MASTERPIPE®Mini Profiler
Installation and Operations Guide
February 11, 2014
Copyright 2013-2014
by Vernon Tool Company

ii MASTERPIPE®Mini Proler
Published by:
Lincoln Electric Cutting Systems
Torchmate Distribution Center
1170 Trademark Drive, #101
Reno, NV 89521
www.torchmate.com
Copyright © 2013-2014 by Vernon Tool Company
All rights reserved.
Reproduction of this work, in whole or in part, without written permission of the publisher is prohibited.
The publisher does not assume and hereby disclaims any liability to any party for any loss or damage
caused by any error or omission in this manual, whether such error results from negligence, accident,
or any other cause.
Publication Date: February 11, 2014
Document 2014MPMP1

iii
Installation and Operations Guide
MASTERPIPE®Mini Proler
(MPMP)
Base machine and single add-on section
cutting 8” I.D. pipe

iv MASTERPIPE®Mini Proler
Table of contents
Statement of warranty . . . . . . . . . . . . . . . . . . . . . vi
Welcome to Torchmate . . . . . . . . . . . . . . . . . . . . . viii
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . 11
Parts and assemblies checklist . . . . . . . . . . . . . . . . 12
Feature overview . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation overview . . . . . . . . . . . . . . . . . . . . . . 18
Step 1: Locate and place the base machine . . . . . . . . . . 20
Step 2: Attach (optional) add-on sections . . . . . . . . . . . 21
Step 3: Install the rails . . . . . . . . . . . . . . . . . . . . . 22
Step 4: Attach cable trays . . . . . . . . . . . . . . . . . . . 23
Step 5: Level the section(s). . . . . . . . . . . . . . . . . . . 24
Step 6: Align the sections . . . . . . . . . . . . . . . . . . . 25
Step 7: Align any add-on section gear racks. . . . . . . . . . 26
Step 8: Install the horizontal drive unit . . . . . . . . . . . . . 27
Step 9: Add hard stops. . . . . . . . . . . . . . . . . . . . . 28
Step 10: Install (optional) AVHC torch mount . . . . . . . . . 29
Step 11: Install (optional) oxy-fuel torch mount . . . . . . . . 30
Step 12: Install (optional) oxy-fuel relay . . . . . . . . . . . . 31
Step 13: Install cradles and catch trays . . . . . . . . . . . . 32
Step 14: Install (optional) small pipe cradles . . . . . . . . . . 33
Step 15: Route cables through cable carrier . . . . . . . . . . 34
Step 16: Connect motor cable to chuck motor . . . . . . . . 35
Step 17: Connect air lines . . . . . . . . . . . . . . . . . . . 36
Step 18: Connect motor cables to CNC Controller . . . . . . 37
Step 19: Connect CNC cable to CNC Controller. . . . . . . . 38
Step 20: Connect CNC cable to AVHC (optional) . . . . . . . 39
Step 21: Connect computer to CNC Controller . . . . . . . . 40
Step 22: Install TM4 Driver software . . . . . . . . . . . . . . 41
Step 23: Load conguration le . . . . . . . . . . . . . . . . 42
Step 24: Test motor jogging . . . . . . . . . . . . . . . . . . 43
Step 25: Set the pipe diameter. . . . . . . . . . . . . . . . . 44

