Lincat Silverlink 600 Series Manual

IS476 ECN4597 1
User, Installation and Servicing Instructions
GR3 and GR7
Silverlink 600 Gas Salamander Grills

IS476 ECN4597
2
NOTE
Dear Customer,
Thank you for purchasing this Lincat product.
This is just one of over 450 different items of catering equipment available
which is constantly being extended and improved. Details are available from
your local distributor or direct from us.
Used for the purposes for which it is intended, and with careful maintenance
as outlined in this User Guide, your Lincat product will give you years of
trouble free service.
IMPORTANT INFORMATION
Please read all of the safety and operating instructions carefully before using this
product. Please pay particular attention to all sections of this User Guide that carry
warning symbols and notices.
WARNING!
This is a Warning symbol. This symbol is used throughout the user guide
whenever there is a risk of personal injury. Ensure that these warnings are
read and understood at all times.
CAUTION!
This is a Caution symbol. This symbol is used throughout the user guide whenever
there is a risk damaging your Lincat product. Ensure that these warnings are read
and understood at all times.
NOTE:
This is a Note symbol. This symbol is used throughout the user guide to provide additional
information, hints and tips.

IS476 ECN4597
3
CONTENTS
Contents Page
Customer Information………………………………………………………. 2
Warnings and Precautions………………………………………………… 3
Technical Data……………………………………………………………….. 4
Commissioning………………………………………………………………. 5
Check List of Enclosures………………………………………………….. 5
Installation…………………………………………………….……………… 6
User…………………………………………………………………………….. 7
Servicing ……………………………………………………………………… 9
Component Replacement ………………………………………….……… 10
Spare Parts List……………………………………………………………… 11
Fault Finding…………………………………………………………………. 11
Accessories…………………………………………………………………… 12
Service information………………………………………………………….. 13
Guarantee………………………………………………………….………….. 13
WARNINGS AND PRECAUTIONS
It is mandatory that all appliances are installed, commissioned and serviced by a
qualified and competent person as defined by the regulations in force in the country
of installation.
Failure to comply will invalidate the warranty.
WARNING!
This appliance must be installed by a competent installation engineer in accordance with the
installation instructions, and should conform to the following requirements:
Do not obstruct or block the appliance flue.
Installation must include sufficient ventilation to prevent the occurrence of unacceptable
concentrations of substances harmful to health in the room in which they are installed.
It is recommended that this appliance is sited under an extraction canopy for the removal of
combustion products
After operation, some parts of the appliance will remain hot for a period of time. Please take
care to avoid accidental burns.
CAUTION!
All equipment must be earthed to prevent shock.
Do not connect directly to any flue, ducting or mechanical extraction system.
Installation should allow for a sufficient flow of fresh air for gas combustion.
Parts which have been protected by the manufacturer or his agent must not be adjusted by
the installer or user.
The gas supply tubing or hose shall comply with the national requirements in force and shall
be periodically examined and replaced as necessary.
The appliance is designated Category 1 and is not intended for conversion from one gas type
to another.

IS476 ECN4597
4
TECHNICAL DATA
Model
GR3
GR7
Dimensions
Overall height (mm)
380
380
Width (mm)
600
750
Depth, excl. handles (mm)
365
365
Weight (kg)
22
33
Cooking Surface –w x d (mm)
415 x 230 (grill shelf)
590 x 320 (branding plate)
Heat Input - Gross
Natural Gas
5.0kW
6.5kW
Propane Gas
5.0kW
6.8kW
Butane Gas
5.0kW
6.8kW
Connection and Operating Pressures
Inlet connection
½” BSPT Male
Natural Gas
20mbar
20mbar
Propane Gas
37mbar
37mbar
Butane Gas
30mbar
30mbar
Gas Consumption
Gas Rate –Natural
0.48m3h-1
0.62m3h-1
Gas Rate –Propane
0.36kg h-1
0.49kg h-1
Gas Rate –Butane
0.36kg h-1
0.49kg h-1

