Quick Reference
RV TRANSPORT GC 3.0 TOUCH PANEL/PAD OPTIONS
Connecting the Tow Vehicle
1. Connect a fully charged battery.
2. Ensure battery disconnect is “On.”
3. Press the “Up” and “Down” arrows
(Fig. 5A and 5B) on the Auto Leveling
Control Touch Pad simultaneously
Fig. 1
A
B
C
D
to turn panel on. The LED (Fig. 5C)
should be solid green.
4. Press the “Up” or “Down” arrows to
extend or retract the landing gear.
NOTE: The arrows control the direction
the front of the trailer will move.
“Up” (Fig. 5A) raises the front
of the trailer. “Down” (Fig. 5B)
lowers the front of the trailer. The
green LED will blink while the
system is running.
5. Connect the tow vehicle.
6. Press and hold the “Down” arrow
until the landing gear is retracted.
7. Use the pull pins on the landing
gear to manually return the jack legs
to their fully retracted position.
8. Turn the battery disconnect “Off.”
Product Information
Ground Control 3.0® automatic leveling system for 5th wheel applications features two
controllers. The earlier version, Rev. A, will have an A on the serial number sticker and black text
for the Lippert part number on the controller (Figs. 1A and 2A). Rev. B will have a B on the serial
number sticker and the Lippert part number text on the controller will be blue (Figs. 3A and 4A).
The controllers will be generally located on the ceiling of a compartment toward the front of the
trailer, and serial number stickers are located in the top left corner on the back of the controller.
AAAA
Fig. 2 Fig. 3 Fig. 4
Fig. 5

Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: [phone] - Email: [email protected]
Rev: 08.22.18 QR-022 / CCD-0001815
Quick Reference
RV TRANSPORT GC 3.0 TOUCH PANEL/PAD OPTIONS
If A Fault Occurs (Rev. B)
If the system stops running and the LED
(Fig. 5C) turns red:
1. Solid red indicates low battery.
A. Ensure battery is fully charged.
B. Ensure battery disconnect is
“On.”
2. A blinking red LED indicates the
system is in Fault Mode. Most
standard codes can be cleared by
pressing "Retract All" (Fig. 5D) on
the Auto Leveling Control Touch
Pad. Three faults cannot be cleared
from the Auto Leveling Control
Touch Pad and must be addressed
from the OneControl Touch Panel
or OneControl App: Hall power
short, bad calibration and sensor
problem.
3. A slowly blinking, faded red LED (red
and green blinking simultaneously)
indicates a jack fault. The landing
gear will still operate in this mode.
A. Press and hold the "Up” (Fig.
5A) icon to extend landing
gear to desired height.
B. Connect tow vehicle.
C. Press and hold the “Retract All”
icon (Fig. 5D) until the landing
gear begins to retract and
the fault code is cleared. The
landing gear will continue to
retract.
D. Use the pull pins on the
landing gear to manually
return the jack legs to their
fully retracted position.
E. Turn the battery disconnect to
"Off."
If A Fault Occurs (Rev. A)
If the system stops running and the LED (Fig. 5C)
turns red:
1. Solid red indicates low battery.
A. Ensure battery is fully charged.
B. Ensure battery disconnect is “On.”
2. A blinking red LED indicates the system is in
Fault Mode.
A. Ensure battery is fully charged.
B. Ensure battery disconnect is “On.”
C. Locate OneControl Touch Panel (Fig. 6)
inside the trailer. If the fault reads a jack
error, complete the following steps:
I. Press “Ok” to acknowledge fault.
II. Press “Extend" (Fig. 6A).
III. Press and hold the “Front” (Fig.
6B) icon to extend landing gear to
desired height.
IV. Connect tow vehicle.
V. Press the “Retract” icon (Fig. 6C).
VI. Press and hold the “Front” icon
until landing gear is retracted.
VII. Use the pull pins on the landing
gear to manually return the
jack legs to their fully retracted
position
VIII. Turn the battery disconnect “Off.”
Fig. 6
B
CA
