Linksys ADSL2MUE Operation manual

Model No.
Product Data
WIRED
ADSL2MUE (UK)
Your fast, convenient, “always on”
connection to the Internet
High-speed ADSL
modem gives you a
fast, “always on”
connection to the
Internet
Connects to your PC
over 10/100 Ethernet
or USB
Up to 25 Mbps
download speeds,
400 times faster than
dial-up analog
modems
Shares your existing
telephone lines to
connect to the
Internet, without tying
up the phone
The Linksys ADSL2 Modem gives you a blazing fast
connection to the Internet, far faster and more
convenient than a standard dial-up. ADSL technology
lets you access the Internet using your existing phone
lines, without interfering with your voice phone service --
you can talk on the phone and surf the net at the same
time! The "always on" connection eliminates dial-up wait
time and busy signals. Web surfing and your e-mail are
instantly available, anytime.
Along with instant connectivity, you'll be surfing the web at
speeds you never imagined possible. The ADSL2 Modem
is compatible with the latest ADSL standards, including
ADSL2 and ADSL2+. With incoming data speeds up to 25
Mbps. (Actual speeds may vary. Speed obtained is
determined by the provisioned speed. ADSL Standard fo
broadband Internet Service Provider (ISP), loop length and
quality, and other factors.) ADSL broadband service
means no more waiting for slow downloads -- even the
most graphic-intensive web pages load in seconds.
Audio and video streams play smooth and glitch-free.
Installation is quick and simple. Connect it directly to any
PC with an available USB or Ethernet port, and you’re
ready to surf the Internet. Or connect it to a Linksys router
and share that high-speed Internet access with everyone
on your home network.
Harness the full potential of the Internet with the Linksys
ADSL2 Modem.
ADSL2 Modem
with USB & Ethernet

Product Data
Model No.
Features
• High Speed ADSL2+ Modem
• Built-In 10/100 Ethernet Port
and USB Connection
• Automatic MDI/MDI-X
ethernet port crossover
detection
• 2-Year Warranty
Linksys
Web: http://www.linksys.com/international
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit
our Worldwide Web Site at
www.linksys.com/international.
ADSL2MUE (UK)
with USB & Ethernet
ADSL2 Modem
Specifications
Model ADSL2MUE
Standards IEEE 802.3, IEEE 802.,3u, G.992.1 (G.dmt), G.992.2
(G.lite), G.992.3 (ADSL2), T1.413i2, Reach-Extended
ADSL (READSL), ADSL2+ (G.992.5), RFC
1483/2684, RFC 2364 PPPoA, RFC 2516 PPPoE,
USB 1.1
Ports ADSL, USB, Ethernet, Power
Buttons Power, Reset
Cabling Type ADSL: RJ-11
Ethernet: 10/100 RJ-45 Port
USB: USB Type B Port
LEDs Power, Ethernet, USB, DSL, Internet
Environmental
Dimensions 187 mm x 48 mm x 156 mm
(W x H x D) (7.36" x 1.89" x 6.14")
Unit Weight 0.36 kg (12.8 oz.)
Power Input 5 VDC, 1 A
Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)
Storage Temp. 0ºC to 70ºC (32ºF to 158ºF)
Operating Humidity 10% to 85% relative humidity, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
ADSL2MUE_V2-DS-UK-50729 KL
Package Contents
•ADSL2Modem
• Power Adapter
•USBCable
• CAT 5 Ethernet Network Cable
• RJ-11 Phone Cable
• Quick Installation
• User Guide and USB Drivers CD-ROM
•Microfilter
Minimum Requirements
• CD-ROM drive
• Computer with 10/100 RJ-45
Ethernet Network Adapter
or
PC running Windows 98, Me, 2000,
or XP equipped with USB port (to use
the USB connection)
• ADSL or ADSL2 Modem service
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
