Lorell NTS 33554 User manual

Ceramic Tower Heater with Motion Sensor
& Remote Control
33554
Part# NTS
INSTRUCTION MANUAL
Please Read And Save These Instructions
1

2
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions carefully and keep for future reference.
When using electrical appliances, basic precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons, including the following:
1. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surface. If provided, use handles when moving this heater. Keep combustible
materials such as furniture, pillows, bedding, papers, clothes and curtains at least
3 feet (0.9m) from the front of the heater. Also, keep these materials away from
the sides and rear of the heater.
2. Extreme caution is necessary when any heater is used by or near children or
invalids, and whenever the heater is left operating unattended.
3. Always unplug the heater when not in use.
4. Do not operate the heater if the cord or plug is damaged or if the heater
malfunctions, or has been dropped or damaged in any manner. Return heater to
an authorized service facility for examination, electrical or mechanical
adjustment, and repair.
5. Do not use outdoors.
6. This heater is not intended for use in bathroom, laundry areas and similar moist
indoor locations. Never locate heater where it may fall into a bathtub or water
container.
7. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or
anything similar. Arrange cord away from traffic areas where it will not be
tripped over.
8. CAUTION: This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of shock, this plug is intended to fit only one way in a
polarized outlet. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. DO NOT attempt to defeat this
safety feature. To do so could result in an electric shock hazard.
9. This heater draws 12.5 amps during operation. To prevent overloading a circuit,
do not plug the heater into a circuit that already has other appliances working.
10. CAUTION: It is normal for the plug to feel warm to the touch. However, a loose
fit between theAC outlet (receptacle) and the plug may cause overheating, and
may distort the plug. Contact a qualified electrician to replace loose or worn
outlet.
11. To disconnect the heater, first turn controls to the OFF position, then grip the
plug and pull it from the wall outlet. Never pull by the cord.
12. Do not insert or allow foreign objects to enter any ventilation or exhaust opening
as this may cause an electric shock or fire, or damage the heater.
13. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surface, like a bed, where openings may become blocked.
14. A heater has hot and sparking parts inside. Do not use it in areas where gasoline,
paint, or flammable liquids are stored or nearby.

15. Use this heater only as described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock, or injury to persons.
16. CAUTION:Avoid the use of an extension cord because the extension cord may
overheat and cause a fire. However, if you have to use an extension cord, it
should be a minimum size of No.14AWG, and rated not less than 1875 watts.
17. The output of this heater may vary and its temperature may become intense
enough to burn exposed skin. Use of this heater is not recommended for persons
with reduced sensitivity to heat or an inability to react to avoid burns.
SAVE THESE IMPORTANTINSTRUCTIONS FOR EASYREFERENCE.
UNPACKINGAND SET-UP ASSEMBLY
Unpack your heater and remove the two half bases from the package.
1. Make sure the heater is unplugged
2. TURN THE HEATER UPSIDE DOWN. Unfasten the four screws.
3. Position the two holes assemblies of the two half bases and fix them as shown.
4. Insert the butterfly screws and screw them tightly.
5. Turn the heater upright.
ELECTRICALRATINGS
3

This product is rated 12.5 amps (1500W) at 120V, 60 Hz.
FEATURES
A:TemperaturePilotLamp
B:ClockPilotLamp
C:Clock1
D:Clock2
E:DigitalIndicator
E
D
CB
A
Tip-Over Switch - Shuts heater off automatically if unit tips over, Heater will resume once
heater is properly oriented. OPERATION
Turning the Unit On
zPlace the heater on a firm level surface free from obstructions, and at least 3
ft. away from any wall and any other objects such as furniture, curtains,
plants or combustible material.
zPlug the heater into a grounded 120V outlet. A buzzer will sound. The
thermal pilot lamp lights up and the “E” Digital Screen indicates room
temperature.
zPress the POWER button repeatedly to the desired setting. The cycle is as
follows:
Hi – Heater operates at a higher wattage.
Lo – Heater operates at a lower wattage.
Auto – Heater will function with the motion sensor, and will automatically
stop heating within 10 minutes if there is no motion. When motion is detected,
the heater will automatically begin heating again.
Fan – Only the fan will operate, circulating cool air.
Note: The fan speed will remain the same for the Hi and Lo settings.
zMODE Key: It is used to set temperature, clock and timer.
Turning the Unit Off
4

•Press the POWER button to cycle through the functions until none of
them are on (HI, LOW, AUTO, FAN).
When then unit is turned off the fan will continue to run for 30 seconds
to cool down.
Setting the Clock
To set or adjust the time while the unit is either ON or OFF.
zPress the MODE until you see the time with flashing.
zUse the ▲and ▼arrows to set the desired hours.
zTo change the minutes press MODE button and press the▲and▼arrows
to the desired minutes.
zPress MODE to finish the setting.
Note: A lit Clock shows the current time.
Setting the Thermostat
In order to set the thermostat the unit has to be on Hi, Lo, or Auto
zWhile the unit is on, toggle through the MODE until you see the
temperature with flashing.
zUse the ▲and▼arrows to adjust to the desired temperature (40F – 95F).
Press MODE to finalize.
Note: To change the temperature to Celsius press the ▲and ▼arrow
simultaneously while the temperature display is showing.
The thermostat is in effect in modes: Hi,Lo, and Auto and will heat to the
desired temperature setting.
A lit Thermometer shows the current temperature.
Note: Press both ▲and ▼synchronously can shift the temperature ”C”
and “F”.
Programming the Unit for Automatic Run Time (Setting the
Timer)
In order to program the unit, it has to be on Hi,
Lo, Auto, or Fan
Programming the unit will tell the heater when to
turn On and Off at specific times set on the timer.
The heater is able to set up to 2 different time
periods.
Setting the Unit to turn on (Program 1)
5

