International Concepts Whitewood WC-2424 User manual

ITEM : WC-2424 Printed in Vietnam
- 1 -
Description
Item No.
: Castored Kitchen Work Center
: WC-2424
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take
the time to read and follow the assembly instructions carefully.
ASSEMB Y INSTRUCTIONS

ITEM : WC-2424 Printed in Vietnam
- 2 -
Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please
separate, identify, and count all parts and metal hardware. Compare with part list to be sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call Toll Free: 1-888-944-8396.
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out of reach of children.
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following
parts:
NO Description Qty Sketch NO Description Qty Sketch
A Top 1 B Leg
(L-R) 4
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM : WC-2424 Printed in Vietnam
- 3 -
C Shelf 1
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the
following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1
Flat Washer
(M8.5xM19mm)
8 2
Lock Washer
(M8.5xM13mm)
8
3
Hexagon Nut
(M8x13mm)
8 4
Wrench
(13mm)
1
5 L-Bracket 4 6
Long Screw
(M6x20mm)
16
7
Short Screw
(M3.5x15mm)
8 8 Castor With
Lock 2
9 Castor Without
Lock 2
STEP 1
Attach Legs (B) to the Top (A), use Hexagon Nuts (3), Flat Washers (1), Lock Washers (2) tighten with the
Wrench (4).
Position the shelf (C) between 4 legs, as shown below and attach L-Brackets (5) to the legs by using Screws (7)
tighten with a screw driver.

ITEM : WC-2424 Printed in Vietnam
- 4 -
STEP 2
Attach Castors (8) and (9) to the bottom of legs (B) by using Screws (6). Tighten with the screw driver as shown
below.
