Lightolier Calculite 7065AZ User manual

1
2
3
4
5
5-5 /8" Dia.
6-1 /8" Dia.
9 1/ 2"
10 3 /4"
Calculite®Incandescent Surface Cylinder 7065AZ
Page 1 of 2 6” Aperture ER30 / ER 40 / BR30 / BR40 / PAR38 Multi-Groove Baffle
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Collar: One piece 16 ga. spun aluminum. Matte black finish
2. Heat Insulltor: Fiberglass bulk insulation.
3. Reflector: 16 ga. Specular clear Alzak®aluminum. 50° visual cut-off to lamp
and lamp image.
4. Housing: One piece spun 16 ga. aluminum with returned bottom edge .
Matte white baked enamel finish.
5. Socket: Medium base porcelain, nickel plated screw shell.
6. Multi-groove Baffle: Seamless aluminum; uniform, sharp edged grooves
spaced 1/8" apart. Optical black finish provides ultra-low aperture bright-
ness. Precisely matches 6" aperture recessed Calculites.
Options & Accessories
Stem Kit: 7249 Matte white
Permits surface units to be stem mounted. Supplied with 1/2"
dia. and 5 1/2" dia. canopy. 37 5/8" O.A. Length. Stem can be
cut to length at the job site. Self aligning swivel provides up to
41° vertical adjustment.
Other reflector and housing finishes consult factory.
Electrical
Requires 75°C Supply wires. No.18 SF-1 leads to porcelain socket.
Labels
UL Listed for damp locations, I.B.E.W.
Catalog Number Lamp
7065AZ Matte white ER30,75W
BR30, 85W
BR40, 120W
ER40, 120W
PAR38, 150W
Alzak®is a registered trademark of ALCOA.

(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
RCR = 10
RCR = 5
RCR = 1
Black MultiGroove with 100W PAR38 FL IR
2070 Lumens per lamp.
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
11109876543
12010080604020
80
70
60
50
40
30
20
10
COEFFICIENTS OF UTILIZATION
%
EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
0
.70
.69
.68
.66
.65
.63
.62
.60
.59
.58
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10
1.81.80.79 .80 .79 .78 .77 .76 .76 .74 .74 .73 .72 .72 .71
2.78.77.75 .77 .75 .74 .75 .74 .73 .73 .72 .71 .71 .70 .70
3.76.74.72 .75 .73 .72 .73 .72 .70 .72 .71 .69 .70 .69 .68
4.74 .71 .70 ..73 .71 .69 .72 .70 .68 .70 .69 .68 .69 .68 .67
5.71.69.67 .71 .68 .67 .70 .68 .66 .69 .67 .66 .68 .66 .65
6.70.67.66 .69 .67 .65 .68 .66 .65 .68 .66 .64 .67 .65 .64
7.68.65.64 .67 .65 .63 .67 .65 .63 .66 .64 .63 .65 .65 .63
8.66.64.62 .65 .63 .62 .65 .63 .62 .65 .63 .61 .64 .62 .61
9.65.62.60 .64 .62 .60 .64 .62 .60 .63 .61 .60 .63 .61 .60
10 .63 .61 .59 .63 .61 .59 .62 .60 .59 .62 .60 .59 .62 .60 .58
% WALL REFLECTANCE
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
0
.81
.80
.80
.79
.79
.78
.78
.77
.77
.76
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10
1.93.92.91 .92 .91 .90 .88 .88 .87 .86 .85 .85 .83 .82 .82
2.91.89.87 .89 .88 .86 .87 .86 .85 .85 .84 .83 .83 .82 .81
3.88.87.85 .87 .86 .84 .86 .84 .83 .84 .83 .82 .82 .82 .81
4.87.85.83 .86 .84 .82 .85 .83 .82 .83 .82 .81 .82 .81 .80
5.85.83.81 .85 .83 .81 .83 .82 .80 .82 .81 .80 .81 .80 .79
6.84.82.81 .84 .82 .80 .83 .81 .80 .82 .80 .79 .81 .80 .79
7.83.81.79 .83 .81 .79 .82 .80 .79 .81 .79 .78 .80 .79 .78
8.82.80.79 .81 .80 .78 .81 .79 .78 .80 .79 .78 .80 .78 .77
9.81.79.78 .81 .79 .78 .80 .79 .77 .80 .78 .77 .79 .78 .77
10 .80 .78 .77 .80 .78 .77 .79 .78 .77 .79 .78 .77 .79 .77 .76
% WALL REFLECTANCE
Uikllthttdti i fliifdidl l fill i ti
(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
RCR = 10
RCR = 5
RCR = 1
Black MultiGroove with 100W PAR38 SP IR
2070 lumens Per Lamp
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
11109876543
12010080604020
80
70
60
50
40
30
20
10
Use quick calculator chart to determine spacing of luminaires for desired level of illumination.
