Lincat OD7006 User guide

IS433 ECN3503 1
OD7006 & OD7007
Dual Fuel Oven Ranges
USER, INSTALLATION, SERVICING AND
CONVERSION INSTRUCTIONS
For use in GB & IE

IS433 ECN3503
2
Dear Customer,
Thank you for purchasing this Lincat product.
This is just one of over 300 different items of catering equipment available
which is constantly being extended and improved. Details are available from
your local distributor or direct from us.
Used for the purposes for which it is intended, and with careful maintenance
as outlined in this User Guide, your Lincat product will give you years of
trouble free service.
IMPORTANT INFORMATION
Please read all of the safety and operating instructions carefully before using this
product. Please pay particular attention to all sections of this User Guide that carry
warning symbols and notices.
WARNING!
This is a Warning symbol. This symbol is used throughout the user guide
whenever there is a risk of personal injury. Ensure that these warnings are
read and understood at all times.
CAUTION!
This is a Caution symbol. This symbol is used throughout the user guide whenever
there is a risk damaging your Lincat product. Ensure that these warnings are read
and understood at all times. 
NOTE:
This is a Note symbol. This symbol is used throughout the user guide to provide additional
information, hints and tips.

IS433 ECN3503
3
CONTENTS
Contents Page
Customer Information………………………………………………………. 2
Warnings and Precautions………………………………………………… 4
Technical Data……………………………………………………………….. 5
Commissioning………………………………………………………………. 6
Check List of Enclosures…………………………………………………... 6
Installation…………………………………………………….……………… 7
Conversion of Gas Types………………………………………………….. 8-9
User…………………………………………………………………………….. 10-11
Servicing ……………………………………………………………………… 12
Component Replacement ………………………………………….……… 12-14
Spare Parts List……………………………………………………………… 15
Fault Finding…………………………………………………………………. 16
Wiring Diagrams…………………………………………………………….. 17
Service information………………………………………………………….. 18
Guarantee………………………………………………………….………….. 18

IS433 ECN3503
4
WARNINGS AND PRECAUTIONS
It is mandatory that all appliances are installed, commissioned and serviced by a qualified and
competent person as defined by the regulations in force in the country of installation.
Failure to comply will invalidate the warranty.
WARNING!
This appliance must be installed by a competent installation engineer in accordance with
the installation instructions, and should conform to the following requirements:
•Gas Safety (Installation & Use)(Amendment) Regulations
•BS 5440: Flues, Air Supply for gas appliances of input not exceeding 70kW
•Institution of Gas Engineers Publications:IGE/UP/1, IGE/UP/2 and IG/UP/4
•BS 6173: Code of Practice for Installation of Gas Catering Appliances
•Local and National Building Regulations
•Fire Precautions Act
•Health & Safety At Work etc Act
•BS EN60335-1 Safety of Household and Similar Electrical Appliances
•BS EN 60335-2-42 Particular Requirements for Commercial Electric Forced
Convection Ovens, Steam Cookers and Steam-Convection Ovens
Do not obstruct or block the appliance flue.
Installation must include sufficient ventilation to prevent the occurrence of
unacceptable concentrations of substances harmful to health in the room in which they
are installed.
It is recommended that this appliance is sited under an extraction canopy for the
removal of combustion products
After operation, some parts of the appliance will remain hot for a period of time. Please
take care to avoid accidental burns.
CAUTION!
All equipment must be earthed to prevent shock.
Do not connect directly to any flue, ducting or mechanical extraction system.
Installation should allow for a sufficient flow of fresh air for gas combustion.
Parts which have been protected by the manufacturer or his agent must not be adjusted
by the installer or user.
A means of disconnection must be incorporated in the fixed wiring having a contact
separation of at least 3.0mm in all poles.
Supply cords shall be oil-resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent synthetic elastomer-sheathed cord (code designation 30245
IEC 57)
Connection of the electrical supply cable is made at the rear of the unit. Remove the
protective cover and fit a suitable cable into the strain relief and then to the inlet terminal
block. The unit is supplied for connection to a three-phase supply. Connections are
provided to allow termination of all three-phase cables, although only two are used to
power the unit. If the unit is to be fed from a single-phase then the two supply terminals
will need to be connected together using a wire link.

