READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE INSTRUCTION SHEET NO.
his fixture is intended for installation in acc=xdance with the National Electrical Code end local
sgulations.To asaure full compiianca with local cades and regulations, chedr with your local eleotricel
wpeotor before installation. To prevent elestricel shook,turnoff eleririoity at fuee box before proceeding. IS:5410
Retain these instructions for maintenance reference. 1291
INSTRUCTIONS FOR INSTALLATION OF HELIOS
COVERS FIXTURES 5410,5411, and 5414
LFOR OCTAGONAL OUTLET BOX MOUNTING. /
1. ScrewCOVER PLATEto the backsideof MOUNTINGPIATE with SCREWSprovided.
2. Pull supplywires from OUTLET BOXthroughthe LOWERWIREWAYHOLEin MOUNTINGPL4TE.
3.Using outlet box screws (provided with outlet box) secure MOUNTING PLATE to outlet box using appropriate SLOTS in MOUNTING PL4TE.
4. Using the uppermost MOUNTING SLOT in MOUNTING PtATEfurthersecure MOUNTING PWTE dhectlyto wall using wood screws, toggle
boltsor alternate fastener (not provided) depending on wall material.
3. FOR VERTICALLY MOUNTED RECTANGULAR GEM OR SWITCH BOXES.
1. Pull eupply wires from outlet box through the LOWER WIREWAY HOLE in MOUNTING PLATE.
2. Using outlet box saews (provided with outlet box) secure MOUNTiNG PIATE to outlet box using the two LOWER SWITCH BOX SLOTS.
NOTE If desired, fixture can be mounted 31/4” lower relative to outlet box by following the above two steps using the upper switch box slots
and upper wireway hole.
‘4. Using the upper MOST MOUNTiNG SLOT in MOUNTING PLATE further secure MOUNTING PLATE
directly to wall using wood screws, toggle bolts or alternate fastener (not provided) depending on well material.
‘.
1. IC31”ITC>I.I Is la” R%&5,T&w%:.R
., IhI

NS”IRUCTION SHEET NO.
IS:541O
0091 Page 2of 2
A. INSTALLATION OF FIXTUREBODY
1.RemoveDIFFUSERfromFIXTUREBODYbygentlygrasping DIFFUSERtowardstopandpull directly awayfrom DIFFUSER
PAN.
2, Hook HANGER LOOPoverone of HANGER TABSon MOUNTING PWTEandallow titiuretohang. \
3, Make mnnections black fislure Iaad or fixture lead without frac=srmarks to black (hot) supply lea~ white fixture lead or
fixture leadwith tracer marks towhite (neutral) supply Iead. UnlnsuIated fixture wires aregroundwires andall mustbe
connected togrounding terminal orwirein’outlet box”, Usewirenute (local hardware item).
CAUTION: Pushsupplywires andwirenut connections backintoouilet box.
4. Mount FIXTURE BODY to MOUNTING PIATE by angling HOUSING TABS up through RECTANGULAR SLOTS in
MOUNTING PIATE.
CAUTION: Makecetinthat nowiresars pinched beWeenmounting plate and fifiurebody.
5. Gently push fixture bodyagainst waii until MOUNTiNG STUD comes through SLOT in FiXIURE BODY, seaure in plaae using
STAR WASHER and BATTERY NUT.
6. Install recommended lamp by engaging iamp base into SOCKET and then snapping into LAMP CLIP.
7. Position open end of DIFFUSER down into FIXTURE BODY@ andgentlypushDIFFUSERbaskagainstDIFFUSERPAN
until DIFFUSER anaps into plac8@.
NOTE Suppodback of DIFFUSER PAN before snapping DlFFUSERintopla~.
CAUTION: Uselamptypes/wattages asmarked on fixture, Forveriicel mounting only.
