Lytespan®Track Lighting System 6282
Page 1 of 2 Par Ring Lytespot®
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
General Description
Minimal, functional form with clearly detailed yoke and attractive ring shaped
Iampholder. Fixture is specially designed to use efficient, precise controlled 75W
PAR-30 tungsten halogen lamp which gives a whiter, brighter light than standard
incandescent reflector and PAR lamps. With a choice of narrow flood and narrow
spot beam spread, they are ideal for jewelry display, sculpture and other mer-
chandise applications. Tensioned trunion mounting allows Lytespot to remain
fixed at any angle. Unit adjusts horizontally up to 350°, vertically up to 90°.
Finish
All painted finishes baked enamel.
Electrical
Porcelain socket, medium base, nickel plated screw shell. No. 1 braided
SF-1 leads.
Labels
UL; C.S.A.; I.B.E.W.
Catalog No. Finishes Mounting Lamps
6282 Matte White All Lytespan Track 75W PAR-30 (Tungsten-Halogen)
6283 Matte Black Systems
LYTESPAN ATTACHMENT
FITTING: Molded
polycarbonate. Integral
color. Fitter twists onto
track and locks on.
PUSH TAB: Molded poly-
carbonate. Detaches unit.
YOKE: .093” steel.
TRUNION MOUNTING:
Tensioned with internal
spring washer and vibration-
resistant nut.
MOVABLE BRASS
CONTACT: Extends for
connection to 2nd circuit
in Advent Lytespan Track.
POLARITY KEYWAY
PIVOT MOUNTING
Tensioned; 350° stop.
SOCKET COVER: Molded
Valox®integral color.
INNER RING: .040” aluminum; snaps
out for lamp replacement.
HOUSING: .040” aluminum
Valox®is a trademark of General Electric.

Lytespan®Track Lighting System 6282
Page 2 of 2 Par Ring Lytespot®
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Job Information Type:
Lighting Data
(FC) is the initial footcandles at the center of the beam.
(L) and (W) are to the point that the candlepower drops to 50% of maximum.
