Lincat OE7011 Manual

IS398 ECN35921
OE7011 & OE7012
Electric Boiling Tops
USER, INSTALLATION AND SERVICING
INSTRUCTIONS
For use in GB & IE

IS398 ECN3592
2
Dear Customer,
Thank you for purchasing this Lincat product.
This is just one of over 300 different items of catering equipment available
which is constantly being extended and improved. Details are available from
your local distributor or direct from us.
Used for the purposes for which it is intended, and with careful maintenance
as outlined in this User Guide, your Lincat product will give you years of
trouble free service.
IMPORTANT INFORMATION
Please read all of the safety and operating instructions carefully before using this
product. Please pay particular attention to all sections of this User Guide that carry
warning symbols and notices.
WARNING!
This is a Warning symbol. This symbol is used throughout the user guide
whenever there is a risk of personal injury. Ensure that these warnings are
read and understood at all times.
CAUTION!
This is a Caution symbol. This symbol is used throughout the user guide whenever
there is a risk damaging your Lincat product. Ensure that these warnings are read
and understood at all times.
NOTE:
This is a Note symbol. This symbol is used throughout the user guide to provide additional
information, hints and tips.

IS398 ECN3592
3
CONTENTS
Contents Page
Customer Information………………………………………………………. 2
Warnings and Precautions………………………………………………… 4
Technical Data……………………………………………………………….. 5
Commissioning………………………………………………………………. 6
Check List of Enclosures…………………………………………………... 6
Installation…………………………………………………….……………… 7
User…………………………………………………………………………….. 8 - 9
Component Replacement ………………………………………….……… 10
Spare Parts List……………………………………………………………… 11
Wiring Diagram………………………………………………………………. 11
Service information………………………………………………………….. 12
Guarantee………………………………………………………….………….. 12

IS398 ECN3592
4
WARNINGS AND PRECAUTIONS
It is mandatory that all appliances are installed, commissioned and serviced by a qualified and
competent person as defined by the regulations in force in the country of installation.
Failure to comply will invalidate the warranty.
WARNING!
This appliance must be installed by a competent installation engineer in accordance with
the installation instructions, and should conform to the following requirements:
Local and National Building Regulations
Fire Precautions Act
Health & Safety At Work etc Act
BS EN60335-1 & BS EN60335-2-36
Do not obstruct or block the appliance flue.
After operation, some parts of the appliance will remain hot for a period of time. Please
take care to avoid accidental burns.
CAUTION!
All equipment must be earthed to prevent shock.
A means of disconnection must be incorporated in the fixed wiring having a contact
separation of at least 3.0mm in all poles.
Supply cords shall be oil-resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent synthetic elastomer-sheathed cord (code designation 30245
IEC 57)
Connection of the electrical supply cable is made at the rear of the unit. Remove the
protective cover and fit a suitable cable into the strain relief and then to the inlet terminal
block. The unit is supplied for connection to a three-phase supply. Connections are
provided to allow termination of all three-phase cables, although only two are used to
power the unit (OE7012).

IS398 ECN3592
5
TECHNICAL DATA
Model
OE7011
OE7012
Dimensions
Overall Height (mm)
325
325
Width (mm)
900
600
Depth (mm)
760
760
Weight (kg)
67
40
Hob Cooking Surface w x d (mm)
900 x 600
600 x 600
Electrical
Hob Rating –per hob element
2.6 kW
2.6 kW
Total Power Rating @ 400V three phase
Phase
1
5.2 kW
Phase
1
5.2 kW
Phase
2
5.2 kW
Phase
2
5.2 kW
Phase
3
5.2 kW
Phase
3
Not
used
Voltage 3N~
Phase
1
22.6A
Phase
1
22.6A
Phase
2
22.6A
Phase
2
22.6A
Amps 3N~
Phase
3
22.6A
Phase
3
Not
used
Total Power Rating
15.6 kW
10.4 kW

IS398 ECN3592
6
NOTE
COMMISSIONING
PREPARATION
Remove all packaging and protective coatings prior to installation.
The appliance is supplied as standard with adjustable feet.
CHECK LIST OF ENCLOSURES
Please ensure the following items are included with this piece of equipment:
Model
OE7011
OE7012
Tick
Warranty Card
1
1
User Instructions
1
1
SERIAL NUMBER
Each appliance manufactured at Lincat has a unique identifying number found in the top
right hand corner of the data plate attached at the rear of the appliance. Please record that
number in the space provided should it be required for future reference.
Serial Number
MARK OF CONFIDENCE
Every singe product that leaves our factory bears a serial plate showing the assembler’s
initials. It’s a mark of confidence we have in our people and our manufacturing process.

IS398 ECN3592
7
INSTALLATION
SITING
The appliance must be installed in accordance with the appropriate regulations listed prior.
The appliance should be installed on a level surface ensuring the unit is stable, firmly located and
positioned to minimise the possibility of accidental touching.
A clear space of at least 100mm must be left to the rear of the appliance to allow for servicing with a
clear space of 600mm to the front to allow for safe operation. A minimum space of 100mm must be
left between any side of the unit and any combustible surface or walls.
Any partitions, walls or kitchen furniture in close proximity must be of non-combustible
materials and not be closer than 100mm from the sides and rear of the flue.
ELECTRICAL SUPPLY AND CONNECTION
Connection of the electrical supply cable is made at the rear of the unit. Remove the protective cover
and fit a suitable cable into the strain relief and then to the inlet terminal block. The unit is supplied
for connection to a three-phase supply. Refer to schematic on page11.
HOTPLATES
Hotplates are controlled by six position rotary switches, ‘6’ is the hottest. Off is indicated by a filled
circle as shown in the control panel illustration on page 5.
.

