LOXONE Nano Motor Controller Air User manual

Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Need Help?
loxone.com/support
V160421
Part No: 100472
Nano Motor
Controller
Air
Connection cable (Output)
Power supply
Wire cross-section
0.75 ... 2.5mm² / AWG18 ... 13
Stripping length 5mm / 0.2”
Temperature resistance
-40 … 105°C / -40 … 221°F
Wire cross-section
1.5mm² / AWG 18
Stripping length 10mm / 0.4"
Temperature resistance
min. 80°C / 176°F for IEC,
min. 75°C / 167°F for UL
Cable length 150mm / 5.91”
Torque of terminal blocks 0.35 ... 0.4Nm / 0.26 ... 0.3 lbf ft
For additional information, declaration of confirmity,
visit loxone.com/help/nano-motor-controller-air
This folder is a part of the product!
Installation
The installation of this device has to be carried out by a
qualified person. The device has to be fitted in accordance with
building regulations for electrical and fire safety. If the device is
not installed according to manufacturers guidelines the
protection of the device may be affected.
Information
Contains FCC ID: 2ARRV-000375
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired operation

About the product
The Nano Motor Controller Air is a compact module with
DC outputs, which is controlled via the Loxone Air radio
technology.
Through the configurable outputs, motors or LED lights can
be connected in the following operating modes:
Motor Bidirectional: One output for DC motors including
control of running direction and speed.
Motor Unidirectional: Two outputs for DC motors with
speed control, no direction change possible.
Dimmer: One output for dimming low voltage LED lamps.
It can be used to control a variety of non-safety critical
functions in your smart home. We recommend it is
configured according to the Loxone Standard.
Features
In Motor-Mode:
•Current Flow Detection (100-3500mA)
•Overcurrent Detection (100-3500mA)
•Control the speed by PWM (0-100%)
LED-Mode:
•1 PWM output
AB
+VDC
Technical Specifications
Power supply 9 ... 26VDC
Power consumption typ. 0.22W, max. 0.28W
PWM Frequency 1 ... 10kHz
Power loss at max.
load
5.8W
Current detection
setting range
100 ... 3500mA
Overcurrent
detection setting
range
100 ... 3500mA
Interface Loxone Air:
868MHz (SRD Band Europe), 4 channels available
max. Power 15.1mW e.r.p.
915MHz (ISM Band Region 2), 10 channels available
max. Power 13.2mW, internal antenna
Safety rating IP20
Ambient temperature -20 … 50°C / -4 … 122°F
Humidity max. 95% r. H. (non condensing)
Dimensions 39.45x38.95x20.20mm / 1.55x1.53x0.80” (LxWxH)
Maintenance &
Cleaning
This device is free of maintenance and may only be
cleaned with a dry cloth.
GND
Motor Bidirectional
Motor Unidirectional
Maximum total load
of outputs
Configuration Motor Bidirectional
1 output
2.1A continuous;
3.5A peak (<30s)
Motor Unidirectional
2 outputs
max. 2.1A
Dimmer
1 output
Dimmer
400Hz
1.7W
-
-
