Lorell 33553 User manual

Motion Sensor Oscillating Heater
with Digital Control
33553
Part# NFE20C
INSTRUCTION MANUAL
Please Read And Save These Instructions
1

IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions carefully and keep for future reference.
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
1. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surface. If provided, use handles when moving this heater. Keep combustible
materials such as furniture, pillows, bedding, papers, clothes and curtains at least
3 feet (0.9m) from the front of the heater. Also, keep them away from the sides
and rear of the heater.
2. Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
3. Always unplug the heater when not in use.
4. Do not operate the heater if the cord or plug is damaged, or if the heater
malfunctions, or has been dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or mechanical adjustment,
or repair.
5. Do not use outdoors.
6. This heater is not intended for use in bathroom, laundry areas and similar moist
indoor locations. Never locate heater where it may fall into a bathtub or other
water container.
7. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or
anything similar. Arrange cord away from traffic areas where it will not be tripped
over.
8. CAUTION: This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of shock, this plug is intended to fit only one way in a
polarized outlet. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. DO NOT attempt to defeat this
safety feature. To do so could result in an electric shock hazard.
9. This heater draws 12.5 amps during operation. To prevent overloading a circuit,
do not plug the heater into a circuit that already has other appliances working.
10. CAUTION: It is normal for the plug to feel warm to the touch. However, a loose
fit between the AC outlet (receptacle) and plug may cause overheating and may
distort the plug. Contact a qualified electrician to replace loose or worn outlet.
11. To disconnect the heater, first turn controls to the OFF position, then grip the
plug and pull it from the wall outlet. Never pull by the cord.
12. Do not insert or allow foreign objects to enter any ventilation or exhaust opening
as this may cause an electric shock or fire, or damage the heater.
13. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surface, like a bed, where openings may become blocked.
14. A heater has hot and sparking parts inside. Do not use it in the areas where
gasoline, paint, or flammable liquids are stored or nearby.
15. Use this heater only as described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock, or injury to persons.
2

16. CAUTION: Avoid the use of an extension cord because the extension cord may
overheat and cause a risk of fire. However, if you have to use an extension cord,
the cord shall be No.14 AWG minimum size and rated not less than 1875 watts.
17. The output of this heater may vary and its temperature may become intense
enough to burn exposed skin. Use of this heater is not recommended for persons
with reduced sensitivity to heat or an inability to react to avoid burns.
SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY
REFERENCE.
ELECTRICALRATINGS
This product is rated 12.5 amps (1500W) at 120V, 60 Hz.
FEATURES
A:TemperaturePilotLamp
B:ClockPilotLamp
C:Clock1
D:Clock2
E:DigitalIndicator
E
D
CB
A
:istheMode button .
:istheOSCILLATION button.
:isthePOWER button.
OPERATION
Turning the Unit On
zPlace the heater on a firm level surface free from obstructions, and at least 3
ft. away from any wall and any other objects such as furniture, curtains,
3

plants or combustible material.
zPlug the heater into a grounded 120V outlet. The buzzer sounds, the thermal
pilot lamp lights and the “E” Digital Screen indicates room temperature.
zPress the POWER button repeatedly to the desired setting. The cycle is as
follows:
Hi – The heater operates at a higher wattage.
Lo – The heater operates at a lower wattage.
Auto – The heater will function with the motion sensor, and will
automatically stop heating within 10 minutes if there is no motion. When
motion is detected, the heater will automatically begin heating again.
Fan – Only the fan will operate blowing cool air to circulate.
Note: The fan speed will remain the same for the Hi and Lo settings.
zMODE Key: It is used to set temperature, clock and timer
Turning the Unit Off
•Press the POWER button to cycle through the functions until none of
them are lit (HI, LO, AUTO, FAN).
When then unit is turned off the fan will continue to run for 30 seconds
to cool down.
Setting the Clock
To set or adjust the time while the unit is either ON or OFF.
zPress the MODE until you see the time with the flashing.
zUse the ▲and ▼arrows to set the desired hours.
zTo change the minutes press MODE button and press the ▲and▼arrows
to the desired minutes.
zPress MODE to finish the setting.
Note: A Lit Clock shows the current time.
Setting the Thermostat
In order to set the thermostat the unit has to be on Hi, Lo, or Auto
zWhile the unit is on, Toggle through the MODE until you see the
temperature with the flashing.
zUse the ▲and▼arrows to the temperature desired. (40F – 95F).
Press MODE to finalize.
Note: To change the temperature to Celsius press the ▲and ▼arrow
simultaneously while the temperature display is showing.
4