v
Installation and Operations Guide
Step 26: Load material for speed and demo cuts . . . . . . . 45
Step 27: Load the speed test cut le. . . . . . . . . . . . . . 46
Step 28: Adjust torch position for speed test cut . . . . . . . 47
Step 29: Set the pierce delay. . . . . . . . . . . . . . . . . . 48
Step 30: Cut the speed test . . . . . . . . . . . . . . . . . . 49
Step 31: Analyze the speed test . . . . . . . . . . . . . . . . 50
Step 32: Load the demo cut le . . . . . . . . . . . . . . . . 51
Step 32: Set the demo cut speed in G-code. . . . . . . . . . 52
Step 33: Cut and analyze the demo cut . . . . . . . . . . . . 53
Driver Introduction . . . . . . . . . . . . . . . . . . . . . . . 55
Installing the Driver software . . . . . . . . . . . . . . . . . . 56
Manually installing the device drivers (if necessary) . . . . 58
Congure the computer’s power saving feature . . . . . . . . 60
Driver software conguration setup les . . . . . . . . . . . . 62
Driver software panels . . . . . . . . . . . . . . . . . . . . . 64
Control panel descriptions . . . . . . . . . . . . . . . . . 66
Coordinates (DRO) panel. . . . . . . . . . . . . . . . . . 68
Connection status . . . . . . . . . . . . . . . . . . . . . 70
G-code panel. . . . . . . . . . . . . . . . . . . . . . . . 72
Viewport panel . . . . . . . . . . . . . . . . . . . . . . . 74
Output panel . . . . . . . . . . . . . . . . . . . . . . . . 76
Driver software basic operations . . . . . . . . . . . . . . . . 78
Jog motion testing . . . . . . . . . . . . . . . . . . . . . 80
Output line testing . . . . . . . . . . . . . . . . . . . . . 82
Test Cutting - Manual Height Control Plasma . . . . . . . 84
Test Cutting - Router . . . . . . . . . . . . . . . . . . . . 86
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Replacement parts . . . . . . . . . . . . . . . . . . . . . . . 90
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 93
Troubleshooting the plasma process. . . . . . . . . . . . . . 94
Troubleshooting the alignment . . . . . . . . . . . . . . . . . 96
Technical Support . . . . . . . . . . . . . . . . . . . . . . . 98

vi MASTERPIPE®Mini Proler
If Buyer is not satised with the performance of the Goods within 30 days from
the date the Goods were shipped from the Seller, Buyer may return the Goods
in the original carton(s) for a full refund less Shipping, Handling, Damages and
Freight Charges. All sales become nal after this 30 day period. Buyer should
determine the satisfactory performance of the Goods by using the software, and
inspecting and bench running the motors and/or accessory items. Any items
to be returned for full refund must be in new, unused (except for bench testing),
and saleable condition at the sole determination of the Seller. Items that, in the
Seller’s judgment, have been used or modied in any way, or kits that have been
partially or fully completed will be subject to a restocking fee to be determined
by the Seller. A return merchandise authorization number (RMA) must be
obtained by the customer prior to any return. Shipments of returned items not
marked with a valid RMA will be refused.
Electronics and motors are warranted by their manufacturer to the original
purchaser for 12 months from the date of Torchmate, Inc.’s sale invoice.
Mechanical components are standard industrial parts and are not warranted
except by their respective manufacturers. If any of the warranted items are
found by Seller to be defective, such Goods will, at Seller’s option, be replaced
or repaired at Seller’s cost. No defective goods are to be returned without
written authorization of seller. The sole purpose of the stipulated exclusive
remedy shall be to provide the Buyer with free repair and replacement of
defective Goods in the manner provided herein. This exclusive remedy shall
not be deemed to have failed of its essential purpose so long as the Seller is
willing and able to repair or replace defective Goods in the prescribed manner.
The foregoing warranty is in lieu of all other warranties, express or implied,
including those of merchantability or tness for any purpose not expressly set
forth herein. No afrmation of Seller, by words or action, other than as set forth
in this Section shall constitute a warranty. Seller’s warranty does not apply to
any Goods which have been subjected to misuse, mishandling, misapplication,
neglect (including but not limited to improper maintenance), accident, improper
installation, modication (including by not limited to use of unauthorized parts or
attachments), or adjustment or repair performed by anyone other than Seller or
one of Seller’s authorized agents. When returning products to Seller packaging
must be adequate or all warranty is null and void. Buyer will pay for the cost of
Shipping to and from the Seller for all warranty repairs.
Statement of warranty
30 Day guarantee
Warranty
Before returning any goods, please contact
Lincoln Electric Cutting Systems Technical Support.
Call Monday through Friday from 6:30 AM to 4:00 PM Pacic Time.
Toll Free: 1-866-571-1066 x3
International: 775-673-2200 x3
Fax: [phone]
Email: [email protected]

