Lincoln Electric OPTITOME2 HPC III User manual

CUTTING MACHINE
OPTITOME²
HPC III
SAFETY INSTRUCTIONS FOR OPERATING AND MAINTENANCESAFETY INSTRUCTIONS FOR OPERATING AND MAINTENANCE
Instruction manualISSUE : EN REF : 8695 4791
REVISION : B
DATE : 03 - 2022 Original instructions

OPTITOME² HPC III II
Thank you very much for the trust you have shown by choosing this piece of
equipment. It will give you trouble-free service if it is used and maintained as
recommended.
Its design, component specications and manufacturing are in accordance with
applicable European directives.
Please refer to the CE declaration enclosed to identify the directives applicable to it.
The manufacturer shall not be liable for any combination of parts not recommended
by it.
For your safety, please follow the non-limitative list of recommendations and
obligations, a large part of which are included in the Labour Code.
Please inform your supplier if you nd any error in this instruction manual.

III User’s guide
A - IDENTIFICATION...................................................................................................................... 1
B - SAFETY INSTRUCTIONS........................................................................................................ 2
1 - Particular safety instructions --------------------------------------------------------------------------------------- 2
2 - Layout----------------------------------------------------------------------------------------------------------------------- 4
C - DESCRIPTION ......................................................................................................................... 6
1 - Description ---------------------------------------------------------------------------------------------------------------- 6
2 - General --------------------------------------------------------------------------------------------------------------------- 7
3 - Mechanical system ----------------------------------------------------------------------------------------------------- 8
4 - Cutting table -------------------------------------------------------------------------------------------------------------- 9
5 - Transverse carriage ---------------------------------------------------------------------------------------------------10
6 - Power systems----------------------------------------------------------------------------------------------------------10
7 - Console--------------------------------------------------------------------------------------------------------------------11
8 - Limit of supply ----------------------------------------------------------------------------------------------------------11
D - ASSEMBLY AND INSTALLATION ......................................................................................... 12
1 - Installation conditions------------------------------------------------------------------------------------------------12
2 - Floor preparation-------------------------------------------------------------------------------------------------------13
3 - Putting in place the Optitome 2040 -------------------------------------------- 13
4 - Putting in place the Optitome 1530 -------------------------------------------- 19
5 - Connecting the energy supplies ----------------------------------------------------------------------------------21
E - OPERATING MANUAL .......................................................................................................... 22
1 - Description of controls-----------------------------------------------------------------------------------------------22
2 - Starting up the machine ---------------------------------------------------------------------------------------------23
3 - Shutting down the machine ----------------------------------------------------------------------------------------25
F - MAINTENANCE...................................................................................................................... 26
1 - Care26
2 - Change in consumables ---------------------------------------------------------------------------------------------27
3 - Troubleshooting --------------------------------------------------------------------------------------------------------28
4 - HMI alarm -----------------------------------------------------------------------------------------------------------------28
5 - Spare parts ---------------------------------------------------------------------------------------------------------------30
PERSONAL NOTES .................................................................................................................... 36
Table of contents

OPTITOME² HPC III IV
• P07005015NG OPTITOME² HPC III 2010
• P07005035NG OPTITOME² HPC III 1530
• P07005045NG OPTITOME² HPC III 2040
• P07005065NG OPTITOME² HPC III 2060
• AS-CM-OPT2D1530FL1 OPTITOME² HPC III 1530 FINELINE 170
• AS-CM-OPT2D1530FL3 OPTITOME² HPC III 1530 FINELINE 300
INFORMATION
This technical literature is intended for the following machines or products:
These instructions and the product covered by them refer to the applicable standards.
Please read these instructions carefully before installing, using or maintaining the machine. Keep
these instructions in a safe place for future reference. These instructions must accompany the
described machine or equipment if there is a change in ownership, up to the time of destruction.
Display and pressure gauge:
Measurement instruments or displays of voltage, intensity, speed, accuracy etc. are to be
considered as indicators, whether they are analogue or digital.
For operating instructions, adjustments, troubleshooting and spare parts, please refer to the
special instructions for safe operating and maintenance.
REVISION : B : 03/22
DATE
DESCRIPTION PAGE
Created in English
REVISIONS

