)
1 x Multi Eects Boards (3PFX)
8x Adhesive Squares
1x 5cm Connecting Cable
6x 15cm Connecting Cables
4x 30cm Connecting Cables
1 x USB Power Cable
(Power Source not Included)
* Spares included
NOTE: If you choose to use the Wireless Power Connectors, we recommend
purchasing the aforementioned components before beginning.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin 5
Blueprint 8
Instructions 9
Final Product 65
Troubleshooting 66
Contact 71

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can
can result in bent pins inside the port or
possible overheating of the expansion
board when connected.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
2
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
3
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
4
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Lamp Post w/ Bit Light

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
5
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
8-Port Expansion Board White 15cm Bit Light

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
6
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2x
White 15cm Bit Light

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
7
8
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 15cm Bit Light

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
9
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect to a 5V
USB Power Bank,
AA Battery Pack,
or 5V USB Wall
Adapter (each sold
seperately).
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
2x
USB Power Cable

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
30cm Connecting Cable
Disconnect the
USB Power Cable
Pull the 30cm
Connecting Cable
towards the back of
the room ensuring to
leave the Expansion
Board positioned at
the front entrance.

LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6-Port Expansion Board
