Logitech Mobile Bluetooth Guide

Using your Bluetooth
headset with the
Logitech wireless hub
© 2003 Logitech, Inc.

Using your Bluetooth headset with the Logitech wireless hub
Contents
Introduction 3
Product compatibility 3
About this guide 4
Get connected 6
Connecting your Logitech headset 6
Checking your headset is connected 14
Communicate without wires 15
Listening to streaming news and music 15
Voice chatting with your instant messenger 16
Learn more about connecting 20
Disconnecting and unpairing your headset 20
Reconnecting your headset 21
Troubleshooting 22
This manual is published by Logitech. Logitech assumes no responsibility for any errors that may appear in this
manual. Information contained herein is subject to change without notice.
© 2003 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech
and may be registered. All other trademarks are the property of their respective owners.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Logitech is
under license. Other trademarks and trade names are those of their respective owners.
Microsoft, MSN, and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries. Screenshots reprinted by permission from Microsoft Corporation.
© 2003 Logitech, Inc. 2

Using your Bluetooth headset with the Logitech wireless hub
Introduction
If you have a Logitech®headset you can connect it to the Bluetooth®wireless
hub provided with your Logitech product.
Chat to friends over the Internet using instant messaging. Relax while you listen
to your favorite music. Keep up to date with streaming news. All without the
constraints of wires.
Connecting a Logitech headset to your Logitech wireless hub means that you
can move around while you listen and talk as long as you stay within range –
typically up to 30 feet or 10 meters depending on your surroundings. What’s
more, solid objects won’t cause a problem because there does not need to be a
line-of-sight connection between the headset and Logitech wireless hub.
In short, connecting a Logitech headset to your Logitech wireless hub gives
you more freedom.
Welcome to the expanding world of cordless freedom offered through your
Logitech wireless hub.
Product compatibility
Further information about the products that are covered in this guide is
available at: www.logitech.com/bluetooth/howto
© 2003 Logitech, Inc. 3

Using your Bluetooth headset with the Logitech wireless hub
About this guide
This guide gets you started using your Logitech headset (or compatible headset)
with your computer. It explains how to get connected, and then how to carry out
your favorite tasks, such as listen to news and music, and voice chat over
Bluetooth®.
Prerequisites
This guide assumes that:
• You have installed your Logitech product and the SetPoint™ software.
• You are using the Bluetooth®wireless hub supplied with your Logitech product.
• You have charged your headset, so it is ready for use.
• You are familiar with basic Bluetooth®technology. If not, please read the
section below.
Further information
This guide contains all the information you need to connect and start using your
Logitech headset. If you need further information, additional sources are
available:
• www.logitech.com/bluetooth provides general information about the
Bluetooth®technology.
• www.logitech.com/bluetooth/howto provides a Using my Bluetooth devices
with the Logitech wireless hub guide which introduces the Bluetooth®
concepts you need to be familiar with, and ‘how to’ guides such as this for
each supported device. There is also a product compatibility matrix which
lists the products that have been tested and approved for use with the
Logitech wireless hub. You can also find out what you can do with each
device.
© 2003 Logitech, Inc. 4

Using your Bluetooth headset with the Logitech wireless hub
How to use this guide
The following symbols are used in this guide:
Symbol Explanation
Tip - a handy hint that may provide a useful alternative or save time.
Note - helpful information that requires your attention.
© 2003 Logitech, Inc. 5

Using your Bluetooth headset with the Logitech wireless hub
Get connected
Connecting your Logitech headset to your computer is easy. A wizard guides
you through the steps involved, which include discovering your device, pairing
and then establishing connection.
Connecting your Logitech headset
To connect your Logitech headset and computer:
1. Place your headset in discoverable mode.
With the headset turned off, press and hold the button on the side of your
headset for up to 10 seconds until its indicator light first flashes blue, and
then blue and red.
Please note:
• If the indicator light flashes red and then stops flashing, this means
that the headset was turned on when you began, and you have now
turned it off. Release the button and start again.
• For the Motorola Bluetooth Headset, with the headset’s boom open,
press and hold the multifunction button for three seconds. For other
headsets, press and hold the button for several seconds. Refer to
your headset’s user guide for full details.
© 2003 Logitech, Inc. 6

