Lippert Components Solera Classic Operating and maintenance instructions

Solera® Classic Awning
OEM INSTALLATION MANUAL

Rev: 06.05.18 Page 2 CCD-0001360
System and Safety Information
The Solera® Classic Awning is designed for use on most recreational vehicle units and is available in a variety
of sizes to fit even the largest unit. Additional information about this product can be obtained from www.
lci1.com/support or by downloading the free myLCI app. The app is available on iTunes® for iPhone® and
iPad® and also on Google Play™ for Android™ users.
iTunes®, iPhone®, and iPad® are registered trademarks of Apple Inc. Google Play™ and Android™ are
trademarks of Google Inc.
Fig. 1
TABLE OF CONTENTS
System and Safety Information 2
Preparation 3
Resources Required 3
Installation 3
Installing the Awning Rail (If Necessary) 3
Assembling the Awning 4
Mounting the Bottom Mounting Brackets 4
Mounting the Awning 5
Securing the Fabric 7
Installing the Stop Bolt 7
Notes 8-9
NOTE: Solera® Classic Awning drive and idler heads are preloaded with tension and secured with cotter
pins from the factory. If the cotter pins have been removed or otherwise lost, and tension needs to
be added to the heads, use the turn chart (Fig. 1) to add the correct number of turns to the awning
heads.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Failure to follow the instructions provided in this manual may result in death, serious injury, unit
damage, or voiding of the component warranty.
Classic Awnings Pre-Install
Turn Chart
Size Turns
6 ft to 10 ft 4
11 ft to 14 ft 5
15 ft to 18 ft 6
19 ft and up 8

Rev: 06.05.18 Page 3 CCD-0001360
Installation
All screws supporting the awning assembly MUST have a backer within the structure of the wall of the unit.
Refer to the unit manufacturer for proper location.
Installing the Awning Rail (If Necessary)
NOTE: Awning rail not included.
1. Position the awning rail along the line where roof and wall meet OR:
A. For pitched awnings: A minimum of 11” above doors or windows
B. For flat awnings: A minimum of 4” above doors or windows
NOTE: The awning rail must be level and parallel with the floor line of the unit (Fig. 2).
2. After determining the awning rail's proper location, mark its position with a non-permanent method of
marking.
3. Seal the back of the awning rail.
4. Align the awning rail on the wall and secure with #10 x ¾” screws, using all fastener holes.
Preparation
Do not remove the following items until instructed:
• Tape securing the fabric.
• Cotter pins in the spring assemblies.
Removing these items prematurely may cause personal injury or property damage.
Upper
Mounting
Bracket
90°
90°
Awning
Width
is from
Centerline
to
Centerline
of Support
Arm
Assemblies
Lower
Mounting
Bracket
Awning
Rail
Resources Required
• 1 to 3 people
• Cordless or Electric Drill or Screw Gun
• Appropriate Drive bits
• Screwdriver
• Ratchet
• ⁄” socket
• ½” socket
• ½” wrench
• ⁄” drill bit
• Non-permanent method of marking
• Silicone sealant or butyl tape
• Silicone lubricant
Roll Tube
Assembly
Support
Arm
Assembly
Floor
Line
Support
Arm
Assembly
Side
View
Fig. 2- Front Facing View

Rev: 06.05.18 Page 4 CCD-0001360
Assembling the Awning
NOTE: The head assemblies (Fig. 3A) and support arm assemblies (Fig. 3B) are numbered to ensure proper
assembly. Match the proper support arm assembly to the correct head assembly.
1. On a flat surface, carefully lay out the support arm assemblies and roll tube assembly. The cam lock
MUST be on the right end of the roll tube when facing the unit.
NOTE: Take care not to set the awning on any surface that may damage the assembly or fabric.
2. Slide the left support arm assembly into the idler head assembly of the roll tube. Align the holes and
secure using one (1) ¼-20 x ½” Phillips drive screw (Fig. 4).
3. Repeat step 2 for the right support arm assembly.
4. Measure and confirm the width of the awning. The distance is measured from centerline of support
arm assembly to centerline of support arm assembly (Fig. 2).
Mounting the Bottom Mounting Brackets
1. On the awning rail, mark the position of the centerlines of the support arm assemblies. Ensure that the
support arm assemblies will not interfere with any lights, vents or the operation of any windows or
doors.
2. Using a non-permanent method of marking, mark a perpendicular line from the awning rail down to
the floor line. This is the centerline of the support arm assembly (Fig. 2).
3. Position the bottom bracket with the fastening points at the floor line (Fig. 5A) and center the bracket
on the centerline mark of the support arm assembly (Fig. 5B). Mark the hole locations. Using a ⁄” drill
bit, pre-drill both holes. Apply a liberal amount of sealant over the holes and attach the bracket using
the ¼” x 2 ½” lag screws provided (Fig. 5).
NOTE: All screws supporting the awning assembly MUST have a backer within the structure of the wall of
the unit. Refer to the unit manufacturer for proper location.
4. Repeat step 3 for the other end of the awning.
A
B
Fig. 3 Fig. 4 Fig. 5
A
B

