Logitech aK1060 User manual

Setup Guide | 设置指南
TYPE-S
Thin and light protective keyboard case
For Samsung GALAXY Tab S 10.5
TYPE-S
aK1060 键盘保护套
适用于 Samsung GALAXY Tab S 10.5

2
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Contents
English 3 简体中文 14
www.logitech.com/support/type-s

3 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Know your product
12
11
8
7
9
10
1
2
5
3
6
4
1. Tablet holder
2. Protective case
3. Hook
4. Magnet
5. Function keys
6. Keyboard
7. Bluetooth/battery status light
8. Bluetooth connect button
9. On/o switch
10. Micro-USB charging port
11. Micro-USB charging cable
12. Product documentation
12
620-006189.002
PDF
www.logitech.com/support/type-s
3
®
®
TYPE- S
4
TYPE-S
Thin and light protective keyboard case
For Samsung GALAXY Tab S 10.5
TYPE-S
aK1060 键盘保护套
适用于 Samsung GALAXY Tab S 10.5

4 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Setting up the keyboard case
Getting started
1. Open the keyboard case and push
your Samsung GALAXY Tab S 10.5
into the tablet holder:
2. Push your Samsung GALAXY Tab S 10.5
down into the hook:
3. Move the keyboard case into the typing
position by lifting the back of the
protective case and sliding the hook
forwards until it aligns with the magnet:

5 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Connecting your keyboard and tablet
The keyboard case links to your tablet
via a Bluetooth connection. The first time
you use the keyboard case, you must pair
the keyboard with your tablet.
®
®
TYPE - S
1. Turn on the keyboard:
The status light blinks blue (fast blink)
to indicate that the keyboard is
discoverable, ready for pairing with
your tablet. The first time you turn on
the keyboard it remains discoverable
for 15 minutes.
If the status light turns red,
charge the battery. For more information,
see “Charging the keyboard battery.”
2. Make sure your tablet’s Bluetooth
feature is on.
From a Home screen, touch Apps
Settings Network connections
section, and turn on the Bluetooth switch.
3. Pair the keyboard case with your tablet.
(i) In your tablet’s Bluetooth settings
page, select “TYPE-S” in the list of
Available devices.
(ii) When prompted, enter the PIN
displayed using the case keyboard.
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.

6 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Connecting to another tablet
1. Make sure the keyboard is turned on.
2. Make sure your tablet’s Bluetooth
feature is on.
From a Home screen, touch Apps
Settings Network connections
section, and turn on the Bluetooth switch.
3. Press the Bluetooth Connect button:
®
The status light blinks blue (fast blink)
to indicate that the keyboard is
discoverable, ready for pairing with
your tablet. The keyboard is discoverable
for 3 minutes.
4. Pair the keyboard case with your tablet.
(i) In your tablet’s Bluetooth settings
page, select “TYPE-S” in the list of
Available devices.
(ii) When prompted, enter the PIN
displayed using the case keyboard.
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.

7 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Using the keyboard case
Two viewing positions
The keyboard case provides two viewing
positions—one for typing and another
for browsing.
To type:
1. Move the tablet holder into the typing
position, aligning it with the built-in
magnet to secure it:
2. Turn on the keyboard:
If the status light turns red,
charge the battery. For more information,
see “Charging the keyboard battery.”
If you don’t use the keyboard for a while in
the typing position, it enters sleep mode
automatically. Pressing any key wakes it.
To browse, place the tablet holder in the
browsing position:
You can switch o the keyboard if you want
to conserve battery power.
Typing position
Browsing position

8 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Status light indicators
Bluetooth and battery status light
Light Description
Blinking green The battery is charging.
Green The battery is charged (more than 10%).
Red Battery power is low (less than 10%). Recharge the battery.
Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.
Slow: The keyboard is trying to reconnect to your Samsung
GALAXY Tab S 10.5.
Solid blue Bluetooth pairing or reconnection is successful.