Using your Bluetooth headset with the Logitech wireless hub
2. Start the Bluetooth Setup Wizard.
The easiest way to do this is to press the Connect button on the front of
your Bluetooth®wireless hub. The first screen of the wizard is displayed:
You can also start the Bluetooth Setup Wizard by:
• Right-clicking on the Bluetooth®icon, , in the Windows

Taskbar and selecting Add a Bluetooth Device from the menu
displayed.
• Selecting Add a Bluetooth Device from the Bluetooth Tasks
panel in the My Bluetooth Places screen in your Windows®
Explorer (available in Windows®XP only).
© 2003 Logitech, Inc. 7

Using your Bluetooth headset with the Logitech wireless hub
3. Search for devices.
Click Next > to proceed. A wizard then searches for Bluetooth®devices
within range, and displays those it finds:
The devices found are listed.
If a large number of devices are
found, make a selection here to
display just those you are
interested in.
You can click here to search again
if your headset is not found.
Your headset may not be found at the first time you carry out a search.
Click Search Again to repeat the search.
© 2003 Logitech, Inc. 8

Using your Bluetooth headset with the Logitech wireless hub
4. Select your headset.
Highlight your headset and click Next >.
You have now discovered your Logitech headset! It remains discoverable
for two minutes.
The next step is to pair it with your computer. This is done in the following
dialog:
1. Enter a number in PIN Code.
2. Click the Initiate Pairing
button.
© 2003 Logitech, Inc. 9

Using your Bluetooth headset with the Logitech wireless hub
5. Pair your headset and computer.
To do this, enter the PIN Code ‘0000’ and click Initiate Pairing.
(A PIN Code is also known as a Passkey.)
For the Sony Ericsson HBH 30/60 Bluetooth Headsets, Motorola
Bluetooth Headset, and Siemens HHB-500 Bluetooth Headset, the PIN
Code is also ‘0000’. For the Nokia HDW-2 Bluetooth Headset, the PIN
Code is specific to that headset – refer to your headset’s user guide.
The Nokia HDW-2 Bluetooth Headset can be paired with more than one
device, though there are some restrictions.
Refer to your headset’s user guide for full details.
When your headset and computer have been successfully paired, the
following dialog is displayed:
One service supports all of
the tasks you can carry out
with your headset.
Please note:
• An explanation of the reasons why Bluetooth®devices need to be
paired is provided in the guide Connecting Bluetooth devices to
my computer.
• If you get an error message indicating that your headset hasn’t
paired, this may be for a variety of reasons:
- your headset may have come out of discoverable mode,
- it may be out of range,
- it may already have been paired with another computer in range.
For suggestions about the actions you can take, see Troubleshooting,
page 22.
© 2003 Logitech, Inc. 10

Using your Bluetooth headset with the Logitech wireless hub
6. Select the Headset service.
To select the service, check the box next to it. The following dialog is
displayed:
Leave the settings unchanged and click OK. You return to the Bluetooth
Service Selection dialog.
© 2003 Logitech, Inc. 11

Using your Bluetooth headset with the Logitech wireless hub
7. Click Finish.
This completes the pairing procedure. A device icon for the headset is
created in your Bluetooth®Neighborhood. To see the device icon:
1. Double-click the Bluetooth®icon, , in the Windows®Taskbar. The
Explore My Bluetooth Places dialog is displayed.
2. Select Entire Bluetooth Neighborhood if you are using Windows®
2000, or View devices in range if you are using Windows®XP. The
following window is displayed:
Logitech headset device icon. The red
check mark shows it is paired.
© 2003 Logitech, Inc. 12

Using your Bluetooth headset with the Logitech wireless hub
8. Connect to your headset.
Right-click on the device icon and selecting Connect Headset. The device
icon changes to show that the headset is now connected (see the next
section). Then, press the button on the side of the headset when it
beep/rings.
Please note:
• For other headsets, refer to your headset’s user guide for full details.
• It is important that you disconnect your Logitech headset when you
have finished using it, to avoid conflict with other Bluetooth devices.
See the section Disconnecting and unpairing your headset, page 20.
© 2003 Logitech, Inc. 13

