25 Lb. (11.3kg)
Diameter 12.5 Lb. (5.7kg) 25 Lb. (11.3kg) Plastic Spool in
in. (mm) Plastic Spool Plastic Spool Vacuum Sealed Bag
1/16 (1.6) ED030933 ED030934 ED031576
.072 (1.8) ED031030 ED031577
Conformance
Welding Positions
1G 2F 2G
3G
➔
4G 5G
➔
Allowable exposure per
Appendix D of FEMA 353
4 Weeks
1/16”
DIAMETERS/PACKAGING
Innershield®NR-233
Self-Shielded Flux-Cored Wire
(AWS A5.20-95: E71T-8)
Advantage Lincoln
User Friendly
Typical Applications
• Vertical up fillet and groove welds
• Overhead fillet and groove welds
• Seismic structural steel erection
• General structural steel erection
• Barge fabrication
AWS A5.20-95: E71T-8
ASME SFA-5.20; E71T-8
Publication C3.2000.3 9/05
www.lincolnelectric.com
CORED WIRE
3F
➔
1F
Note: Appendix D of FEMA 353 allows
additional exposure beyond the
24 hour limit.
NR-233 is an advanced technology, self-shielded flux-cored electrode
designed for high deposition rate welding - even when welding
out-of-position in seismic and non-seismic structural steel applications.
It is also great for fillet welding for ship and barge fabrication. The elec-
trode is welder-friendly, making it easier to pass tough qualification
tests and deposit great looking beads. It does all this while delivering
Charpy V-Notch properties that meet many of the more stringent codes
and specifications for seismic applications.
4F
4 Weeks
.072”
• For the engineer: meets the stringent codes and standards for
Charpy V-Notch properties, such as those listed in FEMA 353.
• For the plant superintendent: higher deposition rates mean
faster building erection, quicker launch of the barge, or more
throughput in fabrication. In short: less cost and more profit.
• For the welder: a more forgiving arc with greater penetration
makes it easier to pass qualification tests, and makes for bet
ter quality welds in production — and the welds look great.
• NR-233 has been formulated to minimize gas marking, even
after the electrode has been exposed to the atmosphere.

THE LINCOLN ELECTRIC COMPANY
22801 St. Clair Ave., Cleveland, OH 44117-1199 • 216.481.8100 • www.lincolnelectric.com
CUSTOMER ASSISTANCE POLICY
The business of The Lincoln Electric Company is manufacturing and selling high quality welding equipment, consumables, and cutting equipment. Our challenge is to meet the
needs of our customers and to exceed their expectations. On occasion, purchasers may ask Lincoln Electric for advice or information about their use of our products. We respond
to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability,
with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s particular purpose, with respect to
such information or advice. As a matter of practical consideration, we also cannot assume any responsibility for updating or correcting any such information or advice once it has
been given, nor does the provision of information or advice create, expand or alter any warranty with respect to the sale of our products.
Lincoln Electric is a responsive manufacturer, but the selection and use of specific products sold by Lincoln Electric is solely within the control of, and remains the sole responsibility
of the customer. Many variables beyond the control of Lincoln Electric affect the results obtained in applying these types of fabrication methods and service requirements.
Subject to Change – This information is accurate to the best of our knowledge at the time of printing. Please refer to www.lincolnelectric.com for any updated information.
TEST RESULTS
Test results for mechanical properties, deposit or electrode composition and diffusible hydrogen levels were obtained from a weld produced and tested according to prescribed
standards, and should not be assumed to be the expected results in a particular application or weldment. Actual results will vary depending on many factors, including, but not limited
to, weld procedure, plate chemistry and temperature, weldment design and fabrication methods. Users are cautioned to confirm by qualification testing, or other appropriate means,
the suitability of any welding consumable and procedure before use in the intended application.
FEMA 353
This electrode has been tested in accordance with FEMA 353 - Recommended Specifications and Quality Assurance Guidelines for Steel Moment-Frame
Construction for Seismic Applications and is capable of depositing weld metal that delivers minimum CVN properties of 40 ft.lbf at 70˚ F (54 Joules at 21˚ C)
at low and high heat input levels. As required by the AWS classification, it meets a minimum CVN of 20 ft.lbf at -20˚ F (27 Joules at -29˚ C), when tested in
accordance with AWS A5.20. This electrode will also deposit metal that will meet the requirements for H16 as tested according to AWS A4.3. FEMA
certificates are available upon request.
Diameter
Polarity Wire Feed Approx. Melt-Off Deposition
CTWD(1) Speed Voltage Current Rate Rate Efficiency
Wire Weight in./min (m/min) (volts) (amps) lbs/hr (kg/hr) lbs/hr (kg/hr) (%)
1/16” 150 (3.8) 17-19 220 5.3 (2.4) 4.2 (1.9) 80
DC- 200 (5.1) 19-21 245 7.1 (3.2) 5.4 (2.5) 76
1/2-1-1/4”(13-32mm) 250 (6.4) 21-23 270 8.9 (4.0) 6.6 (3.0) 74
0.582 lbs./1000” 300 (7.6) 23-25 295 10.4 (4.7) 7.7 (3.5) 75
350 (8.9) 25-27 315 12.3 (5.6) 9.4 (4.3) 77
.072 100 (2.5) 17-18 185 4.5 (2.0) 3.6 (1.6) 80
DC- 150 (3.8) 18-19 250 6.7( 3.1) 5.4 (2.5) 80
3/4-1”(19-25mm) 200 (5.1) 20-21 295 8.9 (4.0) 7.1 (3.2) 81
0.746 lbs./1000” 250 (6.4) 22-23 330 11.2 (5.1) 8.9 (4.0) 79
300 (7.6) 23-24 355 13.4 (6.1) 10.6 (4.8) 79
%C %Mn %P %S %Si %Al
Requirements Report 1.75 0.03 0.03 0.60 1.8
AWS E71T-8 Only max. max. max. max. max.
Typical Test Results 0.17-0.23 0.45-0.66 0.006-0.009 0.003 0.14-0.25 0.47-0.71
(1) To estimate ESO, subtract 1/4” (6.4mm) from CTWD.
Note: For horizontal welding, subtract 1 volt.
TYPICAL OPERATING PROCEDURES
DEPOSIT COMPOSITION - As required per AWS A5.20-95
MECHANICAL PROPERTIES – As required per AWS A5.20-95
Note: The strength and elongation properties reported were obtained from a .505” tensile specimen artificially aged at 220º F (104º C) for 48 hours, as
permitted by AWS A5.20-95. A naturally aged tensile specimen may take months to achieve the specified properties. See AWS A5.20-95, paragraph A8.3. The
time required for the natural aging of weld deposits is dependent upon ambient conditions, weldment geometry, the metallurgical structure of the weld
deposit and other factors.
Charpy V-Notch
Yield Strength Tensile Strength Elongation ft•lbf (Joules)
psi (MPa) psi (MPa) (%) @ -20°F (-29°C)
Requirements 58,000 (400) 70,000 (480) 22 20 (27)
AWS E71T- 8 min. min. min. min.
Typical 62,000- 71,000 73,000 - 92,000 22 - 32 23 - 48
Test Results (430 - 490) (505 - 635) (31 - 65)
