ES20 / ES20M ELECTRIC DOOR STRIKE
INSTALLATION MANUAL
INTRODUCTION:
TECHNICAL DATA:
WIRING AND POWER INPUT REQUIREMENTS:
The patented ES20 series of strikes are manufactured from stainless steel and accept voltages from 12 to 36VDC. It has a 10mm lip, is pre-drilled for
extension lips and has a unique and simple fail secure (power to open)/ fail safe (power to lock) changeover function without the need to dismantle
the strike.
ES20 - Unmonitored Australian profile Electric Door Strike.
ES20M - Fully monitored Australian profile Electric Door Strike
with 3 forms of monitoring.
• Lock Status Sensor (LSS) - State of internal locking mechanism
• Door Latch Sensor (DSS) - Door latch engaged within strike keeper
• Anti – tamper Sensor (ATS) - Door strike removed or repositioned
THE WIRING DIAGRAM IS SHOWN FOR THE LOCK BEING LOCKED, AND DOOR CLOSED.
NO ADDITIONAL DIODE PROTECTION IS REQUIRED.
POWER DSS DOOR STATUS SWITCH LSS LOCK STATUS SWITCH ATS ANTI - TAMPER SENSOR
ES20 AUSTRALIAN PROFILE NON MONITORED DOOR STRIKE. MORTICE MOUNT, POWER TO LOCK/POWER TO OPEN FIELD INTERCHANGEABLE CAPACITY.
ES20M MONITORED VERSION OF THE ES20
HOLDING STRENGTH UP TO 1000KG, TESTED TO 1.5 MILLION CYCLES
VOLTAGE/CURRENT MULTI VOLTAGE 10—30VDC, 250MA AT 12VDC, 125MA AT 24VDC
APPROVALS CE & C-TICK, 4 HOUR FIRE RATED TO A.S. AND B.S. STANDARDS
LSS MONITORING STATUS SENSOR OF THE INTERNAL LOCKING MECHANISM
DSS MONITORING DOOR LATCH SENSOR, DOOR LATCH ENGAGED WITHIN STRIKE KEEPER
ATS MONITORING DOOR STRIKE REMOVED OR REPOSITIONED SENSOR
ENVIRONMENTAL OPERATIONAL TEMPERATURE RANGE - 20 DEG. C TO 60 DEG. C.
1OCTOBER 2020
1mm gap
Keeper
Door
Door latch Front face of
strike keeper
Door Frame
As drawn in the diagram above there should be a 1mm gap between the door latch
and the front-face of the strike keeper, preventing the door from creating back
pressure on the strike keeper when the door is closed.
RED + VE
- VEBLACK
10 - 30 VDC
ORANGE N/C YELLOW N/C WHITE N/C
GREY COM BLACK COM
GREEN N/O RED N/O
WHITE COM
BLUE N/O

OCTOBER 2020
2
ES20 / ES20M ELECTRIC DOOR STRIKE
INSTALLATION MANUAL
DIMENSIONS:
Depth of lip cutout
will vary due to width
of door frame and
mounting technique.
15mm, 25mm, 50mm, 75mm
extension lips are available options.
Remove rubber
plug prior to
assembly of
extension lips
(2 places).
ORDERING DETAILS AND ACCESSORIES:
PART NUMBER PRODUCT DESCRIPTION
ES20 NON MONITORED HIGH SECURITY ELECTRIC STRIKE
ES20M MONITORED HIGH SECURITY ELECTRIC STRIKE
ES20M-M ES20M WITH TWO FACEPLATE MAGNETS
ES20-EL15 ES20 EXTENSION LIP 15MM
ES20-EL25 ES20 EXTENSION LIP 25MM
ES20-EL50 ES20 EXTENSION LIP 50MM
ES20-EL75 ES20 EXTENSION LIP 75MM
ES20-REBATE REBATE KIT FOR ES20 SERIES
CHANGING LOCK FUNCTION FROM FAIL SECURE TO FAIL SAFE
Step 1: Disconnect power before performing any changeover.
Step 2: Remove the protective cover and loosen up the two locking screws 2 turns.
Step 3: 90° turn clockwise on the Cam axis. (Tip: Use a small slot screw driver to make the turn)
Step 4: Tighten up the locking screws and put back on the protective cover.
Step 5: The strike is now in the Fail Safe mode (PTL).
REVERSE ALL STEPS TO CHANGE FROM FAIL SAFE TO FAIL SECURE OPERATION
TURN MARK
POWER TO LOCK
POWER TO OPEN