IS433 ECN3503
5
TECHNICAL DATA
Model OD7006 OD7007
Dimensions
Overall Height (mm)
950 950
Width (mm)
600 900
Depth (mm)
750 750
Weight (kg)
85 113
Hob Cooking Surface w x d (mm)
600 x 600 900 x 600
Usable Oven Capacity w x d x h (mm)
500 x 540 x 400 715 x 540 x 400
Oven Shelf Size (mm) w x d
480 x 530 770 x 530
Heat Input
Total Heat Input Natural (Gross)
24.4 kW 36.6 kW
Total Heat Input Propane (Gross)
22.8 kW 34.2 kW
Hob Rating, per Burner Natural (Gross)
6.1 kW
Hob Rating, per Burner Propane (Gross)
5.7 kW
Hob Low Rating, per Burner Natural
1.4 kW
Hob Low Rating, per Burner Propane
1.2 kW
Connection and Operating Pressures
Gas Inlet Connection
1/2” BSP Female 3/4” BSP Female
Supply Pressure - Natural
20mbar
Operating Pressure - Natural
20mbar
Supply Pressure - Propane
37mbar
Operating Pressure - Propane
37mbar
Gas Consumption
Total Gas Rate – Natural
2.32 m
3
h
-1
3.48 m
3
h
-1
Total Gas Rate – Propane
1.64 kg h
-1
2.46 kg h
-1
Hob Burner Gas Rate - Natural
0.58 m
3
h
-1
Hob Burner Gas Rate - Propane
0.41 kg h
-1
Electrical
Total Power Rating @230V single phase
4.032 kW 6.06 kW
Phase
1
2.032
kW
Phase
1
2.064
kW
Phase
2 2.0 kW Phase 2 2.0 kW
Total Power Rating @ 400V three phase
Phase
3 N/A Phase 3 2.0 kW

IS433 ECN3503
6
NOTE
COMMISSIONING
PREPARATION
Remove all packaging and protective coatings prior to installation.
Check that the burner caps have been fitted correctly to the burner body and the Pan Supports are
located.
VENTILATION
The area in which this equipment is to be installed should have sufficient fixed ventilation to comply
with local legislation requirements. It is recommended that a room, or internal space, be provided
with a minimum free area of 4.5cm
2
per kW (3,400Btu/hr) of total heat input.
OD7007 OD7006
CHECK LIST OF ENCLOSURES
Please ensure the following items are included with this piece of equipment:
Model OD7006 OD7007 Tick
Wire Shelf 3 3
Ignitor Wand 1 1
Pan Supports 2 3
Warranty Card 1 1
User Instructions 1 1
SERIAL NUMBER
Each appliance manufactured at Lincat has a unique identifying number found in the top
right hand corner of the data plate attached at the rear of the appliance. Please record that
number in the space provided should it be required for future reference.
Serial Number
MARK OF CONFIDENCE

IS433 ECN3503
7
Every singe product that leaves our factory bears a serial plate showing the assembler’s
initials. It’s a mark of confidence we have in our people and our manufacturing
process.
INSTALLATION
SITING
The installer must ensure that all regulations are met and that there is an unobstructed minimum
distance of 1000mm from the top of the flue to the ceiling, which must be of non-combustible
material.
The appliance should be installed on a level surface ensuring the unit is stable and firmly located.
Any partitions, walls or kitchen furniture in close proximity must be of non-combustible materials
and not be closer than 50mm from the sides and rear of the flue.
GAS SUPPLY AND CONNECTION
The gas inlet connection is at the rear of the appliance. The pipe work should be of adequate size but
not smaller than the gas inlet connection at the rear of the appliance, i.e. Rp ½” BSP (OD7006) &
Rp ¾” BSP (OD7007).
All joints made must be leak free.
Final gas connection to the appliance and gas supply shall comply with local regulations.
When making the connection to the appliance an isolating cock should be fitted into the supply line
close to the unit, for emergency shutdown or servicing purposes.
SUPPLY PRESSURES
The appliance is connected directly to the gas supply where the gas supply pressure is controlled at
the source of inlet in the building or via the governor attached to the bottle gases. See Technical Data
for the supply pressures.
•To gain access to the gas pressure test nipple the fascia panel requires removal. The test
nipple is situated in the centre of the manifold rail.
•Remove the blanking screw and attach a pressure gauge to the boss of the test nipple.
•Light the oven burner and set thermostat to the highest setting and check the pressure.
ELECTRICAL SUPPLY AND CONNECTION
Connection of the electrical supply cable is made at the rear of the unit. Remove the protective cover
and fit a suitable cable into the strain relief and then to the inlet terminal block. The unit is supplied
for connection to a three-phase supply. Connections are provided to allow termination of all three-
phase cables, although only two are used to power the unit. If the unit is to be fed from a single-
phase then the two supply terminals will need to be connected together using a wire link
LOCKING OF WHEELS
When the appliance has been installed in its intended position the front castors should be
locked by depressing the locking tabs on the castors.
Locks should only be released for the intention of moving the appliance for cleaning
purposes and or routine servicing of the appliance.

