Logitech UE9000 User manual

UE 9000
WirElEss
HEadpHonEs
USER
GUIDE

CONTENTS
ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
繁體中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
한국어 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

POWER
UP.
Turn on the UE 9000
Wireless Headphones.
Turn on your UE 9000
Wireless Headphones.
The Bluetooth® LED should blink blue rapidly,
indicating that the headphones are discoverable.

SYNC
UP. PRESS PLAY.
Pair your headphones with your Bluetooth-enabled device.
Apple iOS
Go to Settings > General > Bluetooth.
Turn on Bluetooth.
Select “UE 9000” from “Devices.”
Optional: Pair additional Bluetooth-enabled devices.
You can pair your headphones with up to eight devices. To do so:
1. Move the slider to the “Bluetooth” position and hold it there until the Bluetooth
LED blinks rapidly blue, indicating that the headphones are discoverable.
2. Complete pairing according to the instructions on the previous page.
3. Press play on the device you’ve just paired.
When you’ve successfully paired a device, the Bluetooth LED will turn solid blue.
If pairing times out (the LED will blink slowly), move the slider to the “Bluetooth”
position and hold it there until the LED starts rapidly blinking again.
Press play on your media device.

GET TO KNOW YOUR
UE 9000 WIRELESS
HEADPHONES.
UE 9000 Wireless Headphones
Molded travel case
Optional audio cable with on-cord mic and controls
USB charging cable
¼-inch (6.35 mm) adapter
Microfiber polishing cloth
WHAT’S IN
THE BOX:
Volume up
Play/Pause
Call answer/hang up
Next track
Previous track
Volume down
Listen Through button
Micro USB charging port
3.5 mm input (Interrupts Bluetooth connection when connected)
On/O/Bluetooth connection slider
Bluetooth LED
Battery level LED
Click, or press and hold
Single click
Single click to answer/
press and hold to hang up
Double click
Triple click
Click, or press and hold
Music/Calling
On-ear controls On-cord controls

FEATURES:
LED BEHAVIOR.
Bluetooth LED Battery Level LED
O
Headphones o or connected to
an audio source via the 3.5 mm jack
Blue (blinking rapidly):
Discoverable/pairing mode
Blue (blinking slowly): Connecting
Blue (solid): Connected
O
Headphone o
Green (pulsing slowly): Charging
Green (solid): Power on; fully charged
Red: Low battery
When in wireless mode, all LEDs turn o automatically. However, the LEDs will illuminate
when there is a pairing change or a control is activated.
To use the “listen through” feature, press the Listen Through button once. Your music will be
muted and environmental sounds will be amplified into your headphones. To resume listening
to music, simply press the Listen Through button again.
The “listen through” feature is only available in wireless mode while listening to music. It is
not available in wired mode or during phone calls.

O
Headphone o
Green (pulsing slowly): Charging
Green (solid): Power on; fully charged
Red: Low battery
FEATURES:
CHARGING.
When the battery level LED turns red, you should recharge your headphones. To do so:
1. Charge the headphones via USB. The battery level LED will pulse green.
2. When your headphones are fully charged, the battery level LED will glow solid green.
Micro USB charging port USB charging cable
Computer USB port
ENGLISH - 9

FEATURES:
TRAVEL STORAGE.
To safely store your headphones while you’re on the go:
1. Swivel the ear cups until they “click”.
2. Place the headphones flat in their case.
3. Place all cables and accessories in the bottom pocket.

PRODUCT CENTRAL.
There’s more information and support available for your product online.
Visit Product Central, where you can:
• Browse online articles and tutorials.
• Find tips about usage and information about additional features.
• Get help troubleshooting a problem.
• Download the latest software for your product.
• Find online documentation and warranty information.
• Connect with other users in our Community Forums to get advice,
ask questions and share solutions.
• Order spare parts (when available).
Go to www.logitech.com/support/ue9000
ENGLISH - 11