vii
Installation and Operations Guide
Any claim by Buyer with reference to the Goods sold hereunder shall be deemed
waived by the Buyer unless submitted in writing to seller within the earlier of (i)
thirty (30) days following the date Buyer discovered or by reasonable inspection
should have discovered, any claimed breach of foregoing warranty, or (ii) 12
months following the date of shipment. Any cause of action for breach of the
foregoing warranty shall be brought within one year from the date the alleged
breach was discovered or should have been discovered, whichever occurs rst.
Seller’s liability (whether under the theories of breach of contract or warranty,
negligence, or strict liability) for its Goods shall be limited to repairing or
replacing Goods found by Seller to be defective, or at Seller’s option, to
refunding the purchase price of such Goods or parts thereof.
In no event shall seller be liable for consequential damages arising out of or
in connection with this agreement, including without limitation, breach of any
obligation imposed on seller hereunder. Consequential damages shall include
without limitation, loss of use, income or prot, or loss sustained as the result of
injury (including death) to any person, or loss of or damage to property (including
without limitation property handled or processed by the use of the goods).
Buyer shall indemnify seller against all liability, cost or expense which may be
sustained by seller on account of any such loss, damage, or injury.
Upon buyer’s receipt of shipment, Buyer shall immediately inspect the Goods.
Unless Buyer provides Seller with written notice of any claim for shortage,
overcharge, or damage of Goods within ten (10) days from invoice date, such
Goods shall be deemed nally inspected, checked and accepted by Buyer and
no allowances shall be made thereafter. In absence of shipping and packaging
instructions, Seller shall use its own discretion in the choice of carrier and
method of packing. Seller shall not be responsible for insuring shipments unless
specically requested by Buyer and any insurance or special packaging so
requested shall be at Buyer’s expense and valuation.
Title to any Goods sold and risk of loss of such Goods passes to Buyer upon
delivery by Seller to carrier and any claims for losses or damages shall be made
by Buyer directly with carrier.
A. In addition to the rights and remedies conferred upon Seller by law, Seller
shall not be required to proceed with the performance of any order or
contract if the Buyer is in default in the performance of any order or contract
with Seller, and in case of doubt as to Buyer’s nancial responsibility,
shipments under this order may be suspended.
B. No delay or omission by Seller in exercising any right or remedy provided
for herein shall constitute a waiver of such right or remedy and shall not be
constituted as a bar to or a waiver of any such right or remedy on any future
occasion.
C. The sale of Goods shall be governed by the laws of the State of Nevada.
Seller agrees to comply with all applicable laws of the United States.
The invalidity or unenforceability of any one or more phrases, sentences, or
sections shall not affect the validity or enforceability of the remaining portions of
this Agreement.
Limitation of
liability
Disclaimer of
consequential
damages
Acceptance and
transportation
Title and
risk of loss
General
conditions
Severability

viii MASTERPIPE®Mini Proler
To the newest member of our Torchmate Family:
Thank You! Thank you for putting your faith and trust in Torchmate.
When you purchased your Torchmate CNC Cutting System, you pur-
chased more than just a machine. You purchased a team. The Torch-
mate team was built with the goal in mind of helping you get the most
value out of your automation investment.
For some, this Torchmate CNC Cutting System purchase is their rst
endeavor into the world of automation. Others may consider themselves
seasoned automation experts. No matter which category you fall into it
is important that you realize that investing in a Torchmate is unlike any
other machinery purchase you have made. We consider your success
our success as well as your challenges our challenges.
The Torchmate product line is designed to be simple, reliable and accu-
rate. While there is no “Easy” button on your new system, I can promise
that you will get out of it what you put in. Operating any machinery is a
skill and does have a learning curve.
The rst and perhaps most important item I want to give you today is the
Torchmate Technical Support Hotline: [phone], ext 3. This num-
ber is toll free for those within the United States. For those outside the
United States, use the following number [phone], ext 3. There is
a dedicated professional support staff available Monday – Friday from
7:30am to 4pm to assist you in any way that they can. We pride our-
selves on offering free unlimited telephone support for your machine and
all we expect in return is communication, understanding and patience.
We are here for you as long as you need us.
Please don’t be a stranger. If you have questions or problems, call us.
No matter how trivial your issue may seem it is not trivial if it cuts into
your productivity. Call, Call, Call! We are here for you! Thank you again
for putting your trust in us. We will do our best to not let you down.
Sincerely,
Bill Kunz, Jr., General Manager
Torchmate Inc.
Call us for help
Welcome Letter
Welcome to Torchmate