IS433 ECN3503
8
CONVERSION OF GAS TYPES
Conversion of Gas Type – Injector Changes
Model Gas Inlet Pressure Injector ∅
∅∅
∅Mark Part No.
GG 1.90 190 JE252 x 4
OD7006 G20 20 mbar C N/A 76 JE216 x 4
GG 1.90 190 JE252 x 6
OD7007 G20 20 mbar C N/A 76 JE216 x 6
GG 1.20 120 JE253 x 4
OD7006 G31 37 mbar C N/A 50 JE217 x 4
GG 1.20 120 JE253 x 6
OD7007 G31 37 mbar C N/A 50 JE217 x 6
Fascia Panel Removal
AA
FF
BB
CC
DD
EE C
GG
LL
MM

IS433 ECN3503
9
B
A
C
D
FF
HH
GG
KK
•Remove the three pan supports AA, together with the control knobs CC.
•Remove the fascia panel BB fixing screws EE from the underside of the panel.
Hob Valve Bypass Injectors
•Remove the bypass injectors C from each of
the hob burner control valves B.
•Replace the bypass injectors applicable to the
required gas type. Screw fully home but do
not over tighten.
Hob Burner Injectors
•Remove pan supports.
•Lift off the burner cap FF together with the burner base HH.
•Remove injector GG and fit replacement applicable to the required gas type.
•Replace burner base and cap.
•Repeat the procedure for remaining hob burners.
Hob Burner Components
Part Description
FF Burner Cap
GG Injector
HH Burner Base
KK Injector Holder
Completion of Conversion
•Remove the redundant data plate and gas type identification label and attach new
replacements corresponding to new gas type.
Hob Tap Components
Part Description
A Manifold
B Gas tap
C Bypass injector
D Clamp screw

IS433 ECN3503
10
•Test all previously dismantled joints for soundness.
•Functionally operate the appliance to the new operating pressure as detailed in page 7.
USER INSTRUCTION
APPLIANCE USE
This appliance is only for professional use and should only be used by qualified personnel.
Ensure that the person responsible understands how to light, safely operate, clean and shut down the
appliance and is made aware of the position and operation of the gas isolating cock in the event of an
emergency. All users should know how to clean burner caps and to correctly locate the burner cap on
the burner body.
LIGHTING SEQUENCE – HOB BURNER
Ensure that all the burner caps and pan supports are in the correct positions.
MAINS POWER ON
OVEN THERMOSTAT
CONTROL KNOB
OVEN ELEMENT
POWER ON
HOB INDICATOR ON / OFF INDICATOR
LH REAR BURNER
LH FRONT BURNER
MIDDLE REAR BURNER
MIDDLE FRONT BURNER
RH REAR BURNER
RH FRONT BURNER
PAN SUPPORTS
•Open the main gas cock.
•Push in the control knob then rotate anti-clockwise to any position to allow gas through to the
burner. Manually light this burner using a taper or piezo ignitor wand.
•On establishing a flame at the burner, keep the knob depressed for approximately 15 seconds
then release. The burner should remain lit.
OVEN SETTING
•Check the green ‘power on’ neon on the control panel is illuminated.
•Set the control knob to the desired temperature in degrees Celsius. The orange light will
illuminate indicating that power is being supplied to the elements.
•The orange light will go out when the oven has achieved the set temperature. Periodically the
orange light will illuminate to indicate that the oven temperature has fallen and the
elements are turned on to top up the temperature.
SHUT DOWN
To shut down the appliance rotate all control knobs clockwise to the OFF position. The gas supply
stopcock or bottle valve should now be closed.

