4SB115 (18) (21)
Decorative, Pendalux Suspension, Basic Canopy
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Nominal OAL
Body Diagram
A
C
5
4
3
45º
Complete Luminaire consists of Body and Suspension. Order each separately.
Short (Close to Ceiling) Single Stem Suspension, with Swivel, Basic Canopy.
Catalog No. Suggested Use w/Luminaire dia. Nominal Overall Length (A)* Suspension (Stem) and Canopy Finish
4SB115PB 23" or 28" 8 ⅞" Polished Brass
4SB115SB 23" or 28" 8 ⅞" Satin Brass
4SB115SN 23" or 28" 8 ⅞" Satin Nickel
4SB115WH 23" or 28" 8 ⅞" White
4SB118PB 35" 10 15 ⁄16"Polished Brass
4SB118SB 35" 10 15 ⁄16"Satin Brass
4SB118SN 35" 10 15 ⁄16"Satin Nickel
4SB118WH 35" 10 15 ⁄16"White
4SB121PB 42" 11 ⅝" Polished Brass
4SB121SB 42" 11 ⅝" Satin Brass
4SB121SN 42" 11 ⅝" Satin Nickel
4SB121WH 42" 11 ⅝" White
*Add this length (A) to Body length (C) from Body Spec Sheet(s) to get Total Luminaire Nominal OAL.
4SB115 (18) (21)
Decorative, Pendalux Suspension, Basic Canopy
Page 2 of 2
Philips Lightolier
e: [email protected]
t: (508) 679-8131
w: www.lightolier.com
4SB115 May 24, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Nominal OAL
Body Diagram
A
C
5
4
3
45º
Specifications
1. Suspension Size: For optimum performance, testing
recommends luminaire total OAL (overall length) in
proportion to the body diameter. For close-to-ceiling
mounting, it is suggested to use shorter single stems as noted
on Spec Sheet SB115. Total luminaire OAL is defined from the
bottom of the diffuser to ceiling plane.
2. Stem Wires: Equipped with 120" of leads with keyed
connectors for quick connection to body wiring.
3. Suspension: Swivel (central) stem, ⅝" steel tube. Die-cast
ball hanger standard.
4. Mounting Strap (Cross Bar): Die-formed galvanized steel.
5. Canopy: Steel, 7" diameter, fastened internally, no exposed
hardware. Ball hanger on stem that fits into cross bar allows
installation on ceilings with slope up to 45 degrees. Complies
with California Earthquake Code.
6. Cutting Jig: All suspensions are equipped with a cutting jig
that simplifies cutting of center stem pipe in the field .
Options & Accessories
If a longer overall length is desired, use a suspension paired with
a larger body.
If an overall length of greater than 42" is desired, use an
extension stem. Order as a third additional component to make
complete fixture. Please see Spec Sheet No. 4SXT.
Mounting
Mounts directly to 4" outlet box, using crossbar hanger, supplied.
Note: Additional luminaire support plate provided with 35/42"
diameter body to allow luminaire to be supported independent of
the outlet box.
Labels
cULus. Suitable for damp locations.