1
Safety Guide
Safety Information

2MASTERPIPE®Mini Proler
Lincoln Electric Cutting Systems equipment is designed and built with safety in mind.
However, your overall safety can be increased by proper installation ... and thoughtful
operation on your part.
Safety First
PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR
DEATH.
KEEP CHILDREN AWAY.
IF YOU WEAR A PACEMAKER, YOU SHOULD CONSULT WITH YOUR
DOCTOR BEFORE OPERATING.
Read and understand the following safety highlights. For additional safety
information it is strongly recommended that you purchase a copy of “Safety in
Welding & Cutting - ANSI Standard Z49.1” from the American Welding Society,
P.O. Box 351040, Miami, Florida 33135 or CSA Standard W117.2.
BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE, AND RE-
PAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS.
1. ELECTRIC SHOCK can kill.
1.1 The electrode and work (or ground) circuits are electrically “hot”
when the power source is on. Do not touch these “hot” parts with
your bare skin or wet clothing. Wear dry, hole-free gloves to insulate
hands.
1.2 Disconnect the power source before performing any service or
repairs. When the power source is operating, voltages in excess
of 250 volts are produced. This creates the potential for serious
electrical shock - possibly even fatal.
1.3 Insulate yourself from work and ground using dry insulation. Wear
dry gloves and clothing. Take extra care when the work place is
moist or damp.
1.4 Always be sure the work cable makes a good electrical connection
with the metal being cut or gouged. The connection should be as
close as possible to the area being cut or gouged.
1.5 Ground the work or metal to be cut or gouged to a good electrical
(earth) ground.
1.6 Maintain the plasma torch, cable and work clamp in good, safe
operating condition. Repair or replace all worn or damaged parts.
Replace damaged insulation.
1.7 Never dip the torch in water for cooling or plasma cut or gouge in or
under water.
1.8 When working above oor level, protect yourself from a fall should
you get a shock.
1.9 Operate the pilot arc with caution. The pilot arc is capable of burning
the operator, others or even piercing safety clothing.
1.10 Also see Items 4.3 and 6.
WARNING
DO NOT INSTALL,
OPERATE, OR REPAIR
THIS EQUIPMENT
WITHOUT READING
THE SAFETY WARN-
INGS CONTAINED
THROUGHOUT THIS
MANUAL.
Think before you act—
and be careful.
Electric shock

3
Safety Guide
2. ARC RAYS can burn.
2.1 Plasma Arc Rays can injure your eyes and burn your skin. The
plasma arc process produces very bright ultraviolet and infrared
rays. These will damage your eyes and burn your skin if you are not
properly protected.
2.2 Use safety glasses and a shield with the proper lter and cover
plates to protect your eyes from sparks and the rays of the arc when
performing or observing plasma arc cutting or gouging. Glasses,
head-shield, and lter lens should conform to ANSI Z87. I standards.
Arc Current Minimum
Shade No.
Suggested
Shade No.
Less than 20A 4 4
20A-40A 5 5
40A-60A 6 6
60A-300A 8 9
300A-400A 9 12
400A-800A 10 14
2.3 Use suitable clothing including gloves made from durable ame-
resistant material to protect your skin and that of your helpers from
the arc rays.
2.4 Protect other nearby personnel with suitable non-ammable
screening and/or warn them not to watch the arc nor expose
themselves to the arc rays or to hot spatter or metal.
3. FUMES AND GASES can be dangerous.
3.1 Plasma cutting or gouging may produce fumes and gases
hazardous to health. Avoid breathing these fumes and gases. When
cutting or gouging, keep your head out of the fumes. Use enough
ventilation and/or exhaust at the arc to keep fumes and gases away
from the breathing zone.
3.2 Use an air-supplied respirator if ventilation is not adequate to
remove all fumes and gases.
3.3 When plasma cutting or gouging on lead or cadmium plated steel
and other metals or coatings which produce highly toxic fumes,
keep exposure as low as possible and within applicable OSHA PEL
and ACGIH TLV limits using local exhaust or mechanical ventilation.
In conned spaces or in some circumstances, outdoors, a respirator
may be required.
3.4 Additional precautions are also required when cutting (zinc)
galvanized steel or materials containing or coated with any of the
following:
Antimony Beryllium Cobalt Manganese Selenium
Arsenic Cadmium Copper Mercury Silver
Barium Chromium Lead Nickel Vanadium
Arc rays
Fumes, gases,
and dust

