Litex Industries VN52 User manual

Installation Guide
For Model:
VN52
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Light Kit Assembly (Optional). pgs. 7- 8
Testing Your Fan. pg. 9
Troubleshooting. pg. 10
Parts Replacement. pg. 10
Warranty. pg. 10
net weight of fan: 17.22 lb. (7.81 kg)
E124404
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
PRINTED IN CHINA

SAFETY TIPS.
page 1
WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit
panel before you begin the fan installation or before servicing the fan or installing accessories.
1. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN
AND SAVE THESE INSTRUCTIONS.
CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp
edges.
2. Make sure all electrical connections comply with Local Codes or Ordinances, the National Electrical Code,
and ANSI/NFPA 70-199. If you are unfamiliar with electrical wiring or if the house/building wires are
different colors than those referred to in the instructions, please use a qualified electrician.
3. Make sure you have a location selected for your fan that allows clear space for the blades to rotate, and at
least seven (7) feet (2.13 meters) of clearance between the floor and the fan blade tips. The fan should
be mounted at least thirty (30) inches (76 centimeters) from walls or other upright structures.
4. The outlet box and ceiling support joist used must be securely mounted, and capable of supporting at
least 35 pounds (16 kilograms). The outlet box must be supported directly by the building structure.
Use only UL listed outlet boxes marked "FOR FAN SUPPORT."
WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount to the outlet box marked
"Acceptable for Fan Support of 15.9 kg (35 lb) or less" and use the mounting screws provided with the outlet box.
Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support and
may need to be replaced. Consult a qualified electrician if in doubt.
WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan
are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your house wire is
larger than 12 gauge or there is more than one house wire to connect to the two fan lead wires, consult an
electrician for the proper size wire connectors to use.
5. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and
marked suitable for use with the model fan you are installing. Switches must be UL general use
switches. Refer to the instructions packaged with the light kits and switches for proper assembly.
6. After installation is complete, check that all connections are absolutely secure.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the
equipment-grounding conductor on opposite sides of the outlet box.
WARNING: To reduce the risk of electrical shock or fire, do not use this fan with any solid state speed control
device or control fan speed with a full range dimmer switch. [Using a full range dimmer switch to control fan
speed will cause a loud humming noise from fan.] (Note: This fan is suitable for use with remote control.)
8. Do not operate the reverse switch until the fan has come to a complete stop.
9. Do not insert anything between the fan blades while they are rotating.
WARNING: To reduce the risk of personal injury, do not bend the blade arms during assembly or after
installation. Do not insert objects into the path of the blades.
WARNING: To avoid personal injury or damage to the fan and other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan blades.A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER
than those provided with this fan will void the warranty.
NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense and caution are
necessary factors in the installation and operation of this fan.

1. Unpacking Your Fan.
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket (pre-attached to canopy).
1 piece
c. downrod and hanging ball (with pin and clip).
1 piece
d. motor housing. 1 piece
e. blade arm. 5 pieces
f. blade. 5 pieces
g. light kit fitter. 1 piece
h. finial plate (pre-attached to light kit fitter).
1 piece
ifinial (pre-attached to light kit fitter). 1 piece
j. glass shade. 1 piece
k. hardware packs
page 2
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
bulbs required:
2 x 6.5 watt medium base LED bulbs
(included)
abc
k
j
i
f
h
g
d
e

3. Installation Preparation.
page 3
ON
OFF
ON
OFF
hanging bracket
spring washers
outlet box screws
flat washers
To prevent personal injury and damage, ensure that
the hanging location allows the blades a clearance
of 7ft. (2.13m) from the floor and 30in. (76cm) from
any wall or obstruction.
This fan is suitable for room sizes up to 400 square
feet (37.2 square meters).
This fan can be mounted with a downrod on a
regular (no-slope) or vaulted ceiling.The hanging
length can be extended by purchasing a longer
downrod (0.5in./1.27cm diameter). After installing
hanging bracket, continue to Section 5, page 4 for
those instructions. This fan can also be mounted as
a flushmount only on a regular (no-slope) ceiling.
After installing hanging bracket, continue to Section 6
on page 5 for those instructions.
Installation requires these tools:
Phillips screwdriver, flat-head screwdriver, adjustable
pliers or wrench, stepladder, wire cutters and rated
electrical tape.
Vaulted ceiling
angle is not to
exceed 25 degrees.
downrod
installation
flushmount
installation
12ft. - 20ft.
12ft. - 20ft.
(3.66m - 6.1m)
(3.66m - 6.1m)
7 feet
(2.13m)
(76cm)
30
inches
4. Hanging Bracket Installation.
blade edge
Turn off circuit breakers to current fixture from breaker panel
and be sure operating light switch is turned to the OFF
position.
WARNING: Failure to disconnect power supply prior to
installation may result in serious injury.
Remove existing fixture.
WARNING: When using an existing outlet box, be sure the outlet
box is securely attached to the building structure and can
support the full weight of the fan. Ensure outlet box is clearly
marked "Suitable for Fan Support." If not, it must be replaced
with an approved outlet box. Failure to do so can result in
serious injury.
CAUTION: Be sure outlet box is grounded properly and that a
ground wire (GREEN or bare) is present.
Partially loosen screws in slotted holes of canopy. Remove
the other 2 screws and star washers--save for later use. Twist
canopy to remove hanging bracket.
Install hanging bracket to outlet box using original screws,
spring washers and flat washers provided with new or
original outlet box. *If installing on a vaulted ceiling, face
opening of hanging bracket towards high point of ceiling.
Arrange electrical wiring around the back of the hanging
bracket and away from the hanging bracket opening.
*Note: It is very important that you use the proper hardware
when installing the hanging bracket as this will support the fan.

