Lightolier ProSpec 37104 User manual

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
ProSpec™120V/277V Track Lighting 37104
Page 1 of 2 Mini HID, Step Spot, 20W PAR20 CMH
Features
1. Track Attachment Fitting: Molded polycarbonate, rotates into track.
2. Locking Lever: Steel pin. Locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Ballast Housing: Extruded aluminum housing with die-cast aluminum
end caps.
5. Ballast: Electronic HID.
6. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical
rotation with tensioned mounts for controlled aim.
7. Lamp Housing: Die-cast aluminum with cool-grip® insulation band; a high
temperature silicone rubber which allows aiming adjustments while fixture is
on. Integral color.
8. Lampholder: Medium base 5kV pulse rated glazed porcelain body socket
with plated nickel screw shell and lamp contacts; 18AWG SEW-2 leads
encased in fiberglass sleeving.
9. Cowl: Painted steel; retaining ring included to hold accessory in place.
Accessories
Holder: Integral, holds one accessory
Diffusion/ Special Filters: AF25 series
Color Filters: ADF25 series
Louver (Hex Cell): AL25HC
Electrical
Electronic Ballast (Thermally Protected)
Input Voltage: 120V/277V Total Harmonic Distortion: <10%
Power Factor: >0.99 ANSI Code: M (C) 156
Input Power: 24W Do not use on dimming circuit
Max Input Current: 0.20A@120V/0.09A@277V
Finish
All painted finishes are baked powder or enamel.
Markings
U.L., c.U.L.
7 7/32"
[184 mm]
7 7/8"
[200 mm]
7 15/16"
[202 mm]
1 31/32"
[50 mm]"
4 11/16"
[119 mm]
3 7/32"
[81 mm]
4 15/16"
[125 mm]
2 1/2"
[64 mm]
1 5/8"
[41 mm]
3 1/4"
[83 mm]
Catalog No. Finish Mounting Lamp
37104WH
37104BK
White
Black
ProSpec®120V/277V track systems only. 20W PAR20 CMH (M156) E26 medium base
Not included
9
7
8
6
1
3
2
4
5

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
ProSpec™120V/277V Track Lighting 37104
Page 2 of 2 Mini HID, Step Spot, 20W PAR20 CMH
13000 7500
GE CMH20PAR20/SP
8°
3750 7500
GE CMH20PAR20/FL
25°
Lamp
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
Aiming Angle: 0° 30° Horizontal 30° Vertical 45° Vertical
L Beam length DDistance
W Beam Width AAiming Angle
CDistance to center beam FC Footcandles
Land W are the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp manu-
facturers for availability and performance.
CBCP = Center Beam Candle Power.
D FC L W D C FC L W D C FC L W D C FC L W
8' 4.6' 132 1.5' 1.3'
10' 5.8' 84 1.9' 1.6'
12' 6.9' 59 2.2' 1.9'
14' 8.1' 43 2.6' 2.3'
3' 5.2' 181 1.7' 0.8'
4' 6.9' 102 2.3' 1.1'
5' 8.7' 65 2.8' 1.4'
6' 10.4' 45 3.4' 1.7'
4' 4.0' 287 1.1' 0.8'
5' 5.0' 184 1.4' 1.0'
6' 6.0' 128 1.7' 1.2'
7' 7.0' 94 2.0' 1.4'
8' 203 1.1' 1.1'
10' 130 1.4' 1.4'
12' 90 1.7' 1.7'
14' 66 2.0' 2.0'
6' 3.5' 68 3.6' 3.1'
8' 4.6' 38 4.8' 4.1'
10' 5.8' 24 6.0' 5.1'
12' 6.9' 17 7.2' 6.1'
2' 3.5' 117 4.2' 1.8'
3' 5.2' 52 6.2' 2.7'
4' 6.9' 29 8.3' 3.5'
5' 8.7' 19 10.4' 4.4'
3' 3.0' 147 2.8' 1.9'
4' 4.0' 83 3.7' 2.5'
5' 5.0' 53 4.7' 3.1'
6' 6.0' 37 5.6' 3.8'
6' 104 2.7' 2.7'
8' 59 3.5' 3.5'
10' 38 4.4' 4.4'
12' 26 5.3' 5.3'