4MASTERPIPE®Mini Proler
3.5 The operation of plasma cutting or gouging fume control equipment
is affected by various factors including proper use and positioning
of the equipment, maintenance of the equipment, and the specic
procedure and application involved. Worker exposure levels should
be checked upon installation and periodically thereafter to be certain
levels are within applicable OSHA PEL and ACGIH TLV limits. For
information on how to test for fumes and gases in your work place,
refer to publications section of this manual.
3.6 Do not use plasma cutting or gouging equipment in locations near
chlorinated hydrocarbon vapors coming from degreasing, cleaning
or spraying operations. The heat and rays of the arc can react with
solvent vapors to form phosgene, a highly toxic gas, and other
irritating products. Remove all sources of these vapors.
3.7 Gases used for plasma cutting and gouging can displace air and
cause injury or death. Always use enough ventilation, especially in
conned areas, to insure breathing air is safe.
3.8 Read and understand the manufacturer’s instructions for this
equipment and follow your employer’s safety practices.
3.9 This product, when used for cutting, produces fumes or gases
which contain chemicals known to the State of California to cause
birth defects
3.10 Some dust created by routing, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer,
birth defects or other reproductive harm. Avoid prolonged contact
with this dust. Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your mouth, eyes, or
lay on the skin may promote absorption of harmful chemicals.
Some examples of these chemicals are:
• Lead from lead-based paint.
• Crystalline silica from bricks and cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber (CCA).
3.11 Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed to
lter out microscopic particles.
4. Cutting ame and sparks can cause FIRE OR EXPLOSION.
4.1 Fire and explosion can be caused by hot slag, sparks, oxygen fueled
cutting ame, or the plasma arc.
4.2 Have a re extinguisher readily available. Provide a re watch when
working in an area where re hazards may exist.
4.3 When not cutting or gouging, make certain no part of the electrode
circuit is touching the work or ground. Accidental contact can cause
overheating and create a re hazard.
Safety First (continued)
Fire or Explosion

5
Safety Guide
4.4 Be sure there are no combustible or ammable materials in the
workplace. Any material that cannot be removed must be protected.
4.4.1 Sparks and hot materials from cutting or gouging can easily
go through small cracks and openings to adjacent areas.
4.4.2 Avoid cutting or gouging near hydraulic lines.
4.4.3 Do not cut or gouge tanks, drums or containers until the
proper steps have been taken to insure that such procedures
will not cause ammable or toxic vapors from substances
inside. They can cause an explosion even though they have
been “cleaned.” For information purchase “Recommended
Safe Practices for the Preparation for Welding and Cutting
of Containers and Piping That Have Held Hazardous
Substances”, AWS F4.1 from the American Welding Society
(see address above).
4.4.4 Vent hollow castings or containers before heating, cutting or
gouging. They may explode.
4.5 Do not add fuel to engine driven equipment near an area where
plasma cutting or gouging is being done.
4.6 Connect the work cable to the work as close to the cutting or
gouging area as practical. Work cables connected to the building
framework or other locations away from the cutting or gouging area
increase the possibility of the current passing through lifting chains,
crane cables or other alternate circuits. This can create re hazards
or overheat lifting chains or cables until they fail.
4.7 Hydrogen gas may be formed and trapped under aluminum work
pieces when they are cut underwater or while using a water table.
DO NOT cut aluminum alloys underwater or on a water table
unless the hydrogen gas can be eliminated or dissipated. Trapped
hydrogen gas that is ignited will cause an explosion.
4.8 Read and follow NFPA 51B “ Standard for Prevention During
Welding, Cutting and Other Hot Work”, available from NFPA, 1
Batterymarch Park,PO box 9101, Quincy, Ma 022690-9101.
5. CYLINDER may EXPLODE if damaged.
5.1 Use only compressed gas cylinders containing the correct gas for
the process used and properly operating regulators designed for the
gas and pressure used. All hoses, ttings, etc., should be suitable
for the application and maintained in good condition.
5.2 Always keep cylinders in an upright position securely chained to an
undercarriage or xed support.
5.3 Cylinders should be located: • Away from areas where they may
be struck or subjected to physical damage. • A safe distance from
plasma cutting or gouging, arc welding operations and any other
source of heat, sparks, or ame.
5.4 Never allow any part of the electrode, torch or any other electrically
“hot” parts to touch a cylinder.
5.5 Keep your head and face away from the cylinder valve outlet when
opening the cylinder valve.
5.6 Valve protection caps should always be in place and hand tight
except when the cylinder is in use or connected for use.
Cylinder Explosion