page 4
5. Fan Assembly.
If you wish to extend the hanging length of your
fan, you must remove the hanging ball from the
downrod provided to use with an extended
downrod (sold separately). [If you wish to use the
downrod provided, please proceed to instructions
following the dotted line below.]
To remove hanging ball, loosen set screw on
hanging ball and remove the pin and clip. Lower
hanging ball and remove stop pin. Slide hanging
ball off the original downrod, A, and slide it
down the longer downrod, B (the top of the
downrod should be noted as having a set screw
hole; use this hole when setting the set screw).
Insert stop pin into top of extended downrod
and raise hanging ball. Be sure stop pin aligns
with slots on the inside of the hanging ball.
Tighten set screw securely.
Tip: To prepare for threading electrical wires
through downrod, apply a small piece of
electrical tape to the ends of the electrical
wires--this will keep the wires together when
threading them through the downrod.
Loosen yoke set screws and nut at top of motor
housing. Remove pin and clip from downrod (if
you have not already done so). Slide downrod
through canopy.
Thread electrical wires through downrod and pull
extra wire slack from the upper end of the
downrod.
Place downrod into the motor housing yoke and
re-insert pin and clip that were previously
removed. Tighten yoke set screws and nut
securely. Lower canopy to motor housing.
["Fan Assembly" continued on next page.]
NOTE: The important safety precautions and
instructions appearing in the manual are not meant to
cover all possible conditions and situations that may
occur. It must be understood that common sense and
caution are necessary factors in the installation and
operation of this fan.
set screw hole
set screw
hanging ball
stop pin
pin
clip
A
B
yoke set screw
downrod
electrical wiring
clip
pin
canopy
motor
housing

5. Fan Assembly. (cont.)
page 5
6. Fan Assembly (flushmount).
With the hanging bracket secured to the outlet
box and able to support the fan, you are now
ready to hang your fan. Grab the fan firmly with
two hands. Slide downrod through opening in
hanging bracket and let hanging ball rest on
hanging bracket. Turn hanging ball until slot lines
up with hanging bracket tab.
Tip: Seek the help of another person to hold the
stepladder in place and to lift the fan up to you
once you are set on the ladder.
Continue to "Wiring" section for wiring diagram.
canopy
canopy cover
canopy
motor housing
yoke
Remove and set aside canopy cover to reveal 6
holes. Notice that 3 holes are larger than the rest
of them.
If there are only 3screws in top of motor
housing, please proceed to next paragraph. If
there are 6screws in top of motor housing,
remove every other screw and lock washer.
Thread wiring through canopy. Place canopy
over yoke, aligning larger holes in canopy with
the 3 existing screws in top of motor housing.
Insert the 3 screws and 3 lock washers that had
been removed (if there were only 3 screws
located in top of motor housing, these
screws/lock washers will be located in one of the
hardware packs) into the remaining holes.
Securely tighten these screws.
To prepare the fan for wiring, hang fan onto
hanging bracket by sliding the canopy over the
hanging bracket tab. (Use one of the non-slotted
holes on the rim of the canopy to do so.)
canopy
motor housing
hanging bracket tab
hanging ball slot
hanging bracket tab