VUser’s guide
MEANING OF SYMBOLS
Reading the manual/instructions
mandatory. Indicates a hazard.
Use of safety shoes mandatory. Warning of an electrical risk or hazard.
Use of auditory protection mandatory. Warning of a risk or hazard due to an
obstacle on the ground.
Use of safety helmet mandatory. Warning of a risk or hazard of falling,
with a level di󰀨erence.
Use of safety gloves mandatory. Warning of a risk or hazard due to
suspended loads.
Use of safety glasses mandatory. Warning of a risk or hazard due to the
presence of a hot surface.
Use of safety visor mandatory. Warning of a risk or hazard due to
moving mechanical parts.
Use of safety clothing mandatory.
Warning of a risk or hazard due to the
closing movement of moving mechanical
parts of a machine.
Cleaning the working area mandatory. Warning of a risk or hazard due to the
presence of a laser radiation.
Use of breathing protection mandatory. Warning of a risk or hazard due to an
obstacle at a height.
Visual inspection required. Warning of a risk or hazard due to the
presence of a pointed part.
Indicates a lubrication operation. Wearers of pacemakers may not be
admitted in the designated area.
Requires maintenance action.

OPTITOME² HPC III VI

1User’s guide
A - IDENTIFICATION
The information below should be provided in all correspondence.

OPTITOME² HPC III 2
B - SAFETY INSTRUCTIONS
HANDLING
• For installation or maintenance operations, the operator must use the lifting eyes provided for
that purpose and shown on the drawing.
AIRBORNE NOISE:
Refer to the special instructions 8695 7050 supplied with the equipment.
For general safety instructions, please refer to the specic manual supplied with the
equipment.
1 - Particular safety instructions
CONDITIONS OF USE
• No object is to be placed on the rolling tracks.
• Do not climb on the cable drag chain.
• Before handling plates, make sure that the safety of personnel and property is protected.
• Before using the machine, make sure that all the guards are in place.
• All guard covers must be screwed in.
• Only authorised personnel may access electrical cabinets, which must have locking systems.
• No maintenance may be carried out on the machine when it is supplied with power.
• For any extended absence, the operator must shut o󰀨 the supply of utilities (electricity and
uids).
• Before anyone starts working between the rolling tracks, make sure that the power supply to
the machine has been switched o󰀨 (locking an emergency stop button is su󰀩cient).
• Switch the power source o󰀨 while changing the wearing parts of the torch if the plasma
process is being used.
• The lighting on the control panel must keep the user safe (500 lux on the control panel, 200
lux on the table).
“No climbing on the structure of the machine other than on platforms or gangways
designed for that purpose.
To access equipment at heights, the user must use accessing means in accordance with
the regulations, such as a safe mobile gangway, an aerial lift etc.”.
Clean the working area from time to time.
STABILITY
• The machine must be anchored to the oor.
In spite of all the measures applied, invisible residual risks may still remain.
Residual risks can be reduced if the safety instructions are observed, the machine is used
as recommended and general service instructions are followed

3User’s guide
This machine may only be moved by its designer, namely Lincoln Electric.
The use of Personal Protective Equipment (PPE) and work clothing covering the body is
mandatory.
The emergency stop and safety lines must be interlocked and tested in accordance with the
electricity diagram of the machine.
IMPORTANT: “Do not remove the Nylstop nuts from the fastening screws of the guards:
they keep them captive"
Machine maintenance must be carried out with all the energy supplies switched o󰀨.
The disconnection and padlocking of all energy sources is mandatory.
HANDLING OF PARTS
• The equipment for handling workpieces that have been or need to be cut is not part of the
supply and is to be provided by the customer. The customer must therefore take protective
measures appropriate for the equipment for handling the workpieces.
• CAUTION: While handling sheets to cut, take the necessary precautions to avoid impacts on
the machine and the rolling tracks.
• Impacts on any of the elements can lead to squareness faults or the malfunctioning of the
electrical shaft and therefore incorrect cutting of the workpieces.
• For safety reasons, the operator may not climb on the cutting tables to handle the
workpieces.
• An accidental manoeuvre could restart the movement unintentionally.
• The machine must remain under the supervision of a trained operator when it is operating.
IMPORTANT:
BEFORE ANY MAINTENANCE OPERATION, REMEMBER TO:
• Switch o󰀨 and lock out the electricity supply.
• Switch o󰀨, ush and lock out the gas and compressed air supplies.
Mind the risk of electric shocks: There is an outside power supply in the electrical cabinet
that is not switched o󰀨 with the main disconnector.
That outside power supply is identiable by orange wires and terminals.
If single-beam cells are being used, do not reset the cells if anybody is located between
the cells and the beam.