IS398 ECN3592
8
USER INSTRUCTION
APPLIANCE USE
This appliance is only for professional use and should only be used by qualified personnel.
Ensure that the person responsible understands how to safely operate, clean and shut down
the appliance and is made aware of the position and operation of the isolating switch in the
event of an emergency.
CONTROL PANEL
MAINS POWER ON
ON/OFF INDICATOR HOB INDICATOR
HOTPLATES
LH REAR HOB
LH FRONT HOB MIDDLE REAR HOB
MIDDLE FRONT HOB RH REAR HOB
RH FRONT HOB
OVEN THERMOSTAT CONTROL KNOB
HOB INDICATORS
OFF HIGH
LOW
HOB CONTROL KNOBS
LH FRONT HOB
MIDDLE REAR HOB
MIDDLE FRONT HOB
RH REAR HOB
RH FRONT HOB
PAN SUPPORTS
CONTROL PANEL
LH REAR HOB
HOB FRONT
ON / OFF INDICATOR
HOB INDICATOR
MAINS POWER ON
OVEN ELEMENT POWER ON
1 2 3 4 5 6
HOTPLATE CARE
Before using the appliance for the first time;
Without pans, turn to the maximum setting for approximately four minutes before turning off or
adding pans. This allows the plates to cure and harden to obtain maximum durability.
HOTPLATE OPERATION
Hotplates are controlled by six position rotary switches, 6 is the hottest. ‘Off’ is indicated by a filled
circle, as shown in the control panel illustrations above.
NB: It is important that good quality pans are used to ensure maximum efficiency. Wherever possible
always use lids.
SHUT DOWN
To shut down the appliance rotate all control knobs clockwise to the OFF position.
After operation, some parts of the appliance will remain hot for a period of time; care
should be taken to avoid risk of burns.

IS398 ECN3592
9
CLEANING
Ensure the Electricity supply is isolated before commencing cleaning.
Hotplates
Ensure hotplates are cool before cleaning.
Hotplates can be wiped down with a moist cloth. For more stubborn dirt commercial cleaners
and scourers may be used.
After cleaning apply a thin film of vegetable oil to the plates.
External Cleaning
Do not use abrasives on stainless steel or enamelled parts.
Do not use any products containing chlorine or hydrochloric acid to clean stainless steel
surfaces.
Do not clean the appliance using a water jet.

IS398 ECN3592
10
COMPONENT REPLACEMENT
Hotplate Switch
1. Remove the control knobs and fascia panel, by firstly removing screws.
2. Protect the surrounding area panel work with soft material and support the fascia panel
against it. Access to the hotplate switches is now possible. Remove completely the
component screws from the fascia.
3. Remove and replace wires correctly, ideally transferring wires across, from the old switch to
the new, one at a time. Numbering each wire with an indelible pen may also help.
4. Replacement is a reversal of the removal sequence. Be careful not to trap the wiring harness
whilst replacing the fascia and check the wiring is still protected where it passes through the
heat deflector.
Hotplate
1. Remove the control knobs and fascia panel, by firstly removing screws.
2. Protect the surrounding area panel work with soft material and support the fascia panel
against it. Access to the hotplate switches is now possible. Remove completely the
component screws from the fascia.
3. Unscrew the heat deflector. Access to the hotplate restraining nuts is now possible through the
fascia.
4. Remove the hotplate restraining nut and press the underside of the hotplate up to facilitate
easy removal from above. Protect the surrounding panel work with soft material. Support the
hotplate and access to the hotplate connection block is now possible. Number the wires with
an indelible pen to facilitate replacement.
5. Replacement is a reversal of the removal procedure, taking care not to trap the wiring harness.
6. Check the unit for electrical safety.
HOTPLATE
ELEMENT
HOTPLATE
SWITCH
GREEN
NEON

IS398 ECN3592
11
Part Number
Part Description
Used On
EL188
Hotplate Element
All models
KN227
Control Knob –Hob
All models
LE37
Adjustable Leg
All models
NE38
Green Neon
All models
SW14
Six Position Switch
All models
TE45
Terminal Block
All models
Wiring Diagram
4 3
1
2
REAR
FRONT
NE39
GREEN
NEON
TE45
TERMINAL
BLOCK
Each pair of hotplates are wired the same in all aspects except the pair of controls which are nearest the neon. These have the additional wires for the green neon.
2 3 1 4
2 3 1 4
2
1 3
4
SW14
HOTPLATE
SWITCH
SW14
HOTPLATE
SWITCH
EL188
HOTPLATE
EL188
HOTPLATE
The OE7011 uses all three phases (L1, L2, L3), with a pair of hotplates being served by a phase each.
The OE7010 uses L1 and L2 only, having only two pairs of hotplates.
SPARE PARTS LIST

IS398 ECN3592
12
Catering equipment should be routinely serviced to ensure a long trouble free life. It is recommended
that this appliance is serviced every 6 months by a competent gas engineer.
For help regarding the installation, maintenance and use of your LINCAT equipment, please call:-
LINCAT GROUP SERVICE HELP DESK
[phone]
AUTHORISED SERVICE AGENTS
We recommend that all servicing other than routine cleaning is carried out by our authorised service
agents. We cannot accept responsibility for work carried out by other persons.
Please quote both the model and serial numbers from the data plate attached to the unit. Give brief
details of the service requirement.
If possible please quote the product code of the part number you require.
Work carried out under warranty will normally be undertaken only during normal working hours, i.e.
Monday to Friday, 8.30 a.m. - 5.30 p.m.
CONDITIONS OF GUARANTEE
The guarantee does not cover:-
1) Accidental breakage or damage
2) Operational misuse, wear and tear from normal usage, incorrect adjustment, or neglect.
3) Incorrect installation, maintenance, modification or unauthorised service work.
SERVICE INFORMATION
