Lovencare BP 9771 User manual

•Do not carry extra children or bags on this stroller.
•Never leave your child unattended in the stroller.
•The stroller should not be used on stairs or escalators.
•Follow the manufacturers’ instructions.
•To avoid serious injury always use the harness provided to secure the child.
•Put on all the brakes whenever you park the stroller.
•Care should be taken whilst folding and unfolding stroller to prevent fingers being
trapped.
•Ensure your child’s fingers, hands and all other body parts are clear from any moving
part when adjusting the seat or handle on your stroller.
•Basket maximum weight should not exceed 7kg.
•Do not leave children unattended.
•Make sure children are clear of any moving parts if you adjust the stroller, otherwise
they may be injured.
•This stroller should not be used near an open fire or an exposed flame.
•Do not use accessories other than those supplied or approved by Love N Care
THE MAXIMUM WEIGHT FOR THE STROLLER IS 40KG.
THE MAXIMUM WEIGHT FOR THE TODDLER SEAT IN REAR POSITION IS 15KG.
THE MAXIMUM WEIGHT IN MAIN SEAT OF THE STROLLER IS 25KG
It is recommended to regularly inspect and main
movement of locking devices; and security of essential components.
To maintain the stroller follow the steps mentioned below:
•If wheels become stiff, spray with dry silicon lubricant
•The frame can be washed with soap and warm water, do not use bleach.
•The seat can be wiped down with a clean cloth using soapy warm water.
•The padded stroller liner should be hand washed and hung to dry but not directly
under sunlight.
INFLATE TYRES TO MAX 28PSI using a hand pump
All love n Care products have one year warranty from the date of purchase.
Safety guidelines and instructions must always be followed before making use of this product,
please retain these instructions for future reference.
This product complies with product standard AS/NZS 2088:2000 & EN 1888
CARE AND MAINTENANCE
MANUFACTURED FOR AND IMPORTED BY:
LOVE N CARE PTY LTD, 297-299 CANTERBURY RD
REVESBY NSW 2212

Assembly Instructions
Step 1: Open the Frame
Take the stroller out of the box and
remove all the items. Unclip the safety
locking clip on the side of the chassis
(point 1) Place the frame on the floor,
and pull the handle upwards (point 2)
the frame should spring open and lock
into place.
Step 2: Attach front wheels
Attach the front wheels as shown.
ENSURE the swivel lock is on the
Outside.
Step 3: Insert Mudguard
Place the mudguard into the rear
housing for the wheel and move it
intothe available channels.
PULL on the mudguard to ensure
thatit is fully attached
Step 4: Attach rear wheels
Attach the rear wheel as shown.
ENSURE that the wheel is locked
in before placing the child on the
Stroller.

Step 5: Attaching the hood
Clip the hood on the side of the
frame as shown (point 1)
Ensure that it is locked into
place
Step 6: Attaching the rear toddler seat (optional)
Take the toddler seat and place
the open end into the 1st holder
(point 1) then you should push the toddler
seat down so the rear wrench
snaps into the second holder
(point 2). ENSURE this is done on
both sides and make sure it is
secure before placing a toddler
on it.
Step 7: To attach the front Bar
To attach the front bar make sure
the toddler seat is not attached.
Place the lower hook into the
holder first (point1) and then press
the upper hook to snap it into the
frame (point 2). Pull it a little to
ensure it is in place.
To remove pull down the latch and
push the bar down then lift out of
the holder

Step 8: Using the front wheels in swivel Mode.
To Unlock the front wheels
and use them in swivel
mode push the button up
as illustrated in g 8.
To lock the wheels so it can
only go in one direction
Push the button on the
front of the frame down as
shown in g 9.
Step 9: Using the Rear Parking Brakes
To use the parking brakes step down
on the rear paddle to stop the stroller
moving whilst in a stationary position.
Check that the brakes have been applied
correctly by gently pushing the stroller.
To release the brakes justpush the
paddle up.
PUT ON ALL THE BRAKES WHENEVER YOU PARK THE STROLLER
Step 10: Remove the front wheels
To remove the front wheels push the
trigger (point 1).
The wheel should then be released.

Step 11: To remove the rear wheels.
Pull the release trigger as shown
in Point 1.
The wheel will then be released.
Step 12: Adjusting the Backrest Position
To have the stroller in the fully reclined
pull down on the release strap as
shown at point 1. To adjust the seating
position pull up on the strap shown.
With the excess strap place in the rear
pocket. (to avoid and tangles)
If toddler seat is used in the rear it is
advisable to have themain seat in an
upright postion.
If Toddler seat is used in the front it is
advisable to have the main seat in the recline position
Step 13: Adjusting the handle
To adjust the postion of the handle you
must press the button (point 1) on both
sides of the stroller and either push up or
down on the handle depending on the
desired position required.
Step 14: Attaching the Tether Strap.
Please ensure you attach the tether strap
to the handle of the stroller by using a loop
to better control the stoller and so it
does not get out of reach.

Step 15. Using the hood.
The hood can be made higher or lower depending on your suitability.
Simply unclip the hood bracket from its position and replace in either
the upper or lower position as required (Fig 17)
Step 16: How to use the 5 Point Harness
Carefully place the child in the seat and bring
the safety harness around the childs waist
and over the shoulders. Place the crotch strap
between the childs legs. Insert the male end
of each shoulder strap /waist belt into the
buckle on the crotch strap. Tighten the harness
to be snug around the childs waist and over
the childs shoulders. To release squeeze the
sides of the buckles (located in the centre)
Your child should be securely harnessed at all
times and should never be left unattended.

Step 16: Releasing Parts (A visual View)
Step 17: Releasing rear toddler Seat
To remove the rear toddler seat pull down on the lever switch as
shown on point 6 (on both sides) pull the toddler seat up as shown
in point 6 then lift as shown in point 8.

Step 18: Attaching/removing the front toddler seat
Take the toddler seat and place the open end into the 1st holder
(point 9) then you should push the toddler seat down so the rear
wrench snaps into the second holder (pont 10). ENSURE this is
done on both sides and make sure it is secure before placing a
toddler on it. Then you should attach the hood (Repeat step 5).
To remove the seat push the side levers down and pull the seat
towards you. You can also release one side lever then pull the seat
forward then release the otherside. The toddler seat should then be
removed. Both methods work.

Step 19: Folding the stroller
Remove all toddler seats if attached.
In order to close the stroller close the hood as shown at point 1, pull
the trigger up as shown at point 2 then pull the button point 3 on both
sides of the frame at the same time, then push the handle down as
shown at point 4. This will fold the stroller compactly. To lock the frame
securely use the locking clip shown on point 6.

Contact Us:
Love N Care Pty Ltd.
297-299 Canterbury Rd, Revesby
NSW 2212 Australia
Contact No: 02 9774 4655
Fax: [phone]
Email: [email protected]
Website: www.lovencare.com.au