page 6
8. Canopy Assembly.
7.Wiring.
black
black
from fan
from ceiling
white
white
blue
black supply wire
ground
(green
or bare)
white supply wire
CAUTION: Be sure outlet box is properly grounded
and that a ground wire (GREEN or Bare) is present.
Make sure all electrical connections comply with
Local Codes or Ordinances and the National
Electrical Code. If you are unfamiliar with electrical
wiring or if the house/building wires are different
colors than those referred to below, please use a
qualified electrician.
When downrod is secured in place on the
hanging bracket, electrical wiring can be made
as follows:
Connect BLACK and BLUE wire from fan to
BLACK wire from ceiling with wire connector
provided.
Connect WHITE wire from fan to WHITE wire
from ceiling with wire connector provided.
Connect all GROUND (GREEN) wires together
from fan to BARE/GREEN wire from ceiling with
wire connector provided.
If you intend to control the fan light with a
separate light switch, connect BLUE wire from
fan to the BLACK supply from the independent
switch.
* Wrap each wire connector separately with
electrical tape as an extra safety measure.
*
ground
(green or bare)
Raise canopy to hanging bracket, aligning
slotted holes in canopy with loosened screws
in hanging bracket.Twist canopy to lock.
Insert screws (along with star washers)
previously removed (on page 3, Section 4)
and secure all screws with a Phillips
screwdriver. canopy
hanging bracket
This fan is remote control adaptable
(remote control sold separately).

page 7
10. Light Kit Assembly (Optional).
Remove 3 screws and star washers from switch
housing cap at top of light kit fitter.
If you wish to use your fan WITH the light kit,
remove finial, finial plate, hex nut and rubber
washer from bottom of light kit fitter. Save finial,
finial plate,hex nut and rubber washer for later use.
Locate BLUE and WHITE wires in the switch
housing labeled FOR LIGHT KIT CONNECTION.
Remove and discard cardboard label and plastic
that hold these 2 wires together.
Connect WHITE wire from switch housing to
WHITE wire from light kit fitter. Connect BLUE wire
from switch housing to BLACK wire from light kit
fitter. Be sure molex connections snap together
securely.
Align holes in switch housing cap with holes in
switch housing and attach light kit fitter to switch
housing with 3 screws previously removed. (Note:
The gap on the top edge of the switch housing cap
must align with the reverse switch on the switch
housing for proper fit.) Secure all 3 screws with a
Phillips screwdriver.
["Light Kit Assembly" continued on next page.]
9. Blade Assembly.
WARNING: To reduce the risk of serious bodily
injury, DO NOT use power tools to assemble the
blades. If overtightened, blades may crack and break.
Time Saver: Washers for blade screws can be set on
each blade screw prior to installing blades.
Locate 15 blade attachment screws and washers in
one of the hardware packs. Hold blade arm up to
blade and align holes. Insert 3 blade attachment
screws (along with washers) with fingers first, and
then tighten screws securely with a Phillips
screwdriver. Repeat procedure for remaining blades.
Remove blade arm screws and lock washers from
underside of motor (save blade arm screws and lock
washers to secure blade arms). Align blade arm holes
with motor screw holes and attach blade arm with
lock washers and blade arm screws. Before securing
screws permanently, repeat this procedure with
remaining blade arms. Secure all screws.
Note:Tighten blade arm screws twice a year.
switch housing
molex connections
light kit fitter
switch housing
cap
blade arm screws
lock washers
motor housing
blade arm
blade
blade attachment
screws and washers

page 8
10. Light Kit Assembly (Optional).(cont).
Install two 6.5 watt medium base LED bulbs (included).
Important: When replacing bulbs, please allow bulbs
and glass shade to cool down before touching.
Raise glass shade in order to guide pull chains through
appropriate holes in glass shade. Align threaded rod on
light kit fitter with hole in middle of glass shade and
push up gently allowing threaded rod to come through
hole. (Be sure pull chain for fan operation does not rub
against bulb during operation.) Replace rubber washer
and hex nut on threaded rod.Tighten hex nut but DO
NOT OVERTIGHTEN hex nut as glass may crack or break.
Align hole in center of finial plate with threaded rod,
allowing pull chains to come through appropriate
holes in finial plate, and push up.Thread center pull
chain through hole in finial and secure glass shade to
light kit fitter by tightening finial. Do NOT overtighten
finial as glass may crack or break.
If you wish to use your fan WITHOUT the light kit,
remove hex nut and lock washer from threaded rod at
top of light kit fitter. Unscrew switch housing cap to
remove it from the light kit fitter.Then, gently feed
BLACK and WHITE wires from light kit fitter through
hole in middle of switch housing cap.
Locate cap in one of the hardware packs and place cap
firmly into hole in middle of switch housing cap.
Align holes in switch housing cap with holes in switch
housing. Secure switch housing cap with 3 screws (and
star washers) removed at the beginning of Step 10,
page 7. Tighten all 3 screws securely.
finial plate
glass shade
finial
threaded rod
light kit fitter
fan pull
chain extension
light pull
chain extension
switch housing
rubber washer
switch housing cap
light kit fitter
WHITE BLACK
hex nut
lock washer
switch housing cap
cap
switch housing
bulb
hex nut