IS433 ECN3503
11
After operation, some parts of the appliance will remain hot for a period of time; care should
be taken to avoid risk of burns.
CLEANING
Ensure the appliance is cool and the gas supply is isolated before commencing cleaning.
After use wash the unit down with a warm detergent solution.
Frequently check the burner cap ports for blockages. Clear as necessary.
Do not use abrasives on stainless steel or enamelled parts.
Do not use any products containing chlorine or hydrochloric acid to clean stainless steel
surfaces.
Do not clean the appliance using a water jet.
To remove shelf supports, lift shelf support up and out to disengage from retaining screws.
POTS AND PANS
The minimum recommended pan size should have a base diameter not less than 150mm.
The maximum recommended pan size per burner should not exceed a base diameter of 360mm.
Under no circumstances should multiple burners be covered by a single pan or
container.
OPENING OF THE OVEN DOOR
Care must be taken to avoid injury when opening the oven door, when the oven is in use as hot air
will rapidly escape.
Tilt shelf up at rear and pull to disengage

IS433 ECN3503
12
SERVICING
SERVICE ACCESS
To access and service the gas control valves
•Remove the control knobs and fascia panel to gain access to the valves.
•Remove the two screws securing the valve boss and carefully withdraw the spindle
from the valve.
•Grease as necessary and refit parts. Carry out gas soundness check.
FASCIA PANEL REMOVAL
See page 8 for details
OPERATIONAL CHECK
Commissioning must include an operational check of all controls.
•Check that each burner can be lit at both full rate and low rate.
•Check that each burner will remain lit when turned to low rate.
•Set the Oven thermostat at its lowest setting and check that on the oven attaining the set
temperature the amber light goes out.

IS433 ECN3503
13
COMPONENT REPLACEMENT
Access to Hob components can be more easily gained by removal of the the hob top (as shown
below) rather than removing the fascia.
HOB TOP
ACCESS PANEL
FASCIA
CONTROL KNOB HOOK HOB OVER
FASCIA BEFORE
FASTENING AT
REAR
HOB TOP
FIXING SCREWS
FASCIA FIXING
SCREWS
Hob Thermocouple
•Remove the pan supports, burner caps, rear access panel and hob top as shown above.
•Remove the thermocouple lock nut at the hob top.
•Remove thermocouple nut from valve body B.
•Withdraw the thermocouple.
•Fit the new thermocouple and re-assemble in the reverse order.
Hob Valve
•Remove the control knobs, pan supports, rear access panel and hob top as shown above.
•Remove the nut from the gas output at the valve.
•Remove the thermocouple nut from the valve.
•Remove clamp screws D from the valve.
•Free the valve from the manifold A.
•Fit the new valve and re-assemble reverse order.
•Perform gas soundness test of circuit prior to operation of appliance.
Hob Burner
•Remove the pan supports, rear access panel and hob top as shown above.
•Remove the burner cap FF and base HH.
•Remove the burner body retaining screws.

IS433 ECN3503
14
•Fit the new burner body and re-assemble parts.
Oven Fans
•Ensure that the gas supply to this unit is turned off and the electrical supply is disconnected.
•Remove the oven shelves.
•Loosen the fan guard screws and lift off the keyhole slots.
•Remove the hex head nut from the centre of the fan, this is a left-hand thread, and remove the
fan blade.
•Working from the back of the unit, remove the rear cover panel.
•Remove the electrical connections from the relevant motor.
•Remove the three securing screws and extract the motor unit.
•Refitting is the reversal of removal.
•Check the unit for electrical safety.
Contactor
•Ensure that the gas supply to this unit is turned off and the electrical supply is disconnected.
•Working from the back of the unit, remove the rear cover.
•Remove the electrical connections from the contactor.
•Release the clip from the base of the contactor.
•Refitting is the reversal of removal.
•Check the unit for electrical safety.
Over Temperature Cut-Out Thermostat
•Ensure that the gas supply to this unit is turned off and the electrical supply is disconnected.
•Remove the thermostat bulb from the top of the oven.
•Working from the back of the unit, remove the rear cover panel.
•Remove the electrical connections from the thermostat housing.
•Remove the front control panel.
•Pull the thermostat bulb through the oven back.
•Remove the two securing screws and remove the thermostat unit.
•Refitting is the reversal of removal.
•Check the unit for electrical safety.
Control Thermostat
•Ensure that the gas supply to this unit is turned off and the electrical supply is disconnected.
•Remove the thermostat bulb from the top of the oven.
•Remove the control knobs from the front of the unit.
•Remove the two screws holding the control thermostat to the control panel.
•Remove the control panel as detailed previously.
•Remove the electrical connections from the thermostat housing.
•Remove the thermostat and capillary from the unit.
•Refitting is the reversal of removal.
•Check the unit for electrical safety.

