Solera® Power Awning
OWNER'S MANUAL

Rev: 06.01.2018 Page 2 Solera® Power Awning Owner's
System Information
The Solera® Power Awning features an internal motor to steadily operate the awning. Additionally, the
friction joint allows for rain dump and adjustable pitch features, and there is no rafter arm to lock in place.
The friction joint also provides added stability.
This manual provides operational procedures for Solera® Power Awning. Operating the Solera® Power
Awning in any other manner than described may result in personal injury, damage to the recreational
vehicle or the awning assembly as well as voiding the Lippert Components Limited Warranty.
Table of Contents
System Information 2
Operation 3
Extending the Awning 3
Retracting the Awning 3
Adjusting Pitch - All Solera Awnings 4
Maintenance - All Solera Awnings 4
Fabric Care 4
Troubleshooting 5
Manual Override 5
Solera Power Awning Assembly 6
Solera Power Awning Components 7-14
Notes 15

Rev: 06.01.2018 Page 3 Solera® Power Awning Owner's
Operation
NOTE: Some coaches may not use the LCI switch (Fig. 3).
Extending the Awning
1. Verify the RV battery is fully charged and connected to the electrical system.
2. Locate the locking latch (Fig. 1), if equipped, and unlock the latch (Fig. 2).
NOTE: This latch is optional and may or may not be installed on one or both support arms.
3. Press and hold EXTEND (Fig. 3A) until the awning is extended completely.
NOTE: Extension is considered complete when the fabric is completely unrolled, the valance seam is visible
and a section of the roll tube is exposed (Fig. 4).
NOTE: The awning fabric should always be above the roll tube. However, if the extend switch is engaged
too long or extend is hit inadvertently instead of retract, the awning will roll up backward. This is not
a defect. To correct the fabric orientation, press the RETRACT button. The awning will then extend
to its correct orientation and normal operation can resume.
Fig. 1
Fig. 2
Fig. 3
Fig. 4 - Complete Extension
Valance Seam
Exposed Roll
Tube Section
Retracting the Awning
1. Verify the coach battery is fully charged and connected to the electrical system.
NOTE: The awning can be retracted without resetting the pitch.
2. Press and hold RETRACT (Fig. 3B) until the awning is retracted completely.
3. Locate the locking latch (Fig. 2), if equipped, and lock the latch (Fig. 1).
NOTE: This latch is optional and may or may not be installed on one or both support arms.
Tying down the roll tube once the awning is extended will not allow the free-floating support arms to
work as designed and may cause damage to the awning or RV.
A
B
Fabric
Roll
Tube
Valance Awning
Head

Rev: 06.01.2018 Page 4 Solera® Power Awning Owner's
Adjusting Pitch - All Solera Awnings
NOTE: The awning will pitch itself to purge the pooling of excess water and may dump a significant
amount of water without notice.
1. Pitch can be set by adjusting the articulating arm to tip one side of the awning to allow water runoff.
2. Extend the awning to desired position.
3. Choose the side of the awning for optimum shade or convenient water runoff. Pull downward on the
joint of the articulating arm until desired pitch is set (Fig. 5) to allow for water runoff. Do not push the
joints of the articulating arms up. This will put tension on the gas strut, which can cause the strut to
break. Belleville washers and bolt (Fig. 6A) allow the joint to remain in the position set by the operator.
NOTE: The awning can be retracted without resetting the pitch.
NOTE: If the articulating arm does not hold position, it can be tightened by adjusting the bolt (Fig. 6A) in
the center of the articulating arm.
Fig. 5 Fig. 6
Pitch
Maintenance - All Solera Awnings
Fabric Care
If the awning is rolled up while wet, roll it out and let it dry as soon as conditions allow before rolling it up
again. This will help prevent the formation of mildew and add greatly to the life of the awning. Mildew does
not form on the fabric itself, but on the accumulated dust, dirt and grime.
NOTE: Periodically clean vinyl or woven acrylic fabric using a mixture of ¼cup of dish soap and 5 gallons
of warm water. Liberally slosh the mixture on the top of the fabric and roll up the awning for 5
minutes. This will apply the mixture to the bottom of the fabric as well. Roll the awning back out and
hose off with fresh water. Repeat if necessary. Allow to dry before rolling up.
A