TROUBLESHOOTING.
If your headphones are not working or pairing/connecting properly, try the following:
• Move closer. The range of the Bluetooth wireless connection is up to
10meters or 30 feet.
• Recharge, particularly if the battery level LED is red. See “Charging.”
• Try increasing the volume on the headphones, on your device or in your
media application. And if you’re connected to a computer, check the
volumesettings for your operating system.
• Enable Bluetooth on your device, and then select “UE 9000” from the
Bluetooth device list.
• To x a Bluetooth connection by repairing:
1. On your device: Delete “UE 9000” from the Bluetooth device list
2. On the headphones: Move the slider to “Bluetooth” and hold until the
Bluetooth LED blinks blue.
3. On your device: Select “UE 9000” from the Bluetooth device list
4. From the media player on your Bluetooth device: Select “UE 9000”
• For computers, you may need to specify the headphone as the input/output
device for your operating system.
For help, go to www.logitech.com/support/ue9000

ENGLISH - 13

BATTERY REMOVAL
AND RECYCLING
1. Peel and remove the ear pad from the left ear cup.
2. Remove screws to disassemble the speaker chamber.
3. Unplug the old battery.
4. Dispose of old battery at an authorized
battery recycling center.

HEADPHONE
DISASSEMBLY
Remove screws
LEFT EAR CUP
Peel and remove
earpad
Unplug battery
ENGLISH - 15

開機。
開啟 UE 9000
無線耳機電源。
開啟您的 UE 9000 無線
耳機電源。
藍牙® LED 指示燈會快速閃爍藍燈，
表示耳機目前處於可偵測狀態。

進行
同步。
按下
播放鍵。
將您的耳機與藍牙裝置進行配對。
Apple iOS
移至「設定」>「一般」>「藍牙」。
開啟藍牙功能。
從「裝置」中選擇「UE 9000」。
選用步驟：配對其他藍牙裝置。
您的耳機可與多達 8 個裝置進行配對。請執行下列步驟：
1. 將滑桿移動到「藍牙」位置並按住不放，直到藍牙 LED 指示
燈快速閃爍藍燈，表示耳機目前處於可偵測狀態為止。
2. 依照前頁說明完成配對。
3. 完成配對後按下裝置上的播放鍵。
當成功完成裝置配對時，藍牙 LED 指示燈會轉為恆亮的藍燈。
如果配對逾時 (LED 指示燈緩慢閃爍)，請將滑桿移到「藍牙」
位置並按住不放，直到 LED 指示燈再次快速閃爍為止。
按下媒體裝置上的播放鍵。

瞭解 UE 9000
無線耳機。
UE 9000 無線耳機
塑模隨身收納盒
選用的線控麥克風與控制裝置的音訊連接線
USB 充電連接線
¼吋(6.35 mm) 轉接器
超細纖維拋光布
包裝
內容：
音量增大
播放/暫停
接聽/掛斷
下一首
上一首
音量減小
聆聽按鈕
微型 USB 充電埠
3.5 mm 輸入插孔 (插入此插孔時會中斷藍牙連線)
開啟/關閉/藍牙連線滑桿
藍牙 LED 指示燈
電池電量 LED 指示燈
點按，或是按住不放
按一下
按一下可接聽通話/
按住不放可掛斷通話
按兩下
按三下
點按，或是按住不放
音樂/通話
耳罩整合式控制鍵 線控裝置

功能：
LED 指示燈意義。
藍牙 LED 指示燈 電池電量 LED 指示燈
關閉
耳機關閉或是透過 3.5 mm 插孔連線到音訊來源
藍燈 (快速閃爍)：
可偵測/配對模式
藍燈 (緩慢閃爍)：正在連線
藍燈 (恆亮)：已連線
關閉
耳機關閉
綠燈 (緩慢閃爍)：充電
綠燈 (恆亮)：電源開啟；已完全充電
紅燈：電量過低
當處於無線模式時，所有的 LED 指示燈會自動熄滅。但是，當配對變更或是使用控制鍵時，LED 指示燈
就會亮起。
若要使用「聆聽」功能，請按一下「聆聽」按鈕。您的音樂會變成靜音，環境聲音則會放大送入您的耳機。
若要繼續聆聽音樂，只需再按一下「聆聽」按鈕。
「聆聽」功能僅可在以無線模式聆聽音樂時使用。有線模式或是進行電話通話時無法使用。