IS476 ECN4597
5
NOTE
COMMISSIONING
PREPARATION
Remove all packaging and protective coatings prior to installation.
VENTILATION
The area in which this equipment is to be installed should have sufficient fixed ventilation to
comply with local legislation requirements. It is recommended that a room, or internal
space, be provided with a minimum free area of 4.5cm2per kW of total heat input.
CHECK LIST OF ENCLOSURES
Please ensure the following items are included with this piece of equipment:
Model
GR3
GR7
Tick
Warranty Card
1
1
Grill Pan
1
Toast Rack
1
Drip Tray
1
Wire Shelf
1
Branding Plate
1
Instruction Manual
1
1
SERIAL NUMBER
Each appliance manufactured at Lincat has a unique identifying number found in
the top right hand corner of the data plate attached at the rear of the appliance.
Please record that number in the space provided should it be required for future
reference.
Serial Number
MARK OF CONFIDENCE
Every single product that leaves our factory bears a serial plate showing the
assembler’s initials. It’s a mark of confidence we have in our people and our
manufacturing process.

IS476 ECN4597
6
NOTE
INSTALLATION
SITING
The installer must ensure that all regulations are met and that there is an
unobstructed minimum distance of 300mm from the top of the flue to the extraction
canopy, which must be of non-combustible material.
A combustion check should be carried out along with a check of flame stability. If
these are found to be compromised or unstable then the appliance must be
positioned lower.
Dirty extraction filters and drip trays may become a fire hazard due to a build up of
grease/fat and also drip down onto equipment below. Regular cleaning of extraction
filters and drip trays MUST be carried out and it’s the installer’s responsibility to
make the operator aware of this.
The appliance should be installed on a level surface ensuring the unit is stable and
firmly located.
Any partitions, walls or kitchen furniture in close proximity must be of non-
combustible materials and not be closer than 100mm from the sides and rear of the
flue.
There must be a minimum of 600mm clearance from the front of the appliance in
which to operate the appliance.
If the appliance is installed above or adjacent to a heat source the maximum
temperature surrounding the unit must be no greater than 80ºC. The installer will
need to use an insulated shelf and install heat shields to protect the unit as required.
GAS SUPPLY AND CONNECTION
Connection is at the rear of the unit via a R½ male thread.
Connection shall comply with local regulations.
The hose shall be periodically examined and replaced as necessary.
When making the connection to the appliance an isolating cock should be fitted into
the supply line close to the unit, for emergency shutdown or servicing purposes.
SUPPLY PRESSURES
The Salamander grills are un-governed appliances and connect directly to the
relevant gas supply. See above table for inlet pressures.
If necessary to gain access to the gas pressure test nipple remove the access panel
on the right hand side of the appliance. The nipple is situated fitted to the top of the
valve manifold.
Remove the blanking screw and attach a pressure gauge to the boss of the test
nipple and check inlet pressure.
For those destination countries where the supply pressure exceeds the supply
pressures given in the Technical Data above a regulator must be fitted and the
supply pressure set to the pressures detailed.
ACCESSORIES (see page 12)
A bench stand (GR3/BS, GR7/BS), wall shelf (GR3/WS, GR7/WS) and floor stand
(GR3/FS, GR7/FS) are optional accessories available for these units. Should an alternative
to these accessories be used, please ensure that the mounting is stable and of a non-
combustible material.

