Lightolier 1102TH1R User manual

INSTRUCTION SHEET NO.
© 2000
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE.
This fixture is intended for installation in accordance with the National Electrical Code and local or Federal
code specifications. To assure full compliance with codes and regulations, check with your local electrical
inspector before installation. To prevent electric shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
LIGHTOLIER a GENLYTE THOMAS company
631 Airport Road,Fall River MA 02720
IS:1102TH1R
B0600 Page 1 of 2
INSTALLATION PROCEDURE FOR REMODELER KITS 1102TH1R, 1102TH2R
FOR USE WITH 1102T SERIES TRIMS ONLY
Fig. C
Fig. A
Fig. B
Fig. E
Fig. D
1. CUT OPENING (Fig.A)
Use aperture sticker provided as a template to cut a hole in
the ceiling. Cut to outside edge of sticker.
2. WIRE- IN (Fig. B)
WHITE FIXTURE LEAD to NEUTRAL SUPPLY LEAD; BLACK
FIXTURE LEAD to HOT (120V) SUPPLY LEAD; BARE FIXTURE
WIRE to SUPPLY GROUND. Use wirenuts (local hardware
item). Place all electrical connections in the J-BOX. Attach
J-BOX COVER onto J-BOX. (For CABLE, use built-in CABLE
CLAMP in J-BOX.)
3. ATTACH J-BOX (Fig. C, D, & E)
1. Place J-BOX PLATE onto ceiling and push NAIL TAB into ceiling.
2. Push LONG LEGS of NAIL CLIPS (supplied in parts bag) into
RAISED BUMP of J-BOX PLATE and SHORT LEG into ceiling.
(FIG. E)
WARNING: (RISK OF FIRE) DO NOT INSTALL INSULATION
WITHIN 3” OF FIXTURE SIDES OR WIRING COMPARTMENT,
NOR ABOVE FIXTURE IN SUCH A MANNER SO AS TO
ENTRAP HEAT
J-BOX COVER
RAISED
BUMP
NAIL
TAB
NAIL CLIP LONG LEG
NAIL CLIP SHORT LEG
J-BOX
J-BOX
PLATE
THERMALLY
PROTECTED
BALLAST
MAXIMUM CEILING THICKNESS - (1) INCH

INSTRUCTION SHEET NO.
© 2000
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE.
This fixture is intended for installation in accordance with the National Electrical Code and local or Federal
code specifications. To assure full compliance with codes and regulations, check with your local electrical
inspector before installation. To prevent electric shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
LIGHTOLIER a GENLYTE THOMAS company
631 Airport Road,Fall River MA 02720
INSTRUCTION FOR BALLAST REPLACEMENT
4. ATTACH MOUNTING RING (FIG. F & G)
Push MOUNTING RING into opening until FLANGE sits against
ceiling. Slide MOUNTING STRIOPS down to trap ceiling thickness
and then bend up to secure.
MOUNTING CLIP
MOUNTING RING
FLANGE
FIG. F FIG. G
IS:1102TH1R
B0600 Page 2 of 2
BALLAST REPLACEMENT
1. TURN POWER OFF
2. Remove REFLECTOR TRIM from ceiling (see REFLECTOR TRIM
instructions).
3. Remove BALLAST ASSEMBLY by lifting SPRING on top of J-BOX
and pull BALLAST outward. (Fig. K)
4. Disconnect all wiring.
5. Remove BALLAST ASSEMBLY from J-BOX by pulling SPRING
upward.
6. Remove BALLAST ASSEMBLY through ceiling opening.
7. Disassemble (2) locknuts which held BALLAST to J-BOX COVER.
(Notice orientation of two MOUNTING FINGERS on bottom and
one MOUNTING TAB on top of COVER. They are on the opposite
(inside) surface of the door from which BALLAST is mounted.)
8. Replace old BALLAST with new BALLAST and lock with locknuts.
9. Reassemble new BALLAST ASSEMBLY to J-BOX by replacing
TABS into SLOTS on frame, snap onto SPRING.
10. Rewire Fixture. (SEE WIRING DIAGRAM ON BALLAST LABEL.)
5. PULL-THRU (FIG. H)
6. PUSH-UP (FIG. I)
7. SNAP-IN (FIG. J)
SEE SEPRATE REFLECTOR TRIM
INSTRUCTION SHEET FIG. H FIG. I FIG. J
FIG. K
SPRING
J-BOX
J-BOX
BRACKET
BALLAST
SLOTS
J-BOX
COVER
TABS (2)
IN J-BOX
COVER
BALLAST
ASSEMBLY
