Lightolier Alice 46531 User manual

Alice®46531
Page 1 of 1 Fluorescent Bath Series
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Housing: Die-formed 22 gauge prefinished steel.
2. End Cap: (2) Die-cast zinc alloy.
3. Diffuser Assembly: Extruded aluminum side rails with die cast zinc alloy
end covers. Silicone rubber gasket provided to eliminate light leaks.
Stainless steel spring clips provide easy access for relamping. See chart for
diffuser options.
4. Reflector: Die formed 22 gauge steel, Reflective white finish.
5. Ballast: Universal Electronic, high power factor.
6. Side Diffuser: Extruded UV stabilized acrylic.
7. Lamp: 17W, 25W, or 32W T-8 triphosphor fluorescent (medium bi-pin
base).(by others)
8. Mounting: Center knock-out pattern for direct mounting to 3: or 4” octago-
nal Gem outlet boxes.
9. Auxiliary Mounting: Provided for direct mounting to wall surface.
10. Wiring Kit Connection Detail: For use with Lightolier Wall Wiring Kit -
Catalog Number 46700.
11. In-Line Connection Detail: Provided for Installations where fixtures are to
be mounted end to end. Linear connection and hardware provided with each
fixture.
Electrical
Fluorescent: 1-Light 2-Light 2-Light 2-Light
25W 17W 25W 32W
Ballast: Electronic 120 277 120 277 120 277 120 277
Total Input Watts 16 17 29 30 43 43 57 56
Max. Line Current (amps) 14 .07 .24 .11 .36 .16 .48 .21
Power Factor >.97 >.97 >.97 >.97 >.97 >.97 >.97 >.97
Ballast Factor .87 .87 .87 .87 .87 .87 .87 .87
THD <10% <10% <10% <10% <10% <10% <10% <10%
Min. Starting Temps. -18°C -18°C -18°C -18°C -18°C -18°C -18°C -18°C
(-0°F) (-0°F) (-0°F) (-0°F) (-0°F) (-0°F) (-0°F) (-0°F)
Mounting
Horizontal or Vertical wall mount only.
Labels
UL listed suitable for damp locations.
Ordering Information
Catalog Number Nominal Length Lamp Ballast Finishes
Bullnose Opal Diffuser
46824PB 46821PB 2 ft. (2) 17W T8 Universal Electronic 120/277V Polished Brass (PB)
46534PB 46531PB 3 ft. (1) 25W T8 Universal Electronic 120/277V *For Polished Chrome Finish use
46834PB 46831PB 3 ft. (2) 25W T8 Universal Electronic 120/277V suffix “PC” after catalog number
46844PB 46841PB 4 ft. (2) 32W T8 Universal Electronic 120/277V instead of “PB”.
