Lissmac UNICUT 520 User manual

1/92
OPERATING MANUAL
FLOOR SAW
UNICUT 520
LISSMAC Maschinenbau GmbH
Lanzstrasse 4
D-88410 Bad Wurzach
Telefon [phone] / 307-0
Telefax +49 (0) 7564 / 307-500
[e-mail]
www.lissmac.com
EN

2/92

3/92
Legal notice This operating manual is valid for:
LISSMAC floor saw
UNICUT 520
Manufacturer:
LISSMAC Maschinenbau GmbH
Lanzstrasse 4
D - 88410 Bad Wurzach
Phone: [phone] / 307 – 0
Fax: [phone] / 307 – 500
[e-mail]
www.lissmac.com
Original operating manual
Issue date: 9-2018
This operating manual must not be disclosed or reproduced in any form or its contents used without
written permission to do so.
Breaches will result in claims for compensation. All rights reserved in the event of patent, registered
design or design patent registration.

4/92
BASIC SAFETY INFORMATION
Warning notes and symbols in this manual
SIGNAL WORD
Type and source of danger
Consequence of non-compliance.
Action to avert the danger
The signal word after the hazard symbol indicates the level of danger:
DANGER
This signal word indicates an extremely dangerous situation. If the situation is not avoided,
the consequence will be fatal injuries. The hazard symbol may give details of the danger.
WARNING
This signal word indicates a potentially dangerous situation. If the situation is not avoided, the
consequence may be fatal or serious injuries.
The hazard symbol may give details of the danger.
CAUTION
This signal word indicates a dangerous situation. If the situation is not avoided, the
consequence will be medium and minor injuries. The hazard symbol may give details of the
danger.
NOTICE
This signal word indicates a situation which may present a danger for property. If the situation
is not avoided, the consequence will be property damage. This signal word is shown without a
hazard symbol.
Important information is marked with an "i".
Request for the operator to take action:
The specified sequence of the action steps facilitates the proper and safe handling of the
machine.
Instructions for the operator
The warning notes contained are not exhaustive.
Lissmac cannot foresee every potential hazard.
Reasonable safety rules and precautions must be followed as with any other machine,
in terms of working methodology and operation.

5/92
Warning and safety notes used:
Read the operating manual
Wear hearing protection
Wear safety goggles
Wear work gloves
Wear safety gloves
Wear protective helmet
Wear work clothes and wash regularly
/ Attachment point for crane transports
Remove the ignition key before working on the unit
Cutting hazard at the rotating tool
Wait for all parts to stop
Do not relocate the machine with rotating tool
Extremely flammable fuel vapors
Crush hazard
Ejected parts hazard
Suspended load hazard
Burn hazard

6/92
Suffocation hazard from of toxic exhaust gases.
High pressure injection hazard.
Warning of electric shock due to damaged power lines.
Battery hazards
Explosion hazard
Do not use high pressure cleaners
Use by unauthorized persons not permitted
No step area
No Smoking
Lashing point for vehicle transport
Instruction for damage prevention.
Sound power level of the machine

7/92
OPERATING MANUAL
Preface This operating manual is designed to make it easy to familiarize yourself with the machine and use it
for its intended purpose.
The operating manual contains important information on how to operate the machine safely, properly
and economically. Compliance with it will help to avoid dangers, repair costs and downtimes and
increase the reliability and service life of the machine.
The operating manual is to be supplemented by instructions due to existing national regulations for
accident prevention and environmental protection.
The operating manual must be available at the location of the machine at all times.
The operating manual must be read and used by everybody who undertakes work on the machine, for
example:
Operation, including setting, troubleshooting whilst operating, removal of production waste,
care, disposal of media and consumables
Maintenance (servicing, inspection and repair) and/or
Transport
.
In addition to the operating manual and the binding regulations for accident prevention which apply in
the user's country and at the place of use, the acknowledged rules for safe and correct working
practice must also be observed.
Tools required A tool in the form of a saw blade is required for operating the floor saw. These tools can be purchased
from the manufacturer.
Further documents In addition to this operating manual, further documentations from the respective manufacturer of
individual components of the machine are available:
Internal combustion engine operating manual
For completeness regarding further documentation, LISSMAC does not assume responsibility or liability
regarding their completeness.
Changes and reservations We have taken every effort to ensure that this operating manual is correct and up to date. To keep our
technological lead over our competitors, it may be necessary to make modifications to the product and
its operation without prior notice. We cannot accept any liability for faults, failures and resulting
damage.