6MASTERPIPE®Mini Proler
5.7 Read and follow the instructions on compressed gas cylinders,
associated equipment, and CGA publication P-l, “Precautions for
Safe Handling of Compressed Gases in Cylinders,”available from
the Compressed Gas Association 1235 Jefferson Davis Highway,
Arlington, VA 22202.
6. FOR ELECTRICALLY powered equipment.
6.1 Turn off input power using the disconnect switch at the fuse box
before working on the equipment.
6.2 Install equipment in accordance with the U.S. National Electrical
Code, all local codes and the manufacturer’s recommendations.
6.3 Ground the equipment in accordance with the U.S. National
Electrical Code and the manufacturer’s recommendations.
7. PLASMA ARC can injure.
7.1 Keep your body away from nozzle and plasma arc.
7.2 Operate the pilot arc with caution. The pilot arc is capable of burning
the operator, others or even piercing safety clothing.
8. ELECTRIC AND MAGNETIC FIELDS may be dangerous
8.1 Electric current owing through any conductor causes localized
Electric and Magnetic Fields (EMF). Cutting or gouging current
creates EMF elds around torch cables and cutting machines.
8.2 EMF elds may interfere with some pacemakers, so operators
having a pacemaker should consult their physician before cutting or
gouging.
8.3 Exposure to EMF elds during cutting or gouging may have other
health effects which are now not known.
8.4 All operators should use the following procedures in order to
minimize exposure to EMF elds from the cutting or gouging circuit:
8.4.1 Route the torch and work cables together - Secure them with
tape when possible.
8.4.2 Never coil the torch cable around your body.
8.4.3 Do not place your body between the torch and work cables.
If the torch cable is on your right side, the work cable should
also be on your right side.
8.4.4 Connect the work cable to the workpiece as close as possible
to the area being cut or gouged.
8.4.5 Do not work next to cutting power source.
Safety First (continued)
Electric and
magnetic elds
Electrical power
Plasma arc