IS476 ECN4597
7
A branding plate and drip tray for the GR3 model are available as an accessory part
number APB03.
INSTRUCTION TO USER
Ensure that the person responsible understands how to light, safely operate, clean and
shutdown the appliance and is made aware of the position and operation of the gas
isolating cock in the event of an emergency.
USER INSTRUCTION
APPLIANCE USE
This appliance is only for professional use and should only be used by qualified personnel.
Ensure that the person responsible understands how to light, safely operate, clean and
shutdown the appliance and is made aware of the position and operation of the gas
isolating cock in the event of an emergency.
Ensure that all controls have free and easy movement, if not contact a qualified service
engineer.
This appliance is intended to be used for grilling or culinary preparations that cook or brown
by means of radiant heat and MUST NOT be used for any other purpose.
Operators of the appliance must not leave combustible materials directly in front of the
appliance when in use.
LIGHTING SEQUENCE
Open the main gas cock.
Push in the control knob then rotate anti-clockwise to the spark position as marked
on the control knob to allow gas through to the burner. Manually light the gas at the
burner face using a taper or piezo ignitor wand. Note: The appliance can only be lit
when the control knob is in this position.
On establishing a flame at the burner, keep the knob depressed for approximately
15 seconds then release. The burner should remain lit.
SHUT DOWN
To shut down the appliance rotate all control knobs clockwise to the OFF position. The gas
supply stopcock or bottle valve should now be closed.
USING THE APPLIANCE
The appliance can be used with or without the branding grid.
The toast rack is heavy and it is not recommended to remove the rack during
service with product or trays placed on the rack.
It is advisable that product to be toasted be placed on a suitable tray which is then
placed on the rack whilst in a flat position.
If using to gratinate the rack needs to be positioned flat and at a height that best suits the
application. Additional temperature control can be obtained from the setting of the control
knob.
The branding grid is very heavy and is placed onto the toast rack.
The locating holes in the branding plate align with the locating pins on the toast
rack.
Do not attempt to reposition the height of the branding plate and rack when the
appliance is hot.

IS476 ECN4597
8
For grilling, the best results are obtained with the branding plate in an angled position to
allow for drainage of fats and juices to be collected in the debris tray.
When grilling the product should be handled with suitable tongs.
The use of branding plates requires pre-heating to obtain successful results. It is suggested
the branding plate is pre-heated for at least 15 minutes.
Loading of product to be cooked on the shelves or branding plate must not exceed the
point where the product cannot be safely manipulated during the cooking process.
Parts of the toast rack, branding grid, debris tray and crumb tray can become
very hot during service. Care must be taken to avoid injury.
Grilling
Any food product to be cooked on the branding plate must be placed directly with the aid of
suitable tongs to prevent injury from burns. Cooked food must be removed with tongs whilst
the appliance is in operation.
If the appliance is to be left unattended for long periods, then the appliance burner should
be reduced to the lowest position or turned off.
Do not place any container, plate or anything else on top of the appliance hood as this may
cause an obstruction to the flue gasses.
DO not place any combustible material on the top of the appliance hood.
CLEANING
Ensure the appliance is cool and the gas supply is isolated before commencing cleaning.
After use wash the unit down with a warm detergent solution.
All users should be aware of the importance of maintaining a clean oven cavity and
grill pans and or drip trays in order to prevent a possible fire hazard.
Do not use abrasives on stainless steel or enamelled parts.
Do not use any products containing chlorine or hydrochloric acid to clean stainless
steel surfaces.
Do not clean the appliance using a water jet.
ROUTINE CLEANING
It is important that users of the appliance shall systematically check and clean down
as necessary areas of the grill that have accumulated oils, fats and other
combustible debris from previuos cooking.
This is to prevent the potential risk of fire.
Cleaning of the appliance and its parts must be done when the appliance is cold and
before the start of service.
Areas to check
Branding plate –Regulary remove any debris build up on brander grid.
Debris collecting tray –The trays will need to be emptied and cleaned before use of
debris, oils and fats that may have accumulated from previos cooking.
Failure to routinely clean debris from trays may lead to a risk of fire.
It may be necessary to empty frequently during heavy usage of the appliance.
The tray is likely to be hot and should be handled with care and with heat resistant gloves.
Cooking compartment –When the appliance has cooled remove the toast rack, branding
plate and crumb tray. Clean the cavity as necessary of any build up of debris, oils and fats.
Note –Do not allow the branding grid tray to fill as handling will become difficult and
spillage likely to occur.