8/92
Notes

9/92
Table of contents
1. Features & Benefits ....................................................................................................... 11
2. General safety notes...................................................................................................... 12
2.1. Principle of intended use ................................................................................................12
2.2. Organizational measures ................................................................................................13
2.3. Choice of personnel and - qualification; fundamental obligations.................................. 14
2.4. Safety notes regarding the operating phases ................................................................. 14
2.4.1. Transport, assembly and installation ..................................................................... 14
2.4.2. Commissioning.......................................................................................................15
2.4.3. Operation ............................................................................................................... 15
2.4.4. Relocating the floor saw ........................................................................................ 16
2.4.5. Special work while using the machine .................................................................. 16
2.5. Note relating to special types of danger......................................................................... 16
2.5.1. Dangers for the operator from the machine........................................................... 16
2.5.2. Electrical Energy ....................................................................................................17
2.5.3. Dust........................................................................................................................17
2.5.4. Noise...................................................................................................................... 17
2.5.5. Exhaust gases ........................................................................................................ 17
2.6. Transport.........................................................................................................................17
2.7. Packing and storage........................................................................................................18
2.8. Environmental protection................................................................................................18
2.9. Waste disposal ............................................................................................................... 18
3. Device Description......................................................................................................... 19
3.1. Designation of machine parts ......................................................................................... 19
3.2. Connections/interfaces...................................................................................................20
3.3. Technical specifications.................................................................................................. 21
3.4. Sound power level ..........................................................................................................22
3.5. Exhaust fumes ................................................................................................................22
3.6. Hand-Arm vibration......................................................................................................... 23
4. Commissioning............................................................................................................... 24
4.1. Connections and media .................................................................................................. 24
4.2. Tools (saw blade)............................................................................................................24
4.3. Water pump....................................................................................................................25
4.4. Refueling.........................................................................................................................25
4.5. Saw blade installation/changel (tool)............................................................................. 26
4.6. Conversion of seat position (Optional) ............................................................................ 27
5. Control desk ................................................................................................................... 28
5.1. Joystick........................................................................................................................... 29
5.2. HMI Control unit .............................................................................................................31
5.2.1. Dashboard..............................................................................................................32
5.2.2. Pre-selection page 1 ..............................................................................................33
5.2.3. Water guard...........................................................................................................33
5.2.4. Pre-selection page 2 ..............................................................................................34
5.2.5. Fault memory .........................................................................................................35
5.2.6. Overview................................................................................................................ 36
5.2.7. Display settings ..................................................................................................... 37
5.2.8. Service menu ......................................................................................................... 38
5.2.9. Software adjustment ............................................................................................. 38
6. Transport........................................................................................................................ 39
6.1. Transport position........................................................................................................... 39
6.2. Maneuvering in cutting or rapid traverse mode.............................................................. 40
6.3. Relocating using a crane................................................................................................. 42
6.4. Securing machine for road transport .............................................................................. 43
7. Operation........................................................................................................................ 44
7.1. Safety .............................................................................................................................44
7.2. Maneuvering the floor saw............................................................................................. 46
7.3. Cutting with the floor saw ..............................................................................................46
7.4. Initiating the cutting sequence (main cut)...................................................................... 47
7.5. Comfort Mode................................................................................................................. 48
7.6. Setting toe in ..................................................................................................................49
7.7. Safe machine shutdown ................................................................................................. 50
8. Conversion options ........................................................................................................ 51

10/92
8.1. Conversion from left- to right-cutting ............................................................................. 51
8.2. Tilting the slider box .......................................................................................................52
8.3. Off-setting the slider box ................................................................................................ 53
8.4. Other adjustment options ............................................................................................... 54
9. Lateral cutting unit -Optional- ...................................................................................... 55
9.1. Lateral cutting unit..........................................................................................................55
9.2. Initiating cutting sequence (Lateral cutting) ................................................................... 56
9.3. Saw blade installation / change for side cutting unit (tool)............................................ 58
10. Diesel Particulate filter (DPF) -Optional-..................................................................... 59
11. Maintenance ................................................................................................................ 60
11.1. Servicing ....................................................................................................................... 60
11.2. Maintenance intervals ..................................................................................................61
11.3. Air filter clogged ...........................................................................................................62
11.4. Cleaning the water pump.............................................................................................. 63
11.5. Access to maintenance hatch with laterals cutting unit installed ................................ 64
11.6. Fuses.............................................................................................................................65
11.7. Battery ..........................................................................................................................67
11.8. Lube points ...................................................................................................................68
11.9. Troubleshooting ............................................................................................................70
11.10. Support and training ................................................................................................... 70
11.11. Torque values of screw connections........................................................................... 71
11.12. Maintenance schedule................................................................................................ 72
12. Tools ............................................................................................................................. 73
13. Warranty....................................................................................................................... 74
14. Circuit diagram............................................................................................................. 76
15. Hydraulic Diagram (scematic)..................................................................................... 87
16. Error codes................................................................................................................... 90