7
Safety Guide
9. AUTOMATIC OPERATION
9.1 Any CNC machine may begin to operate automatically without
warning. Only a trained individual familiar with the software,
machine, and computer system should operate this equipment.
9.2 Keep the immediate area around the CNC machine clear of
materials that may cause interference. Keep area clear of
bystanders.
9.3 All untrained persons should not work on or near a CNC machine.
Do not leave the CNC machine unattended while power is on to any
electronics.
10. NOISE
10.1 Noise can cause permanent hearing loss. CNC operation, plasma
arc cutting, plate marking, routing, and drilling can cause noise
levels that exceed safe limits. You must protect your ears from loud
noise to prevent permanent loss of hearing.
10.1.1 To protect your hearing from loud noise, wear protective ear
plugs and/or ear muffs. Protect others in the workplace.
10.1.2 Noise levels should be measured to be sure the decibels
(sound) do not exceed safe levels.
10.2 For information on how to test for noise refer to the publications
section of this manual.
11. HEAVY PARTS
11.1 Parts of CNC machines are heavy. Also, material you are cutting
may be heavy. Use caution when lifting or moving them. To avoid
injury, get someone to help you, or use a mechanical lifter. When
using a mechanical lifter, follow all the manufacturer’s safety
guidelines.
11.2 Review the Occupational Safety & Health Administration (OSHA)
technical manual Sect. 7, Ch 1.5. See the publications section that
follows.
12. FLYING DEBRIS
12.1 Metal cutting and marking operations create waste that can
fragment and y. Make sure you have proper eye protection and that
everyone close to the CNC operations has proper eye protection,
too.
12.2 Review the ANSI Z87.1 requirements. See the publications section
for additional information.
13. PINCH AND CRUSH POINTS
13.1 Pinch and crush points are those normally moving parts of
machinery, like CNC machines, that can pinch, capture, crush, or
sever parts of your body. Be aware of hazardous pinch and crush
points.
13.2 Don’t repair or adjust the machine with the controls on.
Automatic
operation
Noise
Heavy parts
Flying debris
Pinch & crush points

8MASTERPIPE®Mini Proler
13.3 When the end of a CNC machine’s travel creates a “hard stop,” it
creates a crush point. Keep ngers and hands away from this.
13.4 Do not stack or store any additional items in contact with the
machine. These could create additional pinch or crush points, or
could create a falling hazard.
14. SHARP ROTARY TOOLS
14.1 Routing and drilling use high-speed rotating bits and cutters with
sharp edges. Keep clear of bits when in use.
14.2 Turn the router, spindle, or drill off when changing bits. Be careful of
the sharp edges.
15. HOT MATERIAL
15.1 Plasma cutting uses an electric arc that can reach temperatures
of 45,000°F (25,000°C). Oxygen-fuel cutting ames can be up to
6,330°F (3,500°C). Any parts and scrap will be very hot after cutting.
Use extreme care.
15.2 Use tongs and wear protective gloves when handling recently cut
material. Also, consider other devices for safe hot material handling.
15.3 It is safest to let material cool completely before handling.
16. MECHANICAL DRIVES
16.1 High-speed mechanical drives made of gears, belts, and or drive
screws are used by CNC machines. Keep clear of them during
operation.
16.2 Do not attempt to service, adjust, or otherwise touch these
components while the machine is on.
16.3 Secure any loose clothing and cables to prevent entanglement.
17. AIR LINES UNDER PRESSURE
17.1 Some tools use compressed air or gases. Often exible tubing (lines)
bring the high-pressure air or gas to the machine. Inspect these
lines periodically. Repair or replace damaged lines.
17.2 Hot sparks, ying debris, other objects, or vehicles can melt, burn,
or puncture these lines. Check them for punctures, burns, or other
damage or defects that could cause failure.
17.3 Check the routing of the lines to keep them away from trafc and
from underfoot.
Rotary Tools
Mechanical Drives
Hot Material
Safety First (continued)
Pressurized Air Lines

