Lorex LW1741 User manual

USER’S GUIDE
LW1740 / LW2740
SERIES
English / Français / Español

Thank you for purchasing this product. Lorex is committed to providing our
customers with a high quality, reliable security solution.
This manual refers to the following models:
• LW1741
• LW1742
• LW1744
• LW2742
For the latest online manual, downloads and product updates, and to learn
about our complete line of accessory products, please visit our website at:
www.lorextechnology.com
WARNING
• Risk of electric shock. Do not open.
• To reduce the risk of electric shock, do not remove cover. No user serviceable parts
inside. Refer servicing to qualified service personnel.
• To prevent fire or shock hazard, do not expose this unit to rain or moisture.
• To prevent electric shock, match wide blade of the plug to the wide slot and fully insert.
CAUTION
• Test the video monitor before use. Become familiar with its functions.
• If you do not plan to use the unit for a prolonged period of time, disconnect the battery
or ensure you charge it at least once every 3 months.
• Never use extension cords with power adapters.
• Only use the chargers and power adapters provided. Do not use other chargers or
power adapters as this may damage the device and battery pack.
• Only insert batteries / battery pack of the same type.
• Do not cover the video monitor with a towel or blanket.
• Do not use this product in humid or wet places.
• Do not install the video monitor near a heat source.
• Do not touch the plug contacts with sharp or metal objects.
• It is highly recommended to connect the product to a surge protector to protect from
damage caused by electrical surges. It is also recommended to connect the product to
an uninterruptible power supply (UPS), which has an internal battery that will keep the
product running in the event of a power outage.
• Keep this user’s guide for future reference.
#LX400030; r. 1.0/17112/17628; en-US iv

Table of contents
1 LW1740 / LW2740 Series Features.........................................1
2 Getting Started ...................................................................3
3 Installing the Camera(s).......................................................4
3.1 Installation Tips ..........................................................4
3.2 Mounting Positions......................................................4
4 Installing the Receiver .........................................................7
4.1 Setting the Time .........................................................9
5 Camera Overview.............................................................. 10
6 LCD Receiver Overview...................................................... 11
6.1 Front Panel.............................................................. 11
6.2 Side Panel .............................................................. 12
6.3 Rear Panel .............................................................. 13
7 Using the System .............................................................. 14
7.1 Understanding the On-screen Display ........................... 14
7.2 Navigating Menu Screen ............................................ 16
7.3 Viewing Modes ........................................................ 16
7.3.1 Auto Sequence Viewing Mode .......................... 16
7.3.2 Quad Mode .................................................. 17
7.4 Digital Zoom............................................................ 18
7.5 Changing Audio Volume............................................. 18
8 Recording ........................................................................20
8.1 Format Memory........................................................ 20
8.2 Recording Mode Summary ......................................... 21
8.3 Scheduled Recording ................................................ 22
8.3.1 Creating a Recording Schedule......................... 23
8.3.2 Pausing Scheduled Recording .......................... 24
8.3.3 Modifying / Disabling a Recording
Schedule......................................................24
8.3.4 Deleting a Recording Schedule ......................... 25
8.4 Manual Recording .................................................... 26
8.5 Taking a Snapshot .................................................... 26
8.6 Enabling / Disabling File Overwrite ............................... 27
8.7 Configure Recording Time for Motion Events .................. 28
8.8 Motion Detection Sensitivity ........................................ 29
8.9 Motion Detection Area ............................................... 30
8.10 Enabling / Disabling Alarm for Motion Events .................. 32
#LX400030; r. 1.0/17112/17628; en-US v

Table of contents
8.11 Maximum Recording Times ........................................ 34
9 Playback ..........................................................................35
9.1 Video Playback ........................................................ 35
9.1.1 Playback Controls .......................................... 36
9.2 Viewing Snapshots ................................................... 37
9.3 Deleting Files........................................................... 38
9.4 Viewing Video Directly from the microSD Card................ 39
9.4.1 Player Overview............................................. 41
10 Settings ...........................................................................43
10.1 Camera Brightness ................................................... 43
10.2 Enabling / Disabling Date & Time Stamps ...................... 44
10.3 Changing Date & Time Format..................................... 45
10.4 Power Saving Mode .................................................. 46
10.5 Activating / De-activating Channels............................... 47
10.6 Changing Scan Interval for Auto Sequence
Viewing...................................................................49
10.7 Update Firmware...................................................... 50
10.8 Restore Default Settings ............................................ 51
11 Pairing Additional Cameras ................................................ 53
12 Technical Specifications .................................................... 56
12.1 General Specifications............................................... 56
12.2 Camera Specifications............................................... 56
12.3 Receiver Specifications.............................................. 57
12.4 Dimensions ............................................................. 58
12.4.1 LCD Receiver................................................ 58
12.4.2 Camera with Metal Stand................................. 58
13 Troubleshooting................................................................ 59
14 Notices ............................................................................61
14.1 FCC Notice ............................................................. 61
14.2 Industry Canada Notice ............................................. 62
14.3 Modification............................................................. 62
14.4 RoHS..................................................................... 62
#LX400030; r. 1.0/17112/17628; en-US vi