IS476 ECN4597
9
BRANDING GRID
TRAY
CRUMB/DEBRIS
TRAY
SERVICING
Visual Inspection shall determine that:-
Branding plate is kept clean and excessive carbon build up has been removed.
Debris collection tray is in an acceptable clean condition.
Crumb tray is kept clean.
Toast rack is kept clean.
Flexible gas supply hose (where fitted) is of sound condition and safety restraint
chain/cable is attached.
Gas tap functions correctly in terms of lighting burner.
Spindle of gas tap shows no evidence of sticking and has a smooth operation.
Top of the appliance is free from obstructions.
SERVICE ACCESS
General Access
Remove the two screws at the rear of the hood ‘A'.
Slide the hood forward to free the hood from the key-hole slots in the side panels.
Access to the test nipple can be made from the top of the appliance.
Remove the side panel ‘B’ retaining screws for access to the valve and other
components.
1 OF 1
A
B
Valve Servicing - Recommended every 6 months
Remove the control knob

IS476 ECN4597
10
From the front of the appliance carefully remove the two screws securing the niting
cap on the valve body.
Withdraw the spindle from the valve and grease as necessary.
Reassemble parts in reverse order.
Perform soundness check for leaks.
Thermocouple Servicing - Recommended every 6 months
Check millivolt output and replace thermocouple if required.
Check thermocouple is secure in its bracket and tighten if required.
COMPONENT REPLACEMENT
Access to gas circuit components can be made when the hood and side panel are removed
as described earlier.
Burner
Remove the six burner retaining screws (not shown) and lift the burner Zfrom the
support bracket.
Fit the new burner.
1 OF 1
Z
R
P
ST
O
N
M
V
W
X
Y
U
Q
L
K
Injector
The burner injector Ycan be removed separately using a ¼" AF spanner.
Replace the copper washer (CO113) and fibre washer (WA08) when fitting a new
injector.
Thermocouple
Loosen the thermocouple lock nut Nat the valve body O.
From inside the cooking compartment remove the two screws Ksecuring the fixing
bracket L.
Withdraw the thermocouple capillary Uthrough the body (noting its position).
Fit new thermocouple and re-assemble components.

IS476 ECN4597
11
Is the isolator open ?
No
Check operating pressure
Loose
Open and retry
Correct
Yes
Check thermocouple connection at valve
Tighten and retry
Tight
Check thermocouple voltage
15mV or above
Check burner injector
Change and retry
Less than 15mV
Fit correct jet and retry
Clear and retry
Blocked
Incorrect
Valve
Loosen the burner feed pipe nut Tand the thermocouple lock nut N.
Remove the control knob Rfrom the valve spindle.
Loosen the valve clamp screws from the manifold.
Free the valve from the pipe work and manifold.
Remove the burner feed compression fitting from the valve and fit to the new valve
with a suitable thread sealant (Loctite 577 recommended).
Description
GR3
Part number
GR7
Part number
Branding Plate
BR25
BR39
Main Burner
BU23
BU142
Burner injector - Natural
JE40
JE52
Burner injector –Butane/Propane
JE04
JE15
Copper Washer (Burner injector)
CO113
Fibre Washer (Burner Injector)
WA08
Gas Valve
VA11
Thermocouple Split Nut
TC07
Thermocouple
TC03
Grill Shelf
SH89
SH90
Base Drip Tray (option on GR3)
SA399
SA389
Control Knob
KN188
Burner
will
not
light
or stay
lit
SPARE PARTS LIST
FAULT FINDING

IS476 ECN4597
12
WALL SHELF
GR3/WS
GR7/WS
FLOOR STAND
GR3/FS
GR7-FS
ACCESSORIES

IS476 ECN4597
13
BENCH STAND
GR3/BS
GR7/BS
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning MUST be carried out by qualified
personnel and a record kept of any remedial actions taken and at least cover the
requirements of the service schedule of this document. We cannot accept
responsibility for work carried out by other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
DECLARATION
All Lincat products capable of burning gaseous fuels, satisfy the requirements of the
Gas Appliance Regulations 2016/426.
GUARANTEE
This unit carries a comprehensive UK mainland warranty. The guarantee is in
addition to, and does not diminish your statutory or legal rights. Contact Lincat for
terms and conditions
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
SERVICE INFORMATION

IS476 ECN4597
14
Consumable items (such as filters, glass, bulbs, slot toaster elements and
door seals.)
Damage due to incorrect installation, modification, unauthorised service work
or damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
personnel to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for within
the warranty. Any requirement for staff attending the call to spend greater time than 15
minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