Conversion Factors:
120W BR40 SP, F.C. X 0.65.
90W BR40 SP, F.C. X 0.45.
75W BR40 SP, F.C. X 0.30.
60W IR PAR38 SP, F.C. X 0.5.
60W PAR38 SP, F.C. X 0.4.
90W PAR38 SP, F.C. X 0.6.
90W IR PAR38 SP, F.C. X 0.7.
120W PAR38 SP, F.C. X 0.9.
Use quick calculator chart to determine spacing of luminaires for desired level of illumination.
Conversion Factors:
60W IR PAR38 FL, F.C. X 0.5.
60W PAR38 FL, F.C. X 0.4.
90W PAR38 FL, F.C. X 0.6.
90W IR PAR38 FL, F.C. X 0.7.
120W PAR38 FL, F.C. X 0.9.
TESTED ACCORDING TO IES PROCEDURES. TEST DISTANCE EXCEEDS FIVE TIMES
THE GREATEST LUMINOUS OPENING OF LUMINAIRE.
ZONE LUMENS % LAMP % LUMINAIRE
0–30 1427 58.95 96.37
0–40 1473 71.18 99.48
0–60 1480 71.52 99.98
0–90 1481 71.55 100.00
40–90 7 .37 .52
60–90 0 .03 .04
90–180 0 .00 .00
0–180 1481 71.55 100.00
** EFFICIENCY = 71.68% **
ZONAL LUMENS AND PERCENTAGES
CANDLEPOWER SUMMARY
ANGLE MEAN CP LUMENS
020704
511761 1142
10 3622
15 1199 448
20 306
25 185 84
30 53
35 2 9
40 0
45 0 0
50 0
55 0 0
60 0
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
CERTIFIED TEST REPORT NO.0942FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
SURFACE CYLINDER DOWNLIGHT
5 5/8” APERTURE, BLACK MULTI-GROOVE FINISH INSIDE CYLINDER
100W PAR38 SPOT GE IR LAMP. LUMIN RATING = 2070 LMS.
TESTED ACCORDING TO IES PROCEDURES. TEST DISTANCE EXCEEDS FIVE TIMES
THE GREATESTLUMINOUS OPENING OF LUMINAIRE.
ZONE LUMENS % LAMP % LUMINAIRE
0–30 1674 80.89 99.46
0–40 1683 81.33 100.00
0–60 1683 81.33 100.00
0–90 1683 81.33 100.00
40–90 0 .00 .00
60–90 0 .00 .00
90–180 0 .00 .00
0–180 1683 81.33 100.00
** EFFICIENCY = 81.3% **
ZONAL LUMENS AND PERCENTAGES
CANDLEPOWER SUMMARY
SPACING RATIO = 0.2
SPACING RATIO = 0.6
CERTIFIED TEST REPORT NO. 0940FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
SURFACE CYLINDER DOWNLIGHT
5 5/8” APERTURE, BLACK MULTI-GROOVE FINISH INSIDE CYLINDER
100W PAR38 FL GE IR LAMP. LUMIN RATING = 2070 LMS.
ANGLE MEAN CP LUMENS
04332
53878 368
10 3325
15 2694 727
20 1543
25 576 333
30 180
35 49 45
40 16
45 6 6
50 3
55 1 1
60 0
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
DATE: SEPT. 21,1999
PREPARED FOR:
LIGHTOLIER, FALL RIVER,MA
DATE: SEPT. 22,1999
PREPARED FOR:
LIGHTOLIER, FALL RIVER,MA
Calculite®Incandescent Surface Cylinder 7065AZ
Page 2 of 2 6” Aperture ER30 / ER 40 / BR30 / BR40 / PAR38 Multi-Groove Baffle
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