9 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Function keys
FN + Back: Esc
FN + 1: Lock screen
Lock or unlock the tablet screen
FN + 2: Web browser
FN + 3: Mail
31
FN + 4: Calendar
FN + 5: Music
FN + 6: Previous track
FN + 7: Play/Pause
FN + 8: Next track
FN + 9: Mute
FN + 0: Volume down
FN + -: Volume up
FN + =: Print Screen
FN + Backspace: Forward delete
FN + Tab: Show all apps
FN + Caps Lock:
Quick panel/Notifications
FN + X: Cut
FN + C: Copy
FN + V: Paste
FN + Left cursor: Home
FN + Right cursor: End
FN + Up cursor: Page Up
FN + Down cursor: Page Down
FN + Search: Voice search
Use your voice to send messages,
make calls, and more
FN + Right Alt: Android™ menu
FN + Android home: Switch
applications
FN + spacebar: Switch language
Note:
• To select a function key, press and hold the FN key, and then press the key indicated above.

10 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Charging the keyboard battery
If the status light is red the keyboard case
battery needs to be charged.
1. Plug one end of the micro-USB cable
into the charging port, and the other end
into a USB port on your computer.
The status light blinks green as
the battery charges.
2. Charge the battery until the status light
turns solid green.
Battery information
• A fully charged battery provides about
three months of use when the keyboard
is used about two hours a day.
• Charge the battery if the status light
turns red briefly after the keyboard turns
on.
• When not in use, turn o the keyboard
to conserve battery power.
• The keyboard enters sleep mode
automatically if not used for a while
in the typing position. Press any key
to wake it.
USB

11 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Battery disposal at product end of life
1. Pry o top cover of keyboard with
screwdriver.
2. Detach battery from circuit board
and remove battery.
3. Dispose of your product and its battery
according to local laws.
3
2
1

12 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
When you’ve finished using the keyboard case
Detaching your tablet
1. Release your tablet from the hook:
2. Slide your tablet out of the tab holders:
Your tablet is then released.
Storing your tablet for travel
1. Insert your tablet in the tablet holder.
2. Close the keyboard case:

13 English
TYPE-S — Thin and light protective keyboard case — For Samsung GALAXY Tab S 10.5
Visit Product Support
There’s more information and support
online for your product. Take a moment
to visit Product Support to learn more
about your new keyboard case.
Browse online articles for setup help,
usage tips, and information about
additional features.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
Find a wide selection of content including:
• Tutorials
• Troubleshooting
• Support community
• Online documentation
• Warranty information
• Spare parts (when available)
Go to:
www.logitech.com/support/type-s
Troubleshooting
The keyboard does not work
• Press any key to wake the keyboard
from sleep mode.
• Turn the keyboard o and then back on.
• Recharge the internal battery. For more
information, see “Charging the keyboard
battery.”
• Verify that Bluetooth is turned on
in your tablet’s settings ( Apps
Settings Network connections
section Bluetooth).
• Verify that “TYPE-S” is paired with
your tablet ( Apps Settings
Network connections section
Bluetooth).
• Re-establish Bluetooth connection
between the keyboard and your tablet
by selecting “TYPE-S” in the list of
Available devices. The status light on
your keyboard turns solid blue when
Bluetooth connection is established.
What do you think?
Thank you for purchasing our product.
Please take a minute to tell us what you think of it.
www.logitech.com/ithink

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
14 简体中文
了解您的产品
12
11
8
7
9
10
1
2
5
3
6
4
1. 平板电脑支架
2. 保护盒
3. 挂钩
4. 磁体
5. 功能键
6. 键盘
7. 蓝牙/电池状态指示灯
8. 蓝牙连接按钮
9. 开启/关闭开关
10. 微型 USB 充电端口
11. 微型 USB 充电连接线
12. 产品文档
12
620-006189.002
PDF
www.logitech.com/support/type-s
3
®
®
TYPE- S
4
TYPE-S
Thin and light protective keyboard case
For Samsung GALAXY Tab S 10.5
TYPE-S
aK1060 键盘保护套
适用于 Samsung GALAXY Tab S 10.5

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
15 简体中文
设置键盘保护套
入门指南
1. 打开键盘保护套，将 Samsung
GALAXY Tab S 10.5 推入平板电
脑支架：
2. 将 Samsung GALAXY Tab S 10.5
向下推入挂钩：
3. 提起保护套背面，向前滑动挂钩，
直到挂钩与磁体对齐，将键盘保护套移
动至打字位置：

