Lilin DVR308 User manual

4/8/16CH DIGITAL VIDEO RECORDER
DVR304/308/316
INSTRUCTION MANUAL
MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com 66-DVR304CSE

Summary
DVR series are designed to meet the demands for full 4/8/16-channel real-time recording
systems. Frame rate, video quality, and resolution can be adjusted for each channel to meet
recording requirement. VGA engines are built-in 3D intellectual motion adoptive refinement
with vivid image enhancement algorithm to provide best video quality.
DVR series provide various backup features include USB DVD/RW, USB flash disk, HTTP
download, and Backup Manager FTP for multiple DVRs’ files download. Mobile phone device
remote monitoring is also supported. Browser based remote live monitoring and video
playback features are provided.
The DVR can provide D1 real-time for 4-channel and CIF real-time for 8-/16-channel recording
and playback. Full features web-based user interface, multiple DVR system monitoring
features, various backup features, and easy of cabling, the DVR is ideal solution for DVR
applications.
Major Features
 Full D1 real-time for 4-ch and CIF real-time for 8-/16-channel H.264 recording and
playback
 VGA outputs at 1920 * 1080i, built-in 3D intellectual motion adoptive refinement and vivid
image enhancement engines
 Concurrent multiple-channel playback for 4/8/16-channel.
 Audio recording and playback
 Full features of remote controller controlling
 HTTP web-based interface including DVR configuration, PTZ control, playback, and live
monitoring.
 3G mobile phone solutions provided.
 Resolution, frame rate, and video quality configurable for each channel.
 LCD Power saving design.

DVR User Manual 1
Trademarks and registered trademarks
Microsoft, Windows 2000, Windows XP, Internet Explorer are registered trademarks of
Microsoft Corporation in the U.S. and/or other countries.
Adobe and Adobe PDF are registered trademarks ofAdobe Systems Incorporated in the U.S.
and/or other countries.
JavaScript and all Java-based trademarks and logos are trademarks or registered trademarks
of Sun Microsystems, Inc. in the U.S. and/or other countries.
Linux, Macintosh, Mozilla, and Netscape Navigator are registered trademarks of the respective
holders.
Pelco is a trademark of Pelco - Clovis, CA, and may be registered in certain jurisdictions.
Other names of companies and their products mentioned in this manual may be trademarks or
registered trademarks of their respective owners.
Caution
• Do not drop or strike this equipment
• Do not install the equipment near any naked flames or heat sources
• Do not expose this unit to rain, moisture, smoke or dust environment
• Do not cover the opening of the cabinet with cloth and plastic or to install this unit
in poor ventilated places. Allow 10cm between this unit and its surroundings
• Do not continue to operate the unit under abnormal conditions such as detection
of smoke, strange smell or no display on screen while power is turned on
• Do not touch the power connection with wet hands
• Do not damage the power cord or leave it under pressure
• Do not operate this unit near magnet, speaker system, etc., to avoid unnecessary
magnetic interference
• Connection cables should be grounded properly
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS

DVR User Manual 2
