Lippert Taylor Made EasyGuide 2022106874 Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.09.23
Taylor Made®
EasyGuide™
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-007319
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Resources Required ................................... 2
Parts List ................................................ 2
Installation .............................................. 3
Taylor Made®
EasyGuide™
Installation and
Owner’s Manual
(For Aftermarket Applications)
EasyGuide KitEasyGuide Kit
Part #Part # DescriptionDescription
2022106874 EasyGuide Kit

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.09.23
Taylor Made®
EasyGuide™
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-007319
EasyGuide Kit #EasyGuide Kit # 202210 6874
LetterLetter DescriptionDescription QtyQty
A Float Top (Upper Float Housing) 2
B Float Bottom (Lower Float Housing) 2
C Upper Swing Arm 2
D Lower Swing Arm 2
E Trailer Plate 2
F #12 Screw 24
G 3/8” x 5” Pivot Bolt (Pin) and Nut 4
H 1/4” Arm Bolt and Nut 2
I Float Rest 2
J Sealant 1
Introduction
The Taylor Made EasyGuide watercraft loading system
uses floats attached to the trailer to help accurately align
the watercraft for easy unloading and loading. Boat trailer
guides designed for PWCs and boats up to 1,500 lbs.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/easyguide-by-taylor-made-2022106874 or by using
the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
Parts List
Resources Required
NOTE: Parts are shown for identification purposes only.
Not all parts are available for individual sale. All parts with
a link to the Lippert Store can be purchased.
A B
CD E
F
G
H
J
I
• 9/16” Wrench x 2
• Phillips screwdriver
• U-bolts as needed for 2”, 3” or 4” frames. Four total for the
Trailer Plates and two total for the Float Rest (if needed).
integral float
rest

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.09.23
Taylor Made®
EasyGuide™
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-007319
Installation
1. Inspect and identify the contents of the EasyGuide
carton. Remove all the molded components and the
fasteners supplied with the EasyGuide Kit.
2. Place the two float upper housing tops upside down
(on the EasyGuide logo) on a clean flat work surface. Note
the direction of the EasyGuide logo.
3. Clean the outside edges of both the upper and lower
float housings to remove any contaminates and/or grease or
oil on the sealing surfaces. Apply a bead of the sealant to
the sealing surface on the upper float housing. Also place
sealant in the screw holes on the lower float housing. Place
the lower float housing on the upper float housing and
install the twelve #12 screws per housing assembly. Torque
the screws to approximately 30 in.-lb. Do not over-tighten
the screws.
NOTE: The “E” shaped integral float rest on the lower
housing is to be at the rear of the float assembly. When
the assembly is completed. There should be a LH and RH
float assembly with the EasyGuide logo readable from
the outside of the trailer.
4. Identify the LH upper and LH lower arms (parts are
identied on the underside of the molded components)
(Fig.1). Press the splined male tab of the upper swing arm
into the slot of the lower swing arm.
NOTE: These components will assemble easier at room
temperature and above.
NOTE: The option configuration in Fig. 1 can be used if
more float adjustment is needed.
5. Press arms completely together and install the ¼” arm
bolts and self-locking nuts in the hex shaped pockets. Tighten
to approximately 50 in.-lb. Do not over-tighten. Repeat
these steps for the opposite side swing arm assembly. The
flat surfaces of the swing arm assemblies will be up in the
nal assembly onto the trailer.
6. Take two (2) U-bolts and place them through the desired
holes facing down. Place Trailer Plate on the trailer
slightly in front of axle. Take two (2) tie plates and place
them underneath the trailer onto the U-bolts and secure
with the nuts. DO NOT TIGHTEN TO TRAILER. Repeat
for other side.
7. Take the arm and locate the 1.5” tines (one side is 1” and
the other is 1.5”). Place the 1.5” side to the trailer plate and
secure it with 3/8” x 5” Pivot Bolt (Pin) (Fig.2). DO NOT
PUT THE NUT ON AT THIS TIME.
A
J
E
Fig.1
G
Fig.2
NOTE: To get a snug fit, the lower arms can be moved left
or right one tine on the trailer plate.
8. Take the float and hold it against the waterline on the
boat. Raise the arm to meet the float at the waterline. Once
the tines of the float and arm are connected place 3/8” x 5”
Pivot Bolt (Pin) through the hole. THE PIVOT (BOLT) PIN
SHOULD GO FROM THE INSIDE OUT. (THE THREADS
WILL BE ON THE OUTSIDE OF THE TRAILER.)
tines
trailer
plate
(3 Possible)

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.09.23
Taylor Made®
EasyGuide™
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-007319
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
9. To adjust the pressure of the float against the boat,
move the arm one (1) tine in or out on the float (Fig.3).
Also, the arm can be moved in or out one (1) tine on the
trailer plate, if needed. After moving float and trailer plate
to the desired position tighten the U-bolts to the trailer and
secure all the nuts to the arms. DO NOT OVER TIGHTEN
PIVOT BOLTS (PINS) (opposite arms can also be used
together for a better t for some watercrafts).
Fig.3
10. If your float adjustment puts your float o󰀨 of the trailer
frame, install float rest . Secure the float rest to the trailer
frame using a U bolt (Fig.4). The float rest can be inside or
outside of the trailer.
float
arm
trailer
plate
float rest position
(if needed)
Fig.4
I
11. The float should sit on the float rest in the down
position (Fig.5).
float rest
Fig.5
float