page 9
11.Testing Your Fan.
It is recommended that you test fan before
finalizing installation. Restore power from
circuit box and light switch (if applicable).
Test fan speeds with the pull chain on the
switch housing. Start at the OFF position (no
blade movement). First pull will set the fan to
HI. Second pull will set the fan to MEDIUM.
Third pull will set the fan to LOW. Fourth pull
will again set the fan to the OFF setting.Test
light with the pull chain in the middle. (Refer
to diagram 1.) If fan and/or light do (does)
not function, please refer to
"Troubleshooting" section to solve any issues
before contacting Customer Service.
Turn fan completely off before moving the
reverse switch. Set reverse switch to
recirculate air depending on the season:
- DOWN position in summer (diagram 2)
- UP position in winter (diagram 3)
A ceiling fan will allow you to raise your
thermostat setting in summer and lower
your thermostat setting in winter without
feeling a difference in your comfort.
Important: Reverse switch must be set either
completely UP or completely DOWN for fan to
function. If the reverse switch is set in the
middle position (diagram 4), fan will not
operate.
Attach pull chain extension(s) supplied or
custom pull chain extension(s) (sold
separately) to end(s) of the pull chain(s).
diagram 2 diagram 3 diagram 4
diagram 1
switch housing
fan pull chain
light pull chain
reverse switch

page 10
Troubleshooting. Warranty.
Problem: Fan fails to operate.
Solutions:
1. Check wall switch to fan.
2.Verify that reverse switch is set completely in
either direction.
3. Check to be sure fan is wired properly.
Problem: Light kit (optional) not lighting.
Solutions:
1. Check wall switch to fan.
2. Check that bulbs are installed correctly.
3. Check to be sure wires in canopy are wired
properly.
4.Verify that molex connections in switch
housing are connected properly.
Problem: Fan operates but light fails (if
applicable).
Solutions:
1. Check that bulbs are installed correctly.
2. Check to be sure wires in canopy are wired
properly.
3.Verify that molex connections in switch
housing are connected properly.
4. Replace defective bulbs with same type of
bulb.
Problem: Fan wobbles.
Solutions:
1. Use the balancing kit provided in one of the
hardware packs. If no blade balancing kit is
provided, please call Customer Support,
1-800-527-1292, to request one.
2. Check to make sure set screw(s) on motor
housing yoke is (are) tightened securely.
3. Check to be sure set screw on hanging ball is
tightened securely.
Parts Replacement.
For parts and information, please refer to
"Parts Inventory" on page 2.
Litex Customer Support:
1-800-527-1292
WARNING: Failure to disconnect power supply
prior to troubleshooting any wiring issues may
result in serious injury.
LITEX LIFETIME LIMITED WARRANTY:
LITEX INDUSTRIES, LTD. warrants this fan to the original
household purchaser for indoor use under the following
provisions:
1-YEAR WARRANTY: LITEX INDUSTRIES, LTD.will replace or
repair any fan which has faulty performance due to a
defect in material or workmanship.Contact Litex Customer
Service at 1-800-527-1292 to arrange for return of fan.
Return fan, shipping prepaid, to Litex Industries, Ltd.We will
repair or ship you a replacement fan, and we will pay the
return shipping cost.
5-YEAR WARRANTY: LITEX INDUSTRIES, LTD.will repair or
replace, at no charge to the original purchaser, any fan
motor that fails to operate satisfactorily when failure
results from normal use.
RETURN FAN MOTOR ONLY, shipping prepaid, to Litex
Industries.We will repair or ship purchaser a replacement
motor and Litex will pay the return shipping cost.
6-YEAR to LIFETIME LIMITED WARRANTY: LITEX
INDUSTRIES, LTD. will repair the fan, at no charge to the
original purchaser for labor only, if the fan motor fails to
operate satisfactorily when failure results from normal use.
Parts used in the repair will be billed to the purchaser at
prevailing prices at time of repair.
The purchaser shall be responsible for all costs incurred
in the removal, reinstallation and shipping of the product
for repairs.
This warranty does not apply when damage from
mechanical, physical, electrical or water abuse results in
causing the malfunction. Deterioration of finishes or other
parts due to time or exposure to salt air is specifically
exempted under this warranty.
Neither Litex Industries nor the manufacturer will
assume any liability resulting from improper installation or
use of this product. In no case shall the company be liable
for any consequential damages for breach of this, or any
other warranty expressed or implied whatsoever.This
limitation as to consequential damages shall not apply in
states where prohibited.
PWLI1712