Rev: 06.05.18 Page 5 CCD-0001360
Mounting the Awning
1. Measure the distance from the awning rail channel to the lower mounting bracket fastening point.
2. Compare the distance from the center of the roll tube and the support arm assembly foot to the
measurement in Step 1 and adjust the support arm assembly to make both distances equal.
A. Open the support arm assembly handle (Fig. 6) and slide the outer arm lower channel (channel #2)
(Fig. 7) up or down as required. Close the handle and slide the outer arm lower channel (channel
#2) (Fig. 7) until the locking pin clicks into the nearest positioning hole.
Fig. 6 Fig. 7
Fig. 8
3. Use a screwdriver to spread open either end of the awning rail on the installation side (Fig. 8A).
4. To protect the fabric from damage during installation, file any sharp edges or burrs from the awning rail
channel.
5. Use silicone lubricant and spray the inside of the awning rail channel (Fig. 8B).
6. Remove the packaging from the fabric. Unroll a small portion of fabric, but not more than one turn.
NOTE: The next step will require three people: One to feed the polycord into the awning rail channel; two
to walk the support arm assemblies along the awning rail while the fabric slides into position.
7. Slide the polycord into the awning rail channel and walk the support arm assemblies and fabric down
the awning rail channel until the support arm assemblies are in line with the centerline marks made
previously.
8. Lift the support arm assembly up and secure the feet into the previously installed bottom mounting
brackets by pressing the lever and opening the latch (Fig. 9).
9. Slide the mount/rafter arm upper channel (channel #3) (Fig. 7) up or down as needed over the mount
arm lower channel (channel #4) (Fig. 7).
NOTE: If adjustments need made so the upper mounting brackets straddle the awning rail, loosen the
black locking knob on the mount/rafter arm upper channel (channel #3)(Fig. 7).
Channel
#1
Channel
#2
Channel
#4
Locking
Knob
Fig. 9
A
B
Channel
#3
Push
to
Open

Rev: 06.05.18 Page 6 CCD-0001360
Awning
Rail
Upper
Mounting
Bracket
Fig. 10
10. Center the upper mounting brackets on the support arm assembly centerline marked previously and
arrange the upper mounting brackets to straddle the awning rail. Tighten the black locking knob on
the mount/rafter arm upper channel (channel #3) (Fig. 7).
11. Once the upper bracket is located, mark and pre-drill two ⁄” holes through the awning rail or unit.
Apply a liberal amount of sealant over the holes and attach the upper mounting bracket using the ¼”
x 3” lag screws provided (Fig. 10).
NOTE: All screws supporting the awning assembly MUST have a backer within the structure of the wall of
the unit. Refer to the unit manufacturer for proper location. It is acceptable that the lag screws go
through the flat portion of the awning rail.
12. Repeat steps 9-11 for the other support arm assembly.
13. Place cam lock into the roll up position. Firmly grasp the roll tube and remove the safety cotter pin
from each end of the roll tube.
14. Flip the cam lock down to the roll in position and allow the fabric to slowly roll up.
Use care when removing the cotter pins. The cotter pins are holding the
pre-wound tension of the spring. Failure to securely hold the roll tube may allow the roll tube to
rapidly roll up and cause personal injury or damage.
Failure to maintain control of the roll tube, fabric and support arm assemblies may result in serious
injury or property damage.

Rev: 06.05.18 Page 7 CCD-0001360
Securing the Fabric
1. Extend and retract the awning several times to ensure that the fabric is square on the roll tube.
2. Secure the fabric in the awning rail no more than 1” inside the edge of the fabric on both ends using a #6 x
½” hex head screw. Install the screw down through the awning rail into the fabric and the polycord (Fig. 11).
Installing the Stop Bolt
1. Make sure the awning is retracted completely.
2. Make sure the centerline of the roll tube is level with or slightly higher than the centerline of the
awning rail (Fig. 2). The bottom of the roll tube MUST NOT be higher than the awning rail.
3. Adjust support arm assemblies if necessary.
A. Open the outer arm handle (Fig. 12) and slide the outer arm upper channel (channel #1) (Fig. 7)
up or down as required. Close the handle and slide the outer arm upper channel (channel #1) (Fig.
7) on the outer arm lower channel (channel #2) (Fig. 7) until the locking pin clicks into the nearest
positioning hole.
4. Mark the position of the stop hole that is directly below the outer arm upper channel (channel #1)
(Fig. 7).
5. From the inside of the outer arm lower channel (channel #2) (Fig. 7), insert a ⁄” bolt through the hole.
Secure with a star washer and ⁄” cap nut using ½” socket and wrench (Fig. 13).
NOTE: It may be necessary to lift the outer arm upper channel (channel #1) (Fig. 7) to tighten the cap nut.
6. Repeat step 4 and 5 for the other support arm assembly.
Fig. 11
Fig. 12 Fig. 13
Awning
Rail 1"
Fabric
Stitching

Rev: 06.05.18 Page 8 CCD-0001360
Notes

Rev: 06.05.18 Page 9 CCD-0001360
Notes

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from lci1.com.
Please recycle all obsolete materials.