LW1740 / LW2740 Series
Features
1
• 7” rechargeable wireless LCD monitor.
1
• Weather resistant wireless camera.2
• Manual, motion, and schedule recording.
• Listen-in audio monitoring.3
• Expandable up to 4 cameras.
• microSD memory card included; 32GB supported.
• Easy to use menu with icons.
• Simple installation. No video cables required.
• Video motion detection.
• Time and date stamped recordings for easy retrieval.
• Front panel feather touch controls.
• Motorized camera filter provides accurate color reproduction in all lighting
conditions.
• Night time viewing up to 65ft (20m) away in ambient night time lighting con-
ditions and up to 45ft (14m) away in total darkness.4
• View and record up to 4 cameras at the same time in quad screen.
• Secure wireless signal (FHSS).
• Up to 150ft (50m) indoor / 450ft (150m) outdoor wireless range.5
• Record in real time video.
• 2x Digital Zoom.
#LX400030; r. 1.0/17112/17628; en-US 1

LW1740 / LW2740 Series Features
1
Note
1. Up to 5 hours of portable wireless monitoring. For extended monitoring ensure the
wireless monitor is connected to a local power outlet.
2. Wireless cameras require a wired connection to power outlet. Not intended for direct
exposure to rain or snow. For outdoor applications, install under shelter protected
from the elements.
3. Audio recording without consent is illegal in certain jurisdictions. Lorex Corporation
assumes no liability for use of its products that does not conform with local laws.
4. Stated IR illumination ranges are based on ideal conditions in total darkness and typi-
cal outdoor night time ambient lighting. Actual range and image clarity depends on in-
stallation location, viewing area and light reflection / absorption.
5. Range up to 450ft (150m) outdoor and 150ft (50m) indoor based on line of sight. Ac-
tual range will vary depending on obstructions.
#LX400030; r. 1.0/17112/17628; en-US 2

Getting Started
2
The system includes the following components:
Indoor / outdoor
wireless camera(s)*
7” rechargeable
LCD receiver
Power adapters for
receiver and cam-
era(s)*
Rechargeable Lith-
ium polymer battery
Wireless antenna
(s)
for camera(s)
(SMA)*
microSD memory
card
(pre-inserted into
receiver)
Mounting kit(s)* Quick Start Guide
* Configuration may vary by model
Note
Camera configuration, memory card size, and the number of accessories may vary by
model. Please refer to your package for specific details. Check your package to confirm
that you have received the complete system.
#LX400030; r. 1.0/17112/17628; en-US 3

Installing the Camera(s)
3
CAUTION
Cameras are suitable for outdoor installa-
tion, but are weather resistant, not weath-
erproof. Cameras are not intended for
direct exposure to rain or snow. For
outdoor applications, install under shelter
protected from the elements, such as be-
neath roof eaves. The diagram to the right
shows an example of an ideal location for
outdoor placement.
3.1 Installation Tips
• Before you install the camera, plan where and how it will be positioned,
and where you will route the cable that connects the camera to the power
adapter.
• Before starting permanent installation, check the camera image on the re-
ceiver when camera is positioned in the same place it will be permanently
installed.
• It is recommended to ensure a clear line-of-sight between the camera and
receiver and to limit the amount of obstructions, such as walls and tree
branches, between the camera and receiver. Walls made of heavy building
materials such as brick or concrete will significantly reduce signal range.
• If the signal will have to pass through a wall, placing the receiver or camera
next to a window will improve the signal strength.
• Do not install the camera pointing out of a window. The nighttime picture
will be unusable due to reflection from the night vision LED’s.
• The cameras are pre-paired so they work out of the box. Each camera has
a channel number sticker indicating what channel they are paired to. If you
have purchased additional cameras, you will need to pair them to the re-
ceiver, see 11 Pairing Additional Cameras, page 53.
3.2 Mounting Positions
You may mount your cameras on a wall or counter. See the images below for
recommended configurations of the camera stand and antenna.
#LX400030; r. 1.0/17112/17628; en-US 4

Installing the Camera(s)
3
Wall Counter
To install the camera(s):
1. Use the included mounting screws to attach the camera stand(s) to the
mounting surface:
• Mark the positions of the screw holes on the mounting surface with the
base of the mounting stand.
• Drill holes and insert the drywall plugs (included) if installing on a dry-
wall surface.
• Firmly attach the camera(s) to the mounting surface using the included
screws.
Note
If you run the power cable through the mounting surface, connect power before at-
taching the camera to the wall.
2. Attach the camera stand(s) and antenna(s) to the camera(s).
#LX400030; r. 1.0/17112/17628; en-US 5

Installing the Camera(s)
3
3. Loosen the adjustment ring on the metal camera stand(s) and move the
camera to the desired position. Tighten the adjustment ring when finished,
holding the camera firmly in position.
4. Connect one end of the camera’s power adapter to the camera and the
other end to an electrical outlet or surge protector. Make sure the power
connector is fully inserted to avoid water getting in the plug.
Note
Power cables are only weather resistant when fully inserted at the connection point.
Power cables may not be submerged in water.
5. Remove the protective film from the front of the camera. If the film is not
removed, it will affect the quality of the picture.
#LX400030; r. 1.0/17112/17628; en-US 6