Using your Bluetooth headset with the Logitech wireless hub
Checking your headset is connected
You can check that your headset is connected in any of the following ways:
• Listen to your headset. Every five seconds you should hear a short tone
made up of high and low notes.
• Look in My Bluetooth Places and locate the device icon for the Logitech
headset. The device icon shows whether it is paired and/or connected:
Windows
2000
Windows
XP
Windows
2000
Windows
XP
Windows
2000
Windows
XP
Not paired or
connected
Paired but not
connected
Paired and
connected
• Check the indicator light on the side of the headset. Every five seconds the
light flashes. The number of flashes shows the current state of the headset.
Both three or four flashes indicate that the headset is connected.
If you have followed the steps in the previous section but your headset is still not
connected, see Troubleshooting, page 22, for suggestions of the actions you
should take to establish connection.
© 2003 Logitech, Inc. 14

Using your Bluetooth headset with the Logitech wireless hub
Communicate without wires
Having connected your Logitech headset, it’s ready to use!
So what can you do? In short, all of the things that you can do with your
computer’s speakers and microphone such as listen to streaming news and
music or have a voice conversation with friends and co-workers over the Internet
using instant messaging.
And thanks to your Logitech wireless hub, you can do all of this without the
constraints of wires.
Please note:
• Since the headset incorporates a single speaker, the music and
sound is in Mono only.
• You may find that your Logitech mouse is not as responsive as usual
when you are using it and your Logitech headset at the same time.
Listening to streaming news and music
Any program you use to listen to news or music will work with your Logitech
headset, including MusicMatch, Windows MediaPlayer and Microsoft
Internet Explorer.
Whichever program you choose, listening to sound is straightforward. To listen
to streaming news and music:
1. Make sure your headset is connected, and that you have switched your
computer’s sound to the headset, by pressing the headset button. See Get
connected beginning on page 6for details.
2. Launch the program you want to use.
3. Find the music or station you want to listen to and click the Play button
if necessary.
If you can’t hear sound, try pressing the button on the side of your headset.
If you still can’t hear anything see Troubleshooting, page 22, for suggestions of
the actions you should take.
© 2003 Logitech, Inc. 15

Using your Bluetooth headset with the Logitech wireless hub
Voice chatting with your instant messenger
Instant messaging lets you have voice conversations with friends or co-workers
over the Internet.
Your Logitech headset gives you more freedom for voice chatting with instant
messenger. You can chat with both hands free and move around while you talk,
providing you stay within range of your computer.
Why not combine your headset with your webcam to give you the
complete multimedia experience?
You can use your Logitech headset with most of the popular instant messaging
programs, including:
• MSNMessenger. See page 17.
• Yahoo!Messenger. See page 18.
• AOLInstant Messenger™. See page 19.
Want the latest programs?
• Go to http://www.messenger.msn.com for MSNMessenger.
• Go to http://messenger.yahoo.com for Yahoo!Messenger.
• Go to http:/www.aim.com for AOLInstant Messenger™.
For other headsets, refer to your headset’s user guide for full details.
© 2003 Logitech, Inc. 16

Using your Bluetooth headset with the Logitech wireless hub
To voice chat using MSN®Messenger:
1. Connect your headset.
Make sure your Logitech headset is connected, and that you have switched your
computer’s sound to the headset by pressing the headset button. See Get
connected beginning on page 6for details.
For other headsets, refer to your headset’s user guide for full details.
2. Start your messenger session.
Launch MSN Messenger and Sign In.
3. Run the Audio Setup Wizard.
Make sure your Logitech headset is working optimally with MSN®
Messenger by running the MSN®Messenger Audio Tuning Wizard. Start
the wizard by selecting Audio Tuning Wizard from the Tools menu, and
follow the instructions on screen.
Please note the following when running the wizard:
• When asked to select the Microphone and Speakers you want
to use, make sure they are set to ‘Bluetooth Audio.’ If they are
not, select this option from the relevant drop-down lists.
• When testing the speakers, if you can’t hear the drum beat, this
may be because your headset has gone into sleep mode. Try
pressing the button on the side of your headset once.
4. Choose a contact.
Select the contact you want to chat with from the list available. The easiest
way to do this is to double-click their name in the Online list, and then click
Start talking in the side bar of the Conversation window.
You can also select a contact to chat to by:
• Right-clicking on their name in the Online list and selecting
Start a Voice Conversation.
• Highlighting their name in the Online list and selecting Start a
Voice Conversation from the Actions drop-down menu.
A message is sent to your contact inviting them to chat to you. Sit back and
wait for their reply! If you can’t hear your contact speak or if they can’t hear
you, see Troubleshooting, page 22, for suggestions of the actions you should
take.
© 2003 Logitech, Inc. 17