OPTITOME² HPC III 4
For safety reasons, please apply the label supplied in this folder near the machine control console.
LA MACHINE EN FONCTIONNEMENT
DOIT RESTER SOUS SURVEILLANCE
D'UN SEUL OPERATEUR FORME.
LE FRANCHISSEMENT DES RAILS
(électrique et fluides)
FERMER LES ARRIVEES D'ENERGIES
POUR TOUTE ABSENCE PROLONGEE DE L'OPERATEUR
MACHINE AVANT TOUTE INTERVENTION
VERROUILLER L'ARRET D'URGENCE
PEUT ETRE DANGEREUX
2 - Layout
The operator station is located before the control console.
The machine you have purchased can be hazardous if you do not take certain precautions for use.
Make sure that no part of the machine can come within less than 500 mm from an obstacle.
Important: the operator passage way must absolutely be clear over a minimum width of 800 mm according to
safety standards.
The oor should be marked out as shown in the enclosed drawing.
While accessing the marked area, a worker could be hit by the machine or the cable drag chain.
see layout drawing supplied.

5User’s guide

OPTITOME² HPC III 6
C - DESCRIPTION
1 - Description
1Beam
2Cutting table with guide rails
3Tool carriage
4Control panel
5HPC Digital Process III CNC control
6Electrical power system
7Tool holder
1
3
7
2
4
5
6

7User’s guide
2 - General
This is a numerically controlled single-piece plasma cutting machine that is particularly suited to industries
that use steel, stainless steel and aluminium for plates measuring:
• 1500*3000 => Optitome II 1530
• 2000*4000 => Optitome II 2040
• 2000*1000 => Optitome II 2010
• 2000*6000 => Optitome II 2060
The main intended applications are those of iron workers, metal workers, air processing, air-conditioning,
ventilation, refractory industries, workshops producing in small and medium runs or support production.
It is managed by a CNC control of the HPC 3 Digital Process Hpi type.
This machine uses:
• all dry plasma cutting processes
• optional ame cutting to allow the occasional cutting of black steels, maximum thickness 50mm
• optional WEN marking or FELT marking
The control console supports the operating approach.
The integration of an extraction table (included in the basic o󰀨er) that can be connected to any extraction and/
or ltration system and tted with slag collector boxes makes its conditions of use maximally safe and healthy.
The plate frame is removable, giving easy access for cleaning the boxes, or for replacing it to make it easier
to load and unload cut pieces
The frame is 800mm high and has been designed to allow access so that the distance between the edge of
the rails and the side ends of the table is as short as possible.
Single-beam cells:
Single-beam cells are installed with Optitome 2040 and Optitome 2060.
The movements and process are stopped when the cells are crossed.

OPTITOME² HPC III 8
3 - Mechanical system

9User’s guide
Size A (mm) A (mm) A (mm) A (mm)
1530 2550 4375 1500 3000
2010 3050 2550 2000 1000
2040 3050 5325 2000 4000
2060 3050 7380 2000 6000
4 - Cutting table
This is a single-piece machine made up of a mechanically welded cutting table, with, on each side, a guide
rail with ball slides and a rack to guide and move the beam.
Two guide rails with ball slides and a rack are xed to the beam, to guide and move the tool carriage.
The high feed speed is 15m/min.
A console cabinet to be fastened to the oor contains all the electrical and electronic equipment that is
required for control and operator dialogue
This is a mechanically welded box that is xed to the oor between the machine frame, and which has a Ø
350 outlet for connection to an extraction system. For this table, we recommend the use of extraction with
ltration that is suited to machine performance.
A removable support frame for the piece to cut, made of sheet metal for plasma cutting, is placed on the box.
The high feed speed is 15m/min.
The bottom contains slag collector boxes that are easily removable for cleaning.