11/92
1.
FEATURES & BENEFITS
Many years of experience and cooperation with professional users have led to the development of the
UC520. This floor saw is a single device that allows carrying out a variety of jobs.
Easy operation - thanks to the multifunctional joystick
Optimized hydraulic circuit through electro-hydraulic steering, thus higher power transmission
to the saw blade
Traction drive and saw blade speed are electro-hydraulically adjustable - optimum cutting
speed of the saw blade
Optimum weight distribution - low center of gravity
Large sized fuel tank reduces downtime
Quick change from left to right cut - 180 degree swiveling
Large, non-marking drive wheels
Diagonal cuts to the inside and outside possible up to 15 degrees
Slide box can be moved outwards by 150 mm or 200 mm. Additionally the height of the slide
box can be adjusted 150 mm
The blade guard is hydraulically height-adjustable, independent of the saw motor
All settings can be made on the central display and all engine values can be read on the display
Easy access for common maintenance (air filters, oil and fuel filters)
The UNICUT 520 complies with the emission regulations of EU Stage IIIB Flex / US EPA Tier 4i

12/92
2.
GENERAL SAFETY NOTES
2.1. Principle of intended use
The manufacturer and supplier does not assume any liability in case of incorrect or unintended use.
The machine must not be modified by anybody other than the manufacturer. Changes due to
attachments or conversions on the floor saw require the written approval of the manufacturer.
The machine is built according to the state of the art and the recognized safety-related rules.
Nevertheless its use may result in dangers of injury and death of the user or third parties or adverse
effects to the machine and other property.
The machine must only be used if it is in technically perfect condition and for its intended use, with an
awareness of safety and potential dangers and as set out in the operating manual. In particular, faults
which may adversely affect its safety must be rectified immediately.
Intended use The LISSMAC floor saw belongs to the floor cutting grinder and is designed exclusively for cutting
joints in concrete or asphalt with the help of water. The cutting includes saw blades and may only be
used for cutting on the ground. The floor saw may only be operated by one person. The operator must
remain in the driver's seat of the floor saw as long as the machine is running. Any use other than this
will be deemed unintended.
Intended use also includes compliance with the operating manual and compliance with the inspection
and maintenance manual.
Unintended use Foreseeable misapplications / unintended use:
Cutting without blade guard
Cutting without water
Cutting on steep slopes
The cutting of narrow radii
Cutting wood, plastics or metal
(except reinforced concrete)
Design modifications which alter the safety or design type of the floor saw

13/92
2.2. Organizational measures
This operating manual must be kept within easy reach for everyone at the place of use.
Supplements to the operating manual include general statutory and other binding regulations for
preventing accidents and protecting the environment and must be obeyed.
These duties may also relate, for example, to handling hazardous substances or wearing personal
protective equipment or road traffic regulations.
The personnel assigned with activities at the machine must have read and understand the operating
manual before starting work, and here particularly the chapter safety notes. This particularly applies
to personnel who only work on the machine occasionally, for example setting and maintenance
personnel.
Regularly check that the procedures used by the personnel are safe and show an awareness of the
dangers and that they are following the instructions in the operating manual.
Always use the required and prescribed personal protective equipment.
Observe all safety and danger notes at the floor saw and keep them in readable condition. Replace
any damaged or illegible safety information and warnings.
With safety-related changes of the machine or its operational behavior, shut the machine down
immediately and mark it accordingly. Report the fault to the responsible body/person.
Do not make any changes, by attachment or conversions without written permission of the
manufacturer. The instructions provided by the tool manufacturer must be given due consideration.
Use only checked original spare parts of the manufacturer.
Adhere to prescribed periods for inspection or those specified in the operating manual.
For the implementation of maintenance measures, workshop equipment appropriate for the work is
absolutely necessary.
Machines with internal combustion engines must not be used in closed rooms.
Always obtain detailed information on underground cables in the cutting area and take appropriate
precautions before cutting.

