Logitech ZONE VIBE WIRELESS User manual

ZONE VIBE WIRELESS
Setup Guide
Guide d'installation

CONTENTS
English . . . . . . . . . . . . . . . . . . . 3
Deutsch . . . . . . . . . . . . . . . . . .14
Français . . . . . . . . . . . . . . . . . 25
Italiano . . . . . . . . . . . . . . . . . . 36
Español . . . . . . . . . . . . . . . . . . 47
Português . . . . . . . . . . . . . . . . 58
Nederlands . . . . . . . . . . . . . . . . 69
Svenska. . . . . . . . . . . . . . . . . . 80
Dansk. . . . . . . . . . . . . . . . . . . .91
Norsk . . . . . . . . . . . . . . . . . . .102
Suomi. . . . . . . . . . . . . . . . . . . 113
Ελληνικά . . . . . . . . . . . . . . . . . .124
По-русски. . . . . . . . . . . . . . . . .135
Po polsku . . . . . . . . . . . . . . . . . 146
Magyar . . . . . . . . . . . . . . . . . .157
Česká verze. . . . . . . . . . . . . . . .168
Slovenčina . . . . . . . . . . . . . . . . 179
Українська. . . . . . . . . . . . . . . . .190
Eesti . . . . . . . . . . . . . . . . . . . 201
Latviski . . . . . . . . . . . . . . . . . . 212
Lietuvių . . . . . . . . . . . . . . . . . .223
Български . . . . . . . . . . . . . . . . .234
Hrvatski . . . . . . . . . . . . . . . . . 245
Srpski . . . . . . . . . . . . . . . . . . .256
Slovenščina. . . . . . . . . . . . . . . .267
Română . . . . . . . . . . . . . . . . . 278
Türkçe . . . . . . . . . . . . . . . . . .289
300 . . . . . . . . . . . . . . . . . . 
311 . . . . . . . . . . . . . . . . . . . 

KNOW YOUR PRODUCT
Front view:
Back view:
Microphone
boom
Music control
button (play/
pause/next track)
USB-A
adapter
USB-C
receiver
UC version -
Call button (answer/
end/reject calls)
MSFT Teams version -
Teams/Call button
Volume up/down
3English

Bottom view:
3-position switch (power/
Bluetooth®pairing)
Mute button
USB-C port
LED light
4English

USB-C USB-C USB-AUSB-C
BOX CONTENT
1. Zone Vibe Wireless headphones
2. Charging cable
3. USB-C receiver
4. USB-A adapter
5. Travel bag
6. User documentation
POWER ON/OFF
1. Slide the switch in the arrow’s direction to
the middle to power on the headphones. 1
2
2. Once powered on, the LED light will slightly
turn white.
3. There will be a voice prompt that tells you
the battery status.
5English

CONNECT YOUR HEADPHONES
a. Connect via USB-C receiver
1. Insert the receiver into the computer USB-C
port. Or insert the USB-C receiver with the
USB-A adapter to the USB-A port.
2. Zone Vibe Wireless is already paired to the
receiver it ships with.
3. Once successfully paired, the LED light on
the receiver will turn solid white then dim.
b. Connect via BLUETOOTH®
1. Slide the switch to the bottom in the arrow’s
direction for 2 seconds to initiate pairing.
2. The LED light will ash white rapidly.
3. Open Bluetooth®settings on your device.
4. Select Logi Zone Vibe Wireless in discoverable
devices.
5. Once successfully paired, the LED light will
turn solid white.
LOGI Zone
Vibe Wireless
2 sec.
USB-C
USB-A
ADJUSTING HEADPHONES
1. Adjust the headphones by sliding earcups
up and down the extended part of the
headband.
2. It may be easier to adjust the headphones
on your head. Slide the earcups up and down
the headband until they sit comfortably on
your ears.
6English

HEADPHONES CONTROLS
Note:
- Teams activities are only functional when Teams is running on an unlocked computer.
- Media control functionality depends on the type of application.
- Call activities are always the rst priority. When two devices are connected, the Bluetooth®connection will be prioritized
over the receiver. When two Bluetooth devices are connected, the last active device will override the other.
UC version:
Usage Button Action
Call controls Answer / End call Call button Short press
Reject call 1.5 sec. press
Music controls Play / Pause Music control button Short press
Track forward Double press
Volume Volume up "+" Short press
Volume down "-"
Connectivity Bluetooth pairing 3-position switch 2 sec. press
MSFT Teams:
Usage Button Action
Call controls
Answer / End call
Call button
Short press
Reject call 1.5 sec. press
Resume call Short press
Transfer active call to other device
Team activities Invoke Teams Call button Short press
Music controls Play / Pause Music control button Short press
Track forward Double press
Volume Volume up "+" Short press
Volume down "-"
Connectivity Bluetooth pairing Power button 2 sec. press
Tip: Music EQ controls available on Logi Tune.
7English

HEADPHONES LIGHT INDICATOR
Note:
- User-triggered behaviors, such as Bluetooth pairing or link lost, will be prioritized then revert back to its previous status
once the behavior is completed.
Category Status Light
White
Power
Power ON Turn solid white and then dim
Battery charging Breathing
Battery fully charged Solid
Connectivity
Bluetooth pairing Fast blinking
Bluetooth / receiver connected Turn solid white and then dim
Link lost Dim white
Calls Active call Solid
Incoming call Slow blinking
Red Calls Mute Solid
Power Low battery (< 10%) Slow blinking
Factory reset Fast blink from red to white for
three times then LED turn o
Voice notications indicate
when the microphone is on/
o mute.
MUTE
There are 2 ways to mute your microphone.
Press the button to mute. Flip up or down the mic
boom to mute or unmute.
L L L
Mute
"Mute on"
"Mute o"
8English

RECEIVER LIGHT INDICATOR
MSFT Teams:
Category Status Light
White Connectivity
Receiver connecting O
Receiver connected
New device paired Turn solid white and then dim
Receiver disconnected O
Purple
Connectivity
Connecting to Teams Breathing
Solid
First time failed connecting
to Teams Fast blinking for 10 seconds and then o
Failed connecting to Teams Fast blinking 3 times then LED o
Calls Active call Solid
Incoming call Repeat "fast blinking 3 times then LED o"
Red Calls Mute Solid
Blue Connectivity New device pairing Fast blinking
Connecting mode
Connected/Paired
Incoming call
Mute on
Pairing mode
Paired
9English

UC version
Category Status Light
White
Connectivity
Receiver connecting O
Receiver connected
New device paired Turn solid white and then dim
Receiver disconnected O
Calls
Active call Solid
Incoming call Repeat "fast blinking 3 times then
LED o"
Red Calls Mute Solid
Blue Connectivity New device pairing Fast blinking
Connecting mode
Connected/Paired
Incoming call
Mute on
Pairing mode
10 English