IS433 ECN3503
15
Part Number Part Description Used On
BU55 Door Bushes All models
BU224 Burner Base All models
BU225 Burner Injector Holder All models
BU226 Burner Cap All models
CO113 Copper Washer All models
CA143 125mm Braked Swivel Castors All models
CA145 125mm Un-Braked Swivel Castors All models
CO214 Contactor All models
DO73 Door Catch Assembly All models
EL149 Element – 4kW OD7006
EL248 Element – 3kW OD7007
FA12 LHS Fan/Motor Assembly OD7007
FA102 RHS Fan/Motor Assembly All models
HA77 Door Handle All models
JE252 Hob Burner Injector – Natural All models
JE253 Hob Burner Injector – Propane All models
JE216 Hob Valve Low Rate Jet - Natural All models
JE217 Hob Valve Low Rate Jet – Propane All models
KN228 Control Knob – Oven Thermostat All models
KN256 Control Knob – Hob Burners All models
LE37 Adjustable Leg - 150mm All models
NE39 Green Neon All models
NE40 Amber Neon All models
PA122 Cast Pan Supports All models
SE25 Door Seal All models
SH112 Oven Shelf OD7006
SH81 Oven Shelf OD7007
SP56 Leg Spanner All models
SR07 Side Rack All models
SW58 Fan Switch All models
TC34 Thermocouple 750mm All models
TH46 Thermostat All models
TH63 Safety Cut-Out Thermostat All models
VA65 Hob Burner Valve All models
WA08 Fibre Washer All models
SPARE PARTS LIST

IS433 ECN3503
16
Is there gas at the burner?Yes No
Are thermocouple connections loose?
Is the thermocouple voltage less than 15mV?
Is the valve damaged?
Check injector for blockages
Tighten connections
Replace valve
Yes
Yes
Yes
No
No
No
Replace thermocouple
Recheck system
• Burner/s will not light or stay lit .
•Oven not heating.
FAULT FINDING
Is green neon lit?
Yes No
Check incoming
supply is connected
and switched
correctly
Are the fans operating
when the oven control
switch is turned on?
Yes No
Check the over
temperature cutout
re-set switch at the
rear of the appliance
Faulty switch or
wiring fault.

IS433 ECN3503
17
OD7006 Wiring (E356)
L1
L2
L3
N
1
2
3
4
5
6
7
8
9
13
14
16
18
TE14
CO214
SW58
TH46
NE39
GREEN
NE40
AMBER
TH63
EL149
FA12
TO CHASSIS
23
21
B
B
B
B
B
B
BB
B
B
B
B
B
B
B
USE OUTER PAIRS OF
TERMINALS ONLY NO
CONNECTIONS TO INNER
PAIR OF CONTACTS
B
NO NO
L1 L3 L1 L2
T1 T2 T3
20
10
11
15
22
A1
NO
A2
19 24
12
OD7007 Wiring (E329)
L1 L2 L3
TE55
EARTH TAG
TE47
TERMINAL BLOCK
TH63
SAFETY THERMOSTAT
CO214
CONTACTOR
NE39
GREEN
NEON
NE40
AMBER
NEON
SW58
FAN
SWITCH
TH46
OVEN
THERMOSTAT
EL248
ELEMENT
EL248
ELEMENT
FA12 FAN FA12 FAN
29
28
26
27
B B
Connect to
inner
bulkhead
via
heat
deflector
screw
1
2
3
4
5
6
789
10
11
12
13
14
15
16
17
18
19
N
20
21
22
23
24 25
30
31
32
W
I
R
E
S
W
I
T
H
A
#
T
O
B
E
S
T
R
I
P
P
E
D
1
0
M
M
Connect
to fascia

IS433 ECN3503
18
Gas catering equipment should be routinely serviced to ensure a long trouble free life. It is
recommended that this appliance is serviced every 6 months by a competent gas engineer.
For help regarding the installation, maintenance and use of your LINCAT equipment, please call:-
LINCAT GROUP SERVICE HELP DESK
[phone]
AUTHORISED SERVICE AGENTS
We recommend that all servicing other than our authorised service agents carry out routine cleaning.
We cannot accept responsibility for work carried out by other persons.
Please quote both the model and serial numbers from the data plate attached to the unit. Give brief
details of the service requirement.
If possible please quote the product code of the part number you require.
Work carried out under warranty will normally be undertaken only during normal working hours, i.e.
Monday to Friday, 8.30 a.m. - 5.30 p.m.
CONDITIONS OF GUARANTEE
The guarantee does not cover:-
1) Accidental breakage or damage
2) Operational misuse, wear and tear from normal usage, incorrect adjustment, or neglect.
SERVICE INFORMATION

IS433 ECN3503
19
3) Incorrect installation, maintenance, modification or unauthorised service work.