The thermostat is in effect in modes: Hi,Lo, and Auto and will heat to the
desired temperature setting.
A Lit Thermometer shows the current temperature.
Note: Press both ▲and ▼synchronously can shift the temperature ”C”
and “F”.
Programming the Unit for Automatic Run Time (Setting the Timer)
In order to program the unit, the unit has to be on Hi, Lo, Auto, or Fan.
Programming the unit will tell the heater when to turn On and Off at specific
times that the user has set the time to. The heater is able to set up to 2 different
time periods.
Setting the Unit to turn on (Program 1)
zWhile the unit is On, press the MODE button until you see the and the
word ON flashing
zUse the ▲and ▼arrows to set the hours.
zPress MODE button to set the minutes; use the ▲and ▼arrows.
zPress MODE to finalize.
Setting the Unit to turn off (Program 1)
zAfter setting the unit to turn on, the and the word OFF will be flashing.
zUse the ▲and ▼arrows to set the hours.
zPress MODE once more to set the minutes using the ▲and ▼arrows.
zPress MODE to finish setting Program 1
Setting the Unit to turn on (Program 2)
zWhile the unit is On, press the MODE button until you see and the
word ON flashing
zUse the ▲and ▼arrows to set the hours.
zPress MODE button to set the minutes, use the ▲and ▼arrows.
Press MODE to finalize.
Setting the Unit to turn off (Program 2)
zAfter setting the unit to turn on and the word OFF will be flashing.
zUse the ▲and ▼arrows to set the hours.
zPress MODE once more to set the minutes using the ▲and ▼arrows.
zPress MODE to finish setting Program 2.
Note: Per program, the On time & the Off time must be set in order for the
5

program to be effective.
A Lit - shows that the program has been set.
A Red - means that the program is in effect.
To check a program that’s been set, repeat the steps above to show the Flashing
- and it will show you the time that has been programmed.
To cancel a program, cycle through the functions by pressing the POWER to
turn off, turn on again if needed.
POWER/MODE Function Map
function will cycle through the list accordingly.
F
Power Off Fan
HI
LO
AUTO
Mode
Mode
Time Set
Time Set
Temp Setting
Time On(1)
Time On(1)
Time Off(1)
Time Off(1)
Time On(2)
Time On(2)
Time Off(2)
Time Off(2)
By Pressing POWER/MODE the
unction of Oscillation.
When the machine is on and under operation, the oscillating motor runs by pressing
OSCILLATION key.
RESET INSTRUCTIONS
zThis heater is equipped with an overheating cut-off switch which will shut the unit
Sg, please follow these steps before
0 MINUTES
off if the internal heating components overheat.
hould the heater shutdown due to overheatin
reusing heater:
1) TURN MODE TO OFF
2) UNPLUG UNIT WAIT 1
3) PLUG IN AND TURN ON
6

ADDITIONAL FEATURES
•Convenient Carry Handle
TROUBLESHOOTING
s working
•any obstruction. If you find any obstruction, turn the heater
If your heater fails to operate, please follow these instructions:
•Ensure that your circuit breaker or fuse is working properly.
•Be sure the heater is plugged in and that the electrical outlet i
properly.
Check for
“OFF”. Unplug the heater and wait a few minutes for it to cool down.
Carefully remove the obstruction. Plug the heater in and turn it on again by
referring to the OPERATING INSTRUCTIONS.
ol down.
and store it in a cool and dry place.
CLEANINGANDSTORAGE
It is recommended that the heater be cleaned at least one time during the operating
season in order to provide the optimum level of performance. ALWAYS BE SURE
THAT THE HEATER IS OFF AND UNPLUG THE HEATER BEFORE
CLEANING. Be sure to save the box for off-season storage.
•Before cleaning, unplug the heater and wait for it to co
•Use a dry cloth to clean only external surfaces of the heater.
•Do not use any cleaning agents or detergents.
•Never immerse the heater in water.
•Pack the heater in the original carton
SPECIFICATIONS
Model No.: 33553 (NFE20C)
Voltage: 120V, 60Hz
Current: Maximum continuous draw: 12.5 Amps.
, HI= 1500 Watts
Output: 5200 BTUs
Power: LO =900 Watts
7
