PSX1™ STABILIZER MOTOR REPLACEMENT
TI-379
LEVELING AND STABILIZATION
Purpose
This document outlines the removal and replacement of the PSX1 Stabilizer Motor.
Safety
Resources
• 4 mm hex wrench
• 8 mm combination wrench
• Rotary cutting/grinding tool
Procedure
Motor Removal
1. Disconnect power to the motor from the power source of the unit.
2. Using the 8 mm combination wrench and 4 mm hex wrench, remove the two socket cap screws and
nuts securing one side of the motor to the motor mounting plate.
3. Using the 4 mm hex wrench only, remove the remaining two socket cap screws securing the motor to
the motor mounting plate.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Always wear eye protection when performing this installation procedure. Other safety
equipment to consider would be gloves and possibly a full face shield, depending on the
nature of the installation procedure.
Fig. 1
Socket Cap Screw Nut
NOTE: Motor mounting plate not
shown for clarity.

Rev: 02.01.21 Page 2 CCD-0004129
As a supplier of components to the RV industry, safety, education and customer satisfaction are our primary concerns. Should you
have any questions, please do not hesitate to contact us at [phone] or by email at [email protected]. Self-help tips,
technical documents, product videos and a training class schedule are available at lci1.com or by downloading the MyLCI app.
PSX1™ STABILIZER MOTOR REPLACEMENT
TI-379
LEVELING AND STABILIZATION
Motor Replacement
1. Line up the motor shaft (Fig. 3) on the new motor with the coupler (Fig 2) and install the new motor
using the previously removed socket cap screws and nuts.
NOTE: When installing the new motor, it may be necessary to enlarge the bracket hole from 0.97" to 1.18"
so that the motor shoulder (Fig. 3) fits into the bracket hole. Using a rotary cutting/grinding tool,
remove the material around the bracket hole (Fig. 2) for the shoulder of the motor (Fig. 3) to fit into
the bracket hole.
Fig. 2
Fig. 3
Motor Shaft
Coupler
Bracket Hole
NOTE: The red line indicates designated location to grind.
2. Using the 4mm hex wrench and 8mm combination wrench, securely tighten the socket cap
screws and nuts.
3. Reconnect the wires to the power source and test.
Shoulder