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
16 简体中文
连接键盘和平板电脑
键盘保护套与平板电脑之间通过蓝牙进行
连接。首次使用键盘保护套时，必须将键
盘与平板电脑进行配对。
®
®
TYPE - S
1. 开启键盘：
状态指示灯闪烁蓝灯（快速闪烁)，表示
键盘处于可被搜索状态，可与平板电脑
进行配对。首次开启键盘后，键盘将保
持可被搜索状态 15 分钟。
如果状态指示灯变为红灯，请为电池
充电。有关详细信息，请参见“为键盘
电池充电”。
2. 确保平板电脑的蓝牙功能已开启。
在主屏幕上触击 应用程序 设置
网络连接部分，然后开启蓝牙开关。
3. 将键盘保护套与平板电脑配对。
(i) 在平板电脑的蓝牙设置页面，从可用
设备列表中选择“TYPE-S”。
(ii) 根据提示，通过保护套键盘输入显
示的 PIN。
成功连接后，状态指示灯将在短时间内
变为稳定的蓝光，然后熄灭。

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
17 简体中文
连接到其他平板电脑
1. 确保键盘处于开启状态。
2. 确保平板电脑的蓝牙功能已开启。
在主屏幕上触击 应用程序 设置
网络连接部分，然后开启蓝牙开关。
3. 按下蓝牙连接按钮：
®
状态指示灯闪烁蓝灯（快速闪烁)，表示
键盘处于可被搜索状态，可与平板电脑
进行配对。键盘在 3 分钟内将处于可被
搜索状态。
4. 将键盘保护套与平板电脑配对。
(i) 在平板电脑的蓝牙设置页面，从可用
设备列表中选择“TYPE-S”。
(ii) 根据提示，通过保护套键盘输入显
示的 PIN。
成功连接后，状态指示灯将在短时间内
变为稳定的蓝光，然后熄灭。

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
18 简体中文
使用键盘保护套
两种放置方式
键盘保护套提供两种放置方式：一种用于
输入，一种用于浏览。
如要打字：
1. 请将平板电脑支架放到适合输入的位置,
将其与内置的磁体对齐以固定到位：
2. 开启键盘:
如果状态指示灯变为红灯，请为电池
充电。有关详细信息，请参见“为键盘电
池充电”。
在处于输入位置时，如果有一段时间未
使用，则键盘会自动进入休眠模式。按任
意键可将其唤醒。
如要浏览，请将平板电脑支架置于浏览
位置：
如您想节省电池电量，可关闭键盘。
打字位置
浏览位置

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
19 简体中文
状态指示灯
蓝牙和电池状态指示灯
指示灯 说明
闪烁绿灯 电池正在充电。
绿灯 电池有电（＞10%)。
红灯 电量不足（＜10%)。为电池充电。
闪烁蓝灯 快速: 键盘处于可被搜索状态，已准备好可以进行配对。
缓慢: 键盘正在尝试重新连接您的
Samsung GALAXY Tab S 10.5。
稳定蓝灯 蓝牙配对或重新连接成功。

TYPE-S — aK1060 键盘保护套 适用于 Samsung GALAXY Tab S 10.5
20 简体中文
功能键
FN + Back: Esc
FN + 1: 锁屏
锁定或解锁平板电脑屏幕
FN + 2: 网络浏览器
FN + 3: 邮件
31
FN + 4: 日历
FN + 5: 音乐
FN + 6: 上一曲目
FN + 7: 播放/暂停
FN + 8: 下一曲目
FN + 9: 静音
FN + 0: 调低音量
FN + -: 调高音量
Fn + =: 全屏截图
FN + 退格键: 删除前一个字符
FN + Tab: 显示全部应用程序
FN + Caps Lock:
快速面板/通知
FN + X: 剪切
FN + C: 复制
FN + V: 粘贴
FN + 左光标: Home
FN + 右光标: End
FN + 向上光标: Page Up
FN + 向下光标: Page Down
FN + 搜索: 语音搜索
通过语音发送消息，拨打电话以
及执行其他操作
FN + 右 Alt: Android™ 菜单
FN + Android 主页:
切换应用程序
FN + 空格键: 切换语言
请注意:
• 要选择功能键，请按住 FN 键，然后按上方显示的键。