14/92
2.3. Choice of personnel and - qualification; fundamental obligations
Operators must be aged 18 or above and they must be mentally and physically capable of operating
the floor saw. All persons must be instructed in the operation and be expressly assigned by the
employer with the operation of the floor saw.
Specify the responsibilities of the personnel for operating, setting up, maintenance and repairs.
Ensure that only authorized personnel works on the machine.
The operator must wear personal protective equipment such as safety shoes, gloves, safety goggles
and hearing protection, which comply with the safety regulations.
Expel persons not working with the machine from the work area. Cordon off the working area if
necessary.
The operator must ensure with all movements of the floor saw that he does not endanger himself and
other persons. All obstructions which hinder the work procedure or the implementation of the machine
must be cleared at the place of work.
Work on the electrical equipment on the machine may only be carried out by a qualified electrician or
by trained personnel under the management and supervision of a qualified electrician and in
compliance with the electronic regulations.
The operator must be named as the person responsible for traffic-related regulations and make it
possible for him to reject unsafe instructions by third parties.
Only allow personnel being trained, instructed or those completing an apprenticeship to work on the
machine under the constant supervision of an experienced person.
2.4. Safety notes regarding the operating phases
2.4.1. Transport, assembly and installation
Transport, set-up and installation on/with the floor saw must only be carried out in transport position.
The floor saw must be secured against rolling away.
Transport, set-up and installation on/with the floor saw must only be carried out with the saw blade
removed and the motor switched off.
Use a crane to load and unload the floor saw, taking into account the maximum operating weight.
Transport may only take place, if all parts at the machine are tightened and dropping of individual
parts is impossible.

15/92
2.4.2. Commissioning
Check the direction of rotation when fitting the saw blade. The cutting process must always be done in
synchronism (pointing downwards); otherwise, the material breaks and small parts are hurled around.
When fitting the saw blade, protect your hands from sharp edges.
Make sure the substrate that is used for cutting meets the load-bearing capacity. All obstacles must be
removed from the cutting area and good lighting must be provided.
Visual check of the entire floor saw for any damage and defects. Separate check of the protective
devices.
Supply water for saw blade cooling.
Smoking is prohibited when refueling the internal combustion engine.
Particular care should be taken when refilling the fuel tank. Engine parts that became hot during
operation pose a fire hazard.
Fuel must only be stored in approved containers.
No rotating tool, whose maximum speed is lower than the rated speed of the machine, must be used.
Defective or broken tools must be replaced immediately.
2.4.3. Operation
Do not use any unsafe method of working.
Take measures to ensure that the floor saw is only used if it is safe and in functional condition.
Check the floor saw at least once per shift for external signs of damage and defects. Notify the
responsible place/person immediately when changes have occurred (including the operational
behavior). If necessary, shut down the machine immediately and secure it to prevent it being switched
on again.
If the floor saw malfunctions, shut it down immediately and secure it. Have faults eliminated
immediately. Electrical installation work may only be accomplished by trained electrical personnel.
Only use suitable and checked tools.
To protect against acceleration, the depth adjustment of the saw blade must be moved slowly and in
steps into the ground. Any contact with the rotating tool must be avoided. Keep a safety distance of
1.5m to the saw blade.
Cutting without the blade guard or drive belt cover is prohibited.
The operator must be protected from rotating parts.
In case of fire, persons must follow the operator's fire protection instructions.

16/92
2.4.4. Relocating the floor saw
The floor saw may only be relocated when the saw blade is stationary.
Before leaving the operating position on the floor saw, the internal combustion engine must be
switched off and the saw blade must be stationary.
There is a risk of injury from a rotating saw blade.
2.4.5. Special work while using the machine
Observe the adjustment, maintenance and inspection work and intervals specified in this operating
manual including the details for replacing parts/ parts of the equipment. These activities may only be
accomplished by authorized technical personnel.
When the floor saw has been shut down completely for maintenance and repair work, it must be
secured and marked to prevent it being accidentally switched on again.
Before cleaning, cover and seal all openings, into which no cleaning agent may penetrate for safety
and/or function reasons. Electric motors, switches and plug connectors are at particular risk. Remove
the covers/masking tape completely after finishing the cleaning work.
Always tighten screw connections rendered loose during maintenance and repair work.
If the disassembly of safety devices is necessary with the start-up, maintenance and repair, the
assembly and check of the safety devices must take place immediately after conclusion of maintenance
and repair work.
No rotating tool, whose maximum speed is lower than the rated speed of the machine, must be used.
2.5. Note relating to special types of danger
2.5.1. Dangers for the operator from the machine
Before leaving the operating position on the floor saw, the internal combustion engine must be
switched off and the saw blade must be stationary.
There is a risk of injury from a rotating saw blade.
The internal combustion engine of the floor saw must only be used as intended:
Drive of the floor saw and the saw blade are put into operation.
Depending on the seating position, the exhaust system may be unfavourable for the operator.
The outlet of the exhaust pipe must always point away from the operator. Do not inhale exhaust fumes.
The exhaust pipe gets hot during operation. Avoid contact and wear protective equipment.