Rev: 06.01.2018 Page 5 Solera® Power Awning Owner's
Fig. 7 Fig. 8
Troubleshooting
Manual Override
In the event of power loss or motor failure, the awning can be extended and retracted manually. Perform
the following procedure to manually retract the awning.
NOTE: This procedure may also be performed to extend or retract the awning in the event of dry camping
or camping without a battery.
1. Remove the rubber grommet (Fig. 7A) from the drive head assembly, exposing the manual override
nut on the motor.
NOTE: The drive head assembly is always located on the right side of the awning as it is viewed from
outside of the coach.
2. Using a ⁄" socket and cordless/power drill, spin the manual override nut counterclockwise to retract
the awning (Fig. 8).
NOTE: A ratchet may also be used to turn the manual override nut. Using a ratchet will take a significant
amount of time and should only be used if no cordless/power drill is available.
NOTE: Use caution when retracting the awning manually. The use of a step stool or ladder may be required
to completely retract the awning.
3. When the awning is completely retracted, remove socket or drive device and replace the rubber
grommet in the drive head assembly.
NOTE: The motor’s internal drive system prevents the awning from moving (extend or retract) on its own.
If the motor is damaged or disabled, be sure to secure the awning in the retracted position with a
strap around both the outer support arm and the mounted support arm before the manual override
nut is released.
A
During incidents of high wind, heavy rain or extended time away from the unit, it is advisable to retract
the awning completely to prevent damage to the awning and the RV.

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 6 of 16
SOLERA POWER AWNING ASSEMBLY
AWNINGS
Fabric
Awning Rail
Drive Head
Assembly
Idler Head
Assembly
Roll Tube
Support Arm
Assembly
End Cap

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 7 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
A
Variant Code Information
The variant code on Lippert products can assist LCI customers in obtaining additional information about the
product and its components. For replacement part information, locate the variant code on the awning roll tube
and call LCI customer service at 574-537-8900.
Variant Code
Callout Part # Description
A281928 White Awning Rail (144")
281929 Black Awning Rail (144")
B2661301 White End Caps
2661302 Black End Caps
B

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 8 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
F
DEC
GH
Callout Part # Description
C266147 White Idler Head Assembly
273479 Black Idler Head Assembly
D289563 White Idler Head Front Cover
289566 Black Idler Head Front Cover
E289564 White Idler Head Rear Cover
289567 Black Idler Head Rear Cover
F266146 White Drive Head Assembly
273478 Black Drive Head Assembly
G289557 White Drive Head Front Cover
289560 Black Drive Head Front Cover
H289558 White Drive Head Rear Cover
289561 Black Drive Head Rear Cover

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 9 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
I
Drive Head Gear Kit Part # Description Quantity
I
353964
(Only
available
as a kit)
266133 .873" 20 PA 16 DP, D SLOT GEAR 1
266134 .873" 20 PA 16 DP, D SLOT GEAR 1
266136 .500" 20 PA 16 DP, CLR ZN GEAR 1
266142 Bushing 2
266143 Bushing 1
281828 Bushing 1
266137 E-Clip ½" 1
276160 E-Clip ⁄" 1