While the unit is On, press the MODEbutton until you see
and the word ON flashing
6
Use the▲and ▼arrows to set the hours.
Press MODEbutton to set the minutes, use the ▲and ▼
arrows.
PressMODEto finalize.
Setting the Unit to turn off (Program 1)
After setting the unit to turnon, the andthe word OFF will be flashing.
Use the ▲and ▼arrows to set the hours.
Press MODE once more to set the minutes using the ▲and ▼arrows.
Press MODEto finish setting Program1
Setting the Unit to turn on (Program 2)
While the unit is On, press the MODEbutton until you see and the
word ON flashing.
Use the▲and ▼arrows to set the hours.
Press MODEbutton to set the minutes, use the ▲and ▼arrows.
Press MODEto finalize.
Setting the Unit to turnoff (Program 2)
After setting the unit to turnon, and the word OFF will be flashing.
Use the ▲and ▼arrows to set the hours.
Press MODEonce more to set the minutes using the ▲and ▼arrows.
Press MODEto finish setting Program2.
Note: Per program, the On time & the Off time must be set in order for the
programto beeffective.
ALit - shows that the program has been set.
ARed-means that the program is in effect.
To check a programthat’s been set,repeat thesteps above to show the flashing
- and it willshow you the time thathas been programmed.
To cancel a program, cycle through the functions by pressing POWERto
turn off. Turn on again if needed.

7
POWER/MODE Function Map
le through the function list accordingly.
F
Power Off Fan
HIGH
LOW
AUTO
Mode
Mode
Time Set
Time Set
Temp Setting
Time On(1)
Time On(1)
Time Off(1)
Time Off(1)
Time On(2)
Time On(2)
Time Off(2)
Time Off(2)
Press the POWER/MODE to cyc
unction Of Oscillation
When the heater is on and under operation, press the OSC key
t
e control with the
ey is used to turn the
2.
3.
4. to adjust the set value of
5. use to adjust the set value
o run the oscillating motor.
Use Of The Remote Control:
There are 5 keys on the remot
following functions:
1. ON/OFF: The on/off k
heater ON (will turn on at HI) or OFF.
POWER: While the heater is ON, press the
POWER key to select desired power settings.
OSC: For use to start oscillating function.
Pressing once turns on the function, and
pressing once again to disable it. (Note:
This function can only be used when the
heater is on.)
UP ” + ” : For use
temperature
DOWN ” - “ : For
of temperature, to decrease temperature.

8
Press the UP or DOWN key once to start the temperature value
adjustment. The set temperature light will be flashing. Then,
press the UP or DOWN key again to adjust to the desired
temperature setting.
RESET INSTRUCTIONS
zThis heater is equippe hich will shut the unit
S g, please follow these steps before
0 MINUTES
d with an overheating cut-off switch w
off if the internal heating components overheat.
hould the heater shutdown due to overheatin
reusing heater:
1)TURN MODE TO OFF
2)UNPLUG UNIT WAIT 1
3)PLUG IN AND TURN ON
ADDITIONAL FEATURES
•Washable D
e
ust Filter
•Convenient Carry Handl
TROUBLESHOOTING
If your heater fails to operate, please follow these
your circuit breaker or fuse is working
heater is plugged in and that the electrical
•y obstruction, turn the heater n. y
instructions:
•Ensure that
properly.
•Be sure the
outlet is working properly.
Check for any obstruction. If you find an
“OFF”. Unplug the heater and wait a few minutes for it to cool dow
Carefully remove the obstruction. Plug the heater in and turn it on again b
referring to the OPERATING INSTRUCTIONS.
CLEANINGAND STORAGE
It is recommended that the heater be cleaned at least one time
“OFF”. Unplug the heater, and wait for
clean external surfaces only.
during the operating season in order to provide the optimum
performance. ALWAYS TURN THE POWER SWITCH OFFAND UNPLUG
THE HEATER BEFORE CLEANING. Be sure to save the box for
off-season storage.
•Turn the heater
it to cool down.
•Use a dry cloth to
•Do not use any cleaning agents or detergents.

9
n and store it in a
•Never immerse the heater in water.
•Pack the heater in the original carto
cool and dry place.
SPECIFICATIONS
Model No.: 33554 (NTS)
ntinuous draw: 12.5 Amps.
atts, HIGH = 1500 Watts 5%
Voltage: 120V, 60Hz
Current: Maximum co
Output: 5200 BTUs
Power: LOW = 900 W
Tolerances on all specifications: Not exceeded 10
