LT Series
THERMOPLASTIC LED EXIT
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: Illumination
of the exit stencil face is
accomplished with long-lasting,
high-output Light Emitting
Diodes (LEDs). Hot spots and
striations are eliminated by
the internal “light chamber”
specially designed around the
high-performance LED array.
Housing: Impact resistant,
UL 94 V-0, 5 VA thermoplastic
housing with NFPA-compliant
field-selectable chevrons.
Chevrons can be installed/
removed from outside the
exit housing. White and black
housing finish is available.
Stencil face is easily removed
for installation, maintenance,
and inspection. UL damp
location listing is available
as a factory option. Housing
design simplifies installation,
and does not require hard
wire terminations inside of the
exit housing. The installation
process enables the installer
to easily make all wiring
connections in the junction
box, while all mechanical
connections between the exit
housing and canopy are made
tool free.
Operating Temperature
Range: Standard Location
65°F (19°C) to 85°F (30°C)
Damp Location
50°F (10°C) to 104°F (40°C)
Electronics: AC Only -
120/277 VAC dual voltage
input with surge protection.
Optional 12 VDC input from
remote emergency power
source.
Self-Powered - 120/277 VAC
dual voltage input with surge-
protection, solid-state circuitry
provides for a reliable charging
system. Charging system is
complete with low voltage
disconnect, AC lockout,
brownout protection, AC
indicator lamp and test switch.
Electrical Specifications:
AC Only (120 VAC):
Red - .89 W
Green - 2.17 W
Self-Powered (120 VAC):
Red - 3.62 W
Green - 2.79 W
Code Compliance
UL 924 and optional UL damp
location listed. NFPA 101,
NEC, BOCA, OSHA and IBC
illumination standards
Warranty
Five year full electronics
warranty. Five year full plus
five year prorated battery
warranty.
LTN1RW
13.75"
(35.0 cm)
1.66"
(4.2 cm)
9.5"
(24.1 cm)
7.3"
(18.5 cm)
5.05"
(12.8 cm)
.6"
(1.5 cm)

LT Series
THERMOPLASTIC LED EXIT
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
LT Series November 3, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Ordering Information
Series
LT = Thermoplastic
LED Exit
LT
R= Red
G= Green
Letter Color
2CKT1 = 120 VAC Two Circuit
2CKT2 = 277 VAC Two Circuit
BF = Buzzer/Flasher (emergency operation only)
BZ = DC Buzzer (emergency operation only)
DC12 = 12 VDC Remote Emergency Power (AC only)
DL = UL Damp Location Listing
FA = 24 VDC Fire Alarm Interface (reg. constant DCvoltage)
FL = Flasher (emergency operation only)
ST = Special Input Transformer (specify voltage & frequency)
SW = Special Wording/Graphics (consult factory)
TP = Tamperproof
VRS = Vandal Resistant Lens
Factory Installed Options1
Note
1) Some option combinations may impact UL listing. Consult factory for specifics.
2) Custom pendant lengths and colors available, consult factory.
1= Single
2= Double
U= Universal
Stencil Faces
Accessories (order as a separate item)
SPKIT12WH2= Pendant Kit, 12” White
SPKIT12BK2= Pendant Kit, 12” Black
A= AC Only
N= Nickel
Cadmium
Battery
W= White
B= Black
Face/Housing Color
