LOX CL0002 User manual

INSTRUCTIONS FOR LOCK MODE CHANGE:
1AUGUST 2021
CL0002 CABINET LOCK
INSTALLATION MANUAL
1. Remove the 2 screws on the bottom.
2. Remove the base plate and solenoid.
3. Turn the assembly 180° and install into housing.
WARNING: CARE SHOULD BE TAKEN TO PREVENT DAMAGE TO SWITCH LEVER
4. Insert the two screws.
DOOR MONITOR SWITCH
LOCKING PIN
MONITOR SWITCH
CONNECT TO
APPROPRIATE
DC VOLTAGE
(SEE WIRING DIAGRAM)
FAIL SECURE FAIL SAFE
N/C
N/O
C
N/C
N/O
C
12VDC (200mA)125VAC; 1A / 30VDC; 0.5A
125VAC; 3A / 30VDC; 2A 24VDC (100mA)
1. LOCKING PIN MONITOR SWITCH WIRING DIAGRAM
3. DOOR MONITOR SWITCH WIRING DIAGRAM
2. CABINET LOCK DUAL VOLTAGE WIRING DIAGRAM
4. CABINET LOCK DUAL VOLTAGE WIRING DIAGRAM
RED 12VDC
24VDC
GND
GND
RED
BLUE
BLUE
BLUE
ORANGE
YELLOW
YELLOW
GREEN
GREEN
BLACK
BLACK
BLACK YELLOW
YELLOW LINK
BLACK
BLACK
N/C N/C
N/O N/O
C C
N/C
N/O
C

2AUGUST 2021
CL0002 CABINET LOCK
INSTALLATION MANUAL
PARTS CHECK LIST
QTY DESCRIPTION
4 FLAT HEAD WOOD SCREWS
2 PAN HEAD WOOD SCREWS
Dimensions (mm)
INSTALLATION DIMENSIONS
10
10
17.3 0
30
18
SWINGING CABINET DOOR
SLIDING CABINET DOOR
Dimensions (mm)
93
31
22
32 30
70