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 10 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
Callout Part # Description
J 299419 Screw, PNH, SQ DR, SLFTPG, Zn (#8 - 15 UNC x 0.500”) (End Cap-to-Roll Tube)
K 266156 Screw, PNH, Zn (#6 - 15 UNF x 0.500”) (Head Cover fastener – 6/Cover)
L 299630 Screw, Waxed, PNH, SQ DR, Zn (#8 - 32 UNC x 0.500”) (Head-to-Roll Tube)
M118043 Nut, Nylon Lock, Zn (⁄” - 18 UNC) (Head-to-Arm)
N 266155 Screw, Machine, PNH, PHH (#8 - 32 UNC x 0.500”) (Back Cover-to-Mount)
O 281079 Screw, Hex Washer, SLFDR, Zn (#6 - 20 UNC x 0.500”)
P 266148 Screw, PNH, PHH, Zn (⁄” - 18 UNC x 2.25”) (Head-to-Arm)
Q 237315 Rivet, Aluminum (⁄”x 1.300”) (Klamp-Tite, BAPKTR-06-12)
R 429284 Screw 8 x 1 ¼" PNH ZN CD AB ST HBK
S 384905 Screw #10 32 x ½" PHN Plain PH FT SST
T 384906 Nut #10 - 32 Nylon Lock Plain SST
U 320695 Screw #8 - 18 x ½" PNH SMS ZN SQ AB ST, BLK HD
V 266132 Screw IHWH 2N SLF ST (¼- 20 x ¼") (Motor-to-mount)
JKL
M
O
N
P
Q
R
S
T
UV

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 11 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
AA
Z
Y
X
W
Callout Part # Description
W275071 Rubber Grommet (for Manual Override Opening)
X289373 White Awning Center Support Assembly
289374 Black Awning Center Support Assembly
NOTE: Only required for Solera Awnings greater than 21' in length.
Y293659 White Switch Kit 12GA Wire Harness
293658 Black Switch Kit 12GA Wire Harness
Z 298760 Cotter Hairpin
AA 347119 Cotter Pin

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 12 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
AAE
A
AD
AC
Mount
Arm
AB
Support Arm
Assembly
Measurement
Based on
Mount Arm
Callout Part # Description
AB
295742 White Support Arm Assembly (Short, 61")
295743 Black Support Arm Assembly (Short, 61")
260294 White Support Arm Assembly (Pitched, 66 ⁄")
266169 Black Support Arm Assembly (Pitched, 66 ⁄")
362132 White Support Arm Assembly (Short Standard Fixed Pitch, 60 ½")
362133 Black Support Arm Assembly (Short Standard Fixed Pitch, 60 ½")
281152 White Support Arm Assembly (Flat, 69")
281154 Black Support Arm Assembly (Flat, 69")
AC 280343 Gas Strut; 26"; 124 lbs (for Short and Flat Arm Assemblies)
260282 Gas Strut; 124 - 144 lbs (for Pitched Arm Assemblies)
AD 348108 Screw (#14 - 10 x 1 ¼" (Arms-to-Coach)
AE 282484 Star Washer (for Gas Strut)

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 13 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
AF
AG
AH
AI
AJ AK
Callout Part # Description
AF 266149 Motor
AG 266132 Screw IHWH 2N SLF ST (¼- 20 x ¼") (motor-to-mount)
AH
285499 White Switch Kit (Switch, Plate, and Harness)
285500 Black Switch Kit (Switch, Plate, and Harness)
280570 Wire Harness Only
280565 White Switch Plate Only
280567 Black Switch Plate Only
280564 White Switch Only
280566 Black Switch Only
AI 285079 White Bezel Spacer
285077 Black Bezel Spacer
AJ 373008 Power Feed Wires
AK 273007 Power Feed, 2 Way

Rev: 06.01.2018 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected] Page 14 of 16
SOLERA POWER AWNING COMPONENTS
AWNINGS
AL
Callout Part # Description
AL
275070157 White Wire Cover; 9.75"; Narrow
2750701692 Black Wire Cover; 9.75"; Narrow
275070353 White Wire Cover; 22"; Narrow
2750701888 Black Wire Cover; 22"; Narrow
266138481 White Wire Cover; 30"; Narrow
2661382017 Black Wire Cover; 30"; Narrow
266139337 White Wire Cover; 21"; Wide
2661391872 Black Wire Cover; 21"; Wide
266139429 White Wire Cover; 26.75"; Wide
2661391964 Black Wire Cover; 26.75"; Wide

Rev: 06.01.2018 Page 15 Solera® Power Awning Owner's
Notes

Rev: 06.01.2018 Page 16 Solera® Power Awning Owner's
The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from www.lci1.com.
Please recycle all obsolete materials.