Using your Bluetooth headset with the Logitech wireless hub
To voice chat using Yahoo! ® Messenger:
1. Connect your headset.
Make sure your headset is connected, and that you have switched your
computer’s sound to the headset by pressing the headset button. See Get
connected beginning on page 6for details.
For other headsets, refer to your headset’s user guide for full details.
2. Start your messenger session.
Launch Yahoo! Messenger and Login.
3. Run the Audio Setup Wizard.
Make sure your Logitech headset is working optimally with Yahoo! ®
Messenger by running the Yahoo! ® Messenger Audio Setup Wizard. Start
the wizard by selecting Audio Setup Wizard from the Help menu, and
follow the instructions on screen.
4. Choose a contact.
Select the contact you want to chat with from the list available to you. The
easiest way to do this is to double-click their name in the appropriate group and
click Voice in the toolbar of the Instant Message window.
You can also select a contact or several contacts for a conference call by:
• Highlighting their name in the appropriate group and selecting Invite
to Conference from the Tools drop-down menu.
• Right-clicking on their name in the appropriate group and selecting
Invite to Conference.
The Invite Friends to Conference dialog is displayed, for you to confirm
the contacts you want to chat with before clicking on Invite.
A message is sent to the person you have selected inviting them to chat to you.
When they accept your invitation, relax and discuss whatever’s on your mind!
If you can’t hear your contact speak or they can’t hear you, see
Troubleshooting, page 22, for suggestions of the actions you should take.
© 2003 Logitech, Inc. 18

Using your Bluetooth headset with the Logitech wireless hub
Tips for chatting with Yahoo! ® Messenger:
• Before you start chatting, check the Hands Free box in the Voice
Conference window to indicate that you are using a headset. If you do
not do this you have to use your mouse to hold down the Talk button
when chatting. Refer to the Help for Yahoo! ® Messenger for more
information.
• If you or your contact receive a message saying that you are not
authorized to join a conference, this may be because Yahoo! ® Messenger
has timed out. To be able to join the conference click OK to close the
message, then click Voice Off followed by Voice in the Voice
Conference window.
To voice chat using AOL®Instant Messenger™:
1. Connect your headset.
Make sure your headset is connected, and that you have switched your
computer’s sound to the headset by pressing the headset button. See Get
connected beginning on page 6for details.
For other headsets, refer to your headset’s user guide for full details.
2. Start your messenger session.
Launch AOL Instant Messenger and Sign In.
3. Choose a contact.
Select the contact you want to chat with by right-clicking on their name in
the Online list and selecting Connect to Talk.
You can also select a contact by highlighting their name and selecting
Connect to Talk from the People drop-down menu.
A dialog is displayed asking you to confirm that you want to connect.
4. Connect to your contact.
Click Connect. The Connecting to window is displayed. You can now
begin your conversation.
If you can’t hear your contact speak or they can’t hear you, see
Troubleshooting, page 22, for suggestions of the actions you should take.
© 2003 Logitech, Inc. 19

Using your Bluetooth headset with the Logitech wireless hub
Learn more about connecting
This section contains other information that may be useful to you regarding
disconnecting, unpairing, and reconnecting your headset.
Disconnecting and unpairing your headset
When you have finished using your Logitech headset, you should disconnect it.
Your Logitech headset can only be connected to one device at a time. If you
connect other Bluetooth®devices to your computer, it is essential that you
disconnect your headset to avoid conflicts with the other devices.
If you think that you will not be using the headset with your computer again
soon, or if you want to connect the headset to another computer or device, you
should also unpair it.
If you will be using your headset with your computer again soon, it will
save time if you leave it paired.
To disconnect and/or unpair your Logitech headset from your computer:
1. Locate the device icon for the Logitech headset.
The easiest way to do this is:
• Go to My Bluetooth Places by double-clicking the Bluetooth®
icon, , in the Windows®Taskbar.
• Select Entire Bluetooth Neighborhood if you are using Windows®
2000, or View devices in range if you are using Windows®XP.
2. Disconnect your headset.
Right-click the device icon for the Logitech headset and select Disconnect
Headset.
The device icon changes to show that the headset is no longer connected.
It is, at this point, still paired with your computer.
3. Unpair your headset if required.
To do this, simply right-click the headset device icon again, and select
Unpair Device.
© 2003 Logitech, Inc. 20
