Litheli U1CR04100 User manual

Visit our website at: http://www.litheli.com
Operator's Manual
Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Save This Manual
40V CHARGER
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please contact us: WWW.LITHELI.COM
Copyright 2019 Litheli. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of LITHELI.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
©
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
U1CR04100

Page 2 Item U1CR04100
FETY
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE
ALARGEAMOUNTOFENERGY AND
WILL VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep
Battery Pack dry.
2. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
a. Open,
b. Drop,
c. Short-circuit,
d. Puncture,
e. Incinerate, or
f. Expose to temperatures greater than 104°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
Battery Charger Safety
1. SAVE THESE INSTRUCTIONS - This manual
contains important safety and operating
instruction for battery charger Mode
U1CR04100.
2. Before using battery charger, read all
instructions and cautionary markings on
battery charger, battery, and product using
battery.
3. CAUTION - To reduce risk of injury, charge only
li-ion type rechargeable batteries. Other types
of batteries may burst causing personal injury
and damage.
4. Do not charge or use appliance in rain, or in
wet locations.
5. Do not use battery-operated appliance in rain.
6. Remove or disconnect battery after use,
before servicing, cleaning or removing
material from the gardening appliance.
7. Do not dispose of battery in a fire. The
cell may explode. Check with local codes
for possible disposal instructions.
8. Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage
to the eyes or skin. It may be toxic if swallowed.
9. Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery
or conductor may overheat and cause burns.
WWW.LITHELI.COM
IMPORTANT SAFETY INSTRUCTIONS

Page 3
WWW.LITHELI.COM
Charging the Battery Pack
NOTE : The Battery Pack comes partly charged.
Charge the Battery Pack prior to first use, ideally at least 60 minutes.
Rapid Battery Charger
Power Cord
with Plug
Battery
Pack
Connector
Charging
Status
LED – Red
Charging
Status
LED – Green
Always pull out the Power Plug of the Charger
from the mains before removing or connecting the Battery Pack to the charger.
Never charge the Battery Pack when the ambient temperature is below 10 °C or above 40 °C.
Rest the Charger for at least 15 minutes between successive charging sessions.
If no Battery Pack is inserted into the Charger and the
charger is connected to mains, the Charging Status LED flashes green.
1 .
2.
3.
Align the Battery Pack to the rails of the
Charger and slide it in. Ensure it clicks
noticeably in place.
Connect the Power Plug of the Charger with
the mains. The Charging Status LED lights
up red. The continuously lit green
Charging Status LED indicates
that the charging process is complete.
Disconnect the Power Plug of the
Charger from the mains and remove the
Battery Pack from the charger.
Charging status LEDs
Green LED flashes
without battery pack Charger ready
Green LED lights up
with battery pack
Battery pack fully
charged
Red LED lights up with
battery pack Battery pack charging
Red and green LEDs
flashing Battery pack defect
Red and greenLEDs
continuously lit
Battery pack too cold
or warm
Item U1CR04100

Page 4 Item U1CR04100
WWW.LITHELI.COM
Specifications
Symbology
Double Insulated
VVolts
~Alternating Current
AAmperes
n0 xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Do not throw the batteries in the
household waste, fire or water.
Do not expose the battery to sunlight for
a long time and do not place it on
radiators (max. 45 ° C).
Dispose of the batteries at a collection
point for old batteries, from where
they are taken to environmentally
friendly recycling.
Charge level indication.
Charge level indication.
Charger Input Rating 100-120VAC / 50-60Hz
Charger Output Rating 41.8VDC / 4.2A
Battery Type 40V Litheli Li-Ion

Page 5
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual
including all text under subheadings therein before set up or use of this product.
Charging Battery Pack
WWW.LITHELI.COM
Item U1CR04100
1. Place Battery Charger on a dry, flat, fireproof
surface indoors.
Note: Allow battery to cool completely before
charging.
2. Examine Battery Pack. Do not charge a
cracked, open, or leaking Battery Pack, or
charge a non-recommended type of Battery
Pack.
3. Battery Pack is designed to fit this Charger
specifically. If Battery Pack does not fit
Charger properly, do not try to insert it.
Do
not force Battery Pack into the Charger.
4. Plug Charger into a grounded, 120VAC, 60Hz
receptacle. Green LED will blink, showing that
power is supplied to the charger.
5. Slide Battery Pack onto Charger. Red LED will
light continuously while charging.
Note: A fully discharged Battery Pack will take
about 1 hour to fully charge.
Note: While charging, Battery Pack and Charger
may become warm to the touch and the
Charger′s fan may come on. This is normal.
6. Green LED will light continuously when Battery
Pack is charged. Unplug Charger and remove
Battery Pack when finished.
7. Allow Battery Pack to cool completely before use.

Warranty
Litheli WARRANTY POLICY FOR 40V SERIES PRODUCT
For Litheli 40V SERIES products (bare tool only) used for personal and household purposes, 3-year
limited standard warranty + 2-year limited extended warranty available upon product registration;
For Litheli 40V SERIES battery packs and chargers used for personal and household purposes, 1-year
limited standard warranty + 2-year limited extended warranty available upon product registration;
PRODUCT REGISTRATION
Please register your Litheli product at Litheli OFFICIAL website.
For better warranty services, we recommend that you register the product within 30 days from the date
of the original retail purchase.
WARRANTY CLAIM
For warranty claims, please contact Litheli customer service. You will need to submit a registration
document or proof of purchase in the form of a valid receipt that displays date and place of purchase.
Replacement tools do not come with a new warranty. The warranty of the products will continue from
the date of the original purchase.
NOTICE: Litheli offers a Warranty Extension Service for 40V SERIES products. Litheli 40V SERIES
product Warranty Extension is available only upon product registration. Register your 40V SERIES
product on Litheli OFFICIAL website to activate a 2-year limited extended warranty.
Please contact Litheli customer service at [email protected] any time you have questions or warranty
claims.
1.
2.
3.
4.
5.
6.
7.
LIMITED WARRANTY SERVICE
FOR FIVE (2-year extended warranty included) YEARS from the date of original retail purchase, this
Litheli product (battery not included) is warranted against defects in material or workmanship.
FOR THREE (2-year extended warranty included) YEARS from the date of original retail purchase, the
Litheli battery pack and charger are warranted against defects in material or workmanship.
Defective product will receive free repair or be exchanged.
This warranty applies only to the original purchaser from an authorized Litheli shop and may not be
transferred.
This warranty only covers Litheli products, battery packs and chargers used for residential purposes.
This warranty does not cover the consumables, such as, but not limited to, wheels, blades, trimmer
heads, spools, guide bars, saw chains, nozzles, filters, augers and straps.
This warranty does not cover the damage resulting from modification, alteration or unauthorized
repair.
This warranty only covers defects arising under normal usage and does not cover any malfunction,
failure or defect resulting from misuse, abuse (including overloading of the product beyond capacity,
and immersion in water or other liquid), accidents, neglect, lack of proper installation, improper
maintenance or storage.
This warranty does not cover normal deterioration of the exterior finish, including but not limited to
scratches, dents, paint chips, and any corrosion or discoloring by heat and abrasive or chemical
cleaners.
This warranty does not require Litheli to repair or replace a Litheli lithium-ion battery/ies if the
battery/ies present/s shortened runtime/working hour, reduced capacity, and/or weakened
performance due to normal chemical age.
