Loll Designs Lago User manual

Step 4
Step 3
Step 1
Step 2
*Tighten bolts from Step 3
Loosen bolts if necessary.
7/8" Bolts X12
Back
Front Slat
Back Slat
Right Leg
Left Leg
G Block X 4
7/8" Bolts X12
Back
Front Slat
Back Slat
Right Leg
Left Leg
G Block X 4
7/8" Bolts X12
Back
Front Slat
Back Slat
Right Leg
Left Leg
G Block X 4
7/8" Bolts X12
Back
Front Slat
Back Slat
Right Leg
Left Leg
G Block X 4
1x
BACK
1x
BACK SLAT
*Bolts shown
actual size.
INCLUDED PARTS
ASSEMBLY INSTRUCTIONS
7/8" Bolts X12
Back
Front Slat
Back Slat
Right Leg
Left Leg
G Block X 4
4x
GB
1
Step 4
Step 3
Step 1
Step 2
*Tighten bolts from Step 3
Loosen bolts if necessary.
2x
7/8˝
2x
LEG
2x
FRONT SLAT
12x
7/8˝
2x
1x
LEGS
FRONT
SLAT
1. 2. 3. 5. 4.
ASSEMBLY TIPS:5 Important Points You NEED to Read
Prior to beginning assembly, please inspect and inventory the parts to make sure you have everything and that nothing was damaged during shipping. If damage has occurred, please take photos and go to lolldesigns.com/damage. Rest assured we’ll get it taken care of straight away! To avoid scratching furniture, assemble on a clean soft surface like a blanket, carpet, or the attened cardboard box the furniture was shipped in. Start all bolts by hand to ensure proper alignment and to prevent cross threading. Then using the Allen Key or Loll Tool, tighten until you feel resistance. Bolts should not be forced, but some components, particularly the blocks will need a bit of muscle to get them together as they are machined for a snug t. If parts are still not going together, please send us a photo of the part you are having trouble with. You can use a cordless screw gun if you have one and know how to use it. Set the clutch setting at low to medium torque. We do not recommend using an electric drill without a clutch to install bolts as you can easily overtighten and damage the product.
ASSEMBLY INSTRUCTIONS & PRODUCT INFO:
LOLL TOOL Locate the box marked “Tool Included” before beginning assembly.
RECYCLE THE PACKAGING
We’ve gone through great lengths to make as much of our packaging as possible recyclable. The cardboard box, paper wrap, ller and paper bags can all go in your recycling bin. The muslin hardware bags replaced plastic bags with the intention of reducing plastic and encouraging reuse. Loll Designs and Planet Earth thank you!
WE WANT YOU TO LOVE YOUR LOLL For more info and visual aids, watch the assembly videos at www.lolldesigns.com/videos For product care & maintenance, visit www.lolldesigns.com/care-maintenance For further lollygagging assistance, please reach out! [phone] [email protected] 5912 Waseca Street Duluth, Minnesota 55807
BLOCK & BOLT INSTALLATION Insert bolts through countersunk hole side of blocks as shown below.
CORRECT INCORRECT
Countersunk
Hole
“Loll Designs inspires people to appreciate the outdoors.”
Greg Benson - Founder/CEO
LAGO CHAIR