9
Safety Guide
Refer to the following standards or their latest revisions for more information:
• OSHA, SAFETY AND HEALTH STANDARDS, 29CFR 1910, obtainable from the
Superintendent of Documents, U.S. Government Printing Ofce, Washington, D.C.
20402
• ANSI Standard Z49.1, SAFETY IN WELDING AND CUTTING, obtainable from the
American Welding Society, 550 N.W. LeJeune Rd, Miami, FL 33126
• NIOSH, SAFETY AND HEALTH IN ARC WELDING AND GAS WELDING AND
CUTTING, obtainable from the Superintendent of Documents, U.S. Government
Printing Ofce, Washington, D.C. 20402
• ANSI Standard Z87.1, SAFE PRACTICES FOR OCCUPATION AND EDUCATIONAL
EYE AND FACE PROTECTION, obtainable from American National Standards
Institute, 1430 Broadway, New York, NY 10018
• ANSI Standard Z49.2, FIRE PREVENTION IN THE USE OF CUTTING AND WELDING
PROCESSES, obtainable from American National Standards Institute, 1430
Broadway, New York, NY 10018
• AWS Standard A6.0, WELDING AND CUTTING CONTAINERS WHICH HAVE HELD
COMBUSTIBLES, obtainable from American Welding Society, 550 N.W. LeJeune Rd,
Miami, FL 33126
• NFPA Standard 51, OXYGEN-FUEL GAS SYSTEMS FOR WELDING, CUTTING AND
ALLIED PROCESSES, obtainable from the National Fire Protection Association,
Batterymarch Park, Quincy, MA 02269
• NFPA Standard 70, NATIONAL ELECTRICAL CODE, obtainable from the National
Fire Protection Association, Batterymarch Park, Quincy, MA 02269
• NFPA Standard 51B, CUTTING AND WELDING PROCESSES, obtainable from the
National Fire Protection Association, Batterymarch Park, Quincy, MA 02269
• CGA Pamphlet P-1, SAFE HANDLING OF COMPRESSED GASES IN CYLINDERS,
obtainable from the Compressed Gas Association, 1235 Jefferson Davis Highway,
Suite 501, Arlington, VA 22202
• CSA Standard W117.2, CODE FOR SAFETY IN WELDING AND CUTTING, obtainable
from the Canadian Standards Association, Standards Sales, 178 Rexdale Boulevard,
Rexdale, Ontario, Canada M9W 1R3
• NWSA booklet, WELDING SAFETY BIBLIOGRAPHY obtainable from the National
Welding Supply Association, 1900 Arch Street, Philadelphia, PA 19103
• ANSI Standard Z88.2, PRACTICE FOR RESPIRATORY PROTECTION, obtainable
from American National Standards Institute, 1430 Broadway, New York, NY 10018
PUBLICATIONS

10 MASTERPIPE®Mini Proler
Toll Free: 1-866-571-1066 x3
International: 775-673-2200 x3
Fax: [phone]
Email: [email protected]
When making the connections and setting up the table if a
question or concern arises or a part seems to be missing, please
contact Torchmate technical support.
Technical support will also help you with operating the CNC
system, and troubleshooting problems.
Technical support is available every day from 6:30 AM to 4:00 PM
Pacic Time Zone.
Call, fax, or email
Technical Support
Call us for
Consumables,
or visit our
web store
www.TorchmateStore.com

11
Installation and Operations Guide
Hardware Installation

12 MASTERPIPE®Mini Proler
Parts and assemblies checklist
The parts included in your MASTERPIPE®Mini Proler System (MPMP) shipment are listed
here in the order you will assemble them. To make it easier to complete the assembly of your
cutting system, lay out the received parts in this order as you check them against this list.
;Qty. Part Description Part Number Step
1 MPMP base machine TMS-050-0005-01 1
0 to
4
MPMP 5' add-on section (optional) TMS-050-0005-02 2
0 to
24
3⁄8"–16 X 5⁄8" Socket head cap screw TMS-410-0018-10
(6 per optional add-on
section)
2
0 to
24
3⁄8" Washer TMS-413-0001-18
(6 per optional add-on
section)
2
1 to
5
61” Rail assembly
(May be pre-installed)
TMS-140-0001-06
(1 per base machine
1 per add-on)
3
6 to
30
5⁄16”–18 X ¾” socket head cap screw
(May be pre-installed)
TMS-410-0016-12
(6 per rail assembly)
3
0 to
8
¼”–20 X ¾” hex head cap screw
(May be partly or fully pre-installed)
TMS-410-0014-12
(2 per add on)
3
0 to
8
¼” SAE washer
(May be partly or fully pre-installed)
TMS-413-0001-14
(2 per add on)
3
2 to
6
Cable Carrier Hanger
(May be pre-installed)
TMS-140-0002-12
(2 per base machine
1 per add on section)
4
4 to
12
5⁄16"–18 X 3⁄4" Socket head cap screw
(May be pre-installed)
TMS-410-0014-12
(4 per base machine
2 per add on section)
4
4 to
12
5⁄16" Washer
(May be pre-installed)
TMS-413-0001-14
(4 per base machine
2 per add on section)
4
1 to
5
Cable carrier support tray TMS-140-0002-13
(1 per base machine
1 per add-on section)
4