OPTITOME² HPC III 10
5 - Transverse carriage
This carriage has three ball slides P1 for optimum guidance.
The powered carriage has the following functions:
• Support for transverse power system
• Support for one or more tools with option.
6 - Power systems
M1 Brushless 750W 3000 rpm power motor
M2 1/19.5 reduction gear
M3 M2 20-tooth pinion

11 User’s guide
7 - Console
The control console of the Optitome provides the operator with the HPC3 Digital Process HPi CNC control,
with all the controls required for starting up the machine and operating the cutting cycle.
The most used controls are located outside, in buttons on the front to make the machine and process easier
to control.
8 - Limit of supply
The customer must supply and install a device for isolating each source of energy (electricity, air,
gas and water). The devices must be clearly identied. They must be of the locking type.
The products AS-CM-OPT2D1530FL1 and AS-CM-OPT2D1530FL3 are delivered with:
• 1 400V 16A male connector for supplying power to the machine.
• 1 400V 125A male connector for supplying power to the power source.
To be paired with a female connector of the same type, o󰀨ering adequate protection (data on the power
supply drawing).
The 125A connector has a pilot wire for switching o󰀨 the upstream supply if the connector is disconnected.
That pilot wire must be wired to a contactor that controls the power supply to this connector.

OPTITOME² HPC III 12
D - ASSEMBLY AND INSTALLATION
1 - Installation conditions
The machine must be located in accordance with safety standards to keep personnel
safe.
The following conditions must be fullled before the equipment is installed.
ELECTRICITY SUPPLY
see electrical diagram supplied
VERY IMPORTANT
The power cable (customer supply) must have a section suitable for the power rating of the installation.
The customer is responsible for protecting the power cable and the installation itself.
Such protection must be appropriate for the neutral point treatment of the electricity supply.
The information required for rating the protection is provided on the identication plate of the machine.
GAS SUPPLY
see layout drawing supplied
PNEUMATIC SUPPLY
see layout drawing supplied
The user must provide a source of compressed air with a regulator that can supply the required ow and
pressure. The air must be clean, de-oiled and degreased.
QUALITY CLASS: according to standard
Solid pollutant class Class 3 Grain size 5µm Mass concentration 5mg/m3
Water class Class 3 Maximum dew point under pressure –20°C
Total oil class Class 5 Concentration 25 mg/m3
Arrangement of cables and hoses
The customer must provide the means to support and protect cables and hoses from
mechanical, chemical or thermal damage from their source up to the entrance to the cable drag
chain and from the machine up to the entrance to the control console.

13 User’s guide
2 - Floor preparation
The oor does not need any particular preparation for installing the machine; however, we recommend a
concrete oor for the machine to be satisfactorily stable.
Continuous concrete slab (200 mm thick) made at least 21 days previously. The thickness of the slab and its
reinforcement are provided for guidance and must be adapted to the characteristics of the oor.
Single concrete strip. 20 Mpa (350 kg/m³) concrete with metal reinforcement.
Flatness over the entire site with additional travelling tracks ± 10 mm.
30 mm level di󰀨erence of screed (5 mm/m max.).
see layout drawing supplied
Tools required for installing a machine on the site:
• Level o󰀨ering accuracy of 1/10 per metre
• Hammer drill for concrete, for Ø16 bit
• Tape measure
• chalk line
• Vacuum cleaner
• 24 mm open-ended spanner
• 24 mm ring spanner
3 - Putting in place the Optitome 2040
The components of the installation may only be transported using the slinging points provided, with
appropriate slinging equipment.
Check the atness of the oor with an optical level and identify the high point.
1. Putting in place the three parts of the table:
1Part 1
2Part 2
3Part 2

OPTITOME² HPC III 14
• Place the rst part of the table in the location provided,
IMPORTANT: The use of adjustable chains with four strands with highly recommended.
Operator protection:
Helmet - Gloves - Safety shoes
• Unload the console and the bundle pallet (60 daN),
• Pre-adjust the level using the adjustment screws,
• Anchor the table to the oor at the four corners with the dowels supplied,
