LOGICDATA ACS-CB-PINCH User manual

User Manual
Pinch Protection Module ACS-CB-PINCH
LOGICDATA Electronics & Software Development GmbH
Hinterleitenstrasse 22a
A 8523 Frauental /Austria
Version: GER11-170904
Availability and specifications are subject to change without prior notice. LOGICDATA assumes no
liability for maloperation or improper use of products. LOGICDATA will at point of delivery
replace/repair defective products covered by the warranty. No liability is assumed beyond such
replacement/repair. Please contact LOGICDATA directly on inquiries or custom requirements.
2004 LOGICDATA

User Manual
ACS-CB-PINCH
1. ACS-CB-PINCH Functionality
The ACS-CB-PINCH module is required to connect a squeeze line to LOGICDATA
control boxes that are not equipped with the corresponding interface (CBX, CBS,
CBB).
Note: The ACS-CB-PINCH module is not part of the standard scope of
supply of the CBX, CBS and CBB control boxes! If you decide to use a
squeeze line with these control boxes, you have to order the pinch
protection module separately.
1.1. ACS-CB-PINCH Interfaces
The ACS-CB-PINCH module is equipped with following interfaces:
Fig. 1 - Interfaces
cInterface to control box (M1 oder M2)
dInterface to squeeze line
eInterface to drive 1 or 2 (M1 oder M2)
fStatus-LED
The status-LED lights up when the squeeze line is conducting (i.e. when the person
sitting at the desk touches the squeeze line).
Page 2/4

User Manual
ACS-CB-PINCH
1.2. ACS-CB-PINCH Mounting and Connection
Caution: Unplug the power cord when connecting the ACS-CB-PINCH
module!
To install and connect the ACS-CB-PINCH module, proceed as follows:
1. Connect the short cable (interface c) to the desired interface of the control box
(M1 or M2).
2. Connect the cable of the drive to the interface eof the module.
3. Mount the module with 2 screws in the holes on the bottom side of the desk top.
4. Connect the squeeze line to the interfacedof the module (assuming the squeeze
line is already mounted to the bottom side of the desk top).
5. Connect the power cord to the outlet. Now the squeeze line is operational.
Abb. 2 – Connecting the pinch protection module
cInterface to connect the CBX control box to the ACS-CB-PINCH module
dInterface to connect the squeeze line to the ACS-CB-PINCH module
eInterface to drive 1 or 2 (M1 oder M2)
fSqueeze line mounted to the height adjustable desk
gCBX control box
Page 3/4

User Manual
ACS-CB-PINCH
2. Continuative Information
2.1. Final Disposal
Consider following disposal instructions when disposing of the CBX control box:
Note: Dispose of the components ecologically sound (separate plastic
from electronics parts)!
Same applies to components like squeeze line, drives, cables, etc.!
2.2. Manufacturer's Data
LOGICDATA
Electronics & Software Development
GmbH
Hinterleitenstrasse 22a
A-8523 Frauental - Austria
Tel.: [phone]
Fax: [phone]
Email: [email protected]
www.logicdata.at
Page 4/4