17/92
2.5.2. Electrical Energy
Only use original fuses with the prescribed amperage. The floor saw must be switched off
immediately in the event of faults. Electrical work may only be carried out by certified and qualified
technical personnel.
The electrical equipment of a machine must be inspected/checked at regular intervals. Defects such
as loose connections and damage cables must be rectified immediately. The machine must be marked
to ensure that it will not be started by others.
2.5.3. Dust
With work in confined spaces, observe existing national regulations, if necessary.
To prevent dust formation and provide cooling during cutting, the saw blade must be continuously
sprayed with water. Dry cutting is prohibited. Do not eat, drink or smoke in the work area.
2.5.4. Noise
see section: 3.4
2.5.5. Exhaust gases
Machines with internal combustion engine must not be operated indoors or in confined spaces.
2.6. Transport
Lifting gear of sufficient load-bearing capacity must be used when transferring by crane. Check lifting
gear beforehand for any damage.
Appoint an expert instructor for the hoisting work.
Only lift the floor saw as described in the operating manual using lifting gear.
Only use a suitable transport vehicle with an adequate load-bearing capacity.
Secure the load properly in compliance with the regulations. Use suitable lashing points.
The engine of the floor saw must be switched off even for a minor change of location. The blade must
not rotate when restarted directly.

18/92
2.7. Packing and storage
In order to ensure sufficient protection during dispatch and transport, the machine and its components
were packed carefully. The machine should be checked for damage upon receipt. The machine's
packaging consists of recyclable materials. Please sort them into different materials and place them in
the appropriate containers so that they can be recycled.
Do not start the machine if it is damaged. Damaged cables and plug connectors also pose a safety risk
and must not be used. In this case notify the manufacturer immediately.
If the machine is not operated immediately after unpacking, it must be protected against humidity and
dirt.
2.8. Environmental protection
Packaging material, cleaning products, used or residual media and unpacked wearing parts such as
drive belts or engine oil must be recycled in accordance with the environmental protection regulations
in force at the place of use.
2.9. Waste disposal
When the device reaches its end of life, particularly if it starts to malfunction, render it inoperable.
Dispose of the device according to the environmental regulations valid in your country. Electrical
waste may not be disposed of together with household waste. Deposit the end-of-life device at a
central collection point.

19/92
3.
DEVICE DESCRIPTION
3.1. Designation of machine parts
Pos. 1 Steering rod Pos. 7 Control panel
Pos. 2 Blade guard Pos. 8 Driver seat
Pos. 3 Suction shoe Pos. 9 Control unit compartment
Pos. 4 Footboard Pos. 10 Exhaust pipe
Pos. 5 Cutline indicator Pos. 11 Steering rod
Pos. 6 Mounting rail for suction unit Pos. 12 Engine cover
1
9
8
7
6
5 4
2
3
10
11
12

20/92
3.2. Connections/interfaces
Power
Item 1 Socket water pump 12V (15A) switchable
Item 2 Socket 1 12V (10A) switchable
Item 3 Socket 2 12V (10A) switchable
Item 4 Socket 3 12V (10A) switchable
Item 5 Socket 4 12V (10A) switchable
Item 6 Socket 5 12V (10A) constant current
Water
Item 7 Water connection (max. 5 bar)
Diagnosis
Item 8 Connecting plug diagnosis (only for service)
Controller
Item 9 Control desk connection
Hydraulics
Item 10 Hydraulics P (pressure)
Item 11 Hydraulics T (tank)
Item 12 Hydraulics leaking oil
Motor
Item 13 Ambient air temperature sensor
2 3 5 6
7
1110
9 12
4
8
1
13
