LP Morgan Screenboard User manual

LP Morgan
user manual
www.lpmorgan.com.au
Galleria Tuff
Screenboard

Notes and Cautions
TIP: A tip indicates important information that helps you make better use of your screen.
WARNING: A notice indicates potential damage to wall, ceiling or projector and tells you how to
avoid the problem.
DANGER: Indicates a potential for property damage, personal injury or death.
Information in this document is subject to change without notice.
© 2002-2006 Herma Technologies. All rights reserved.
Reproduction in any manner whatsoever without permission of Herma Technologies is strictly forbidden.
Trademarks used in this text: Herma, the Herma Logo, Galleria, LP Morgan and LP Morgan logo are
registered trademarks of Herma Technologies.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their product. Herma Technologies disclaims interest in trademarks and trade names
other than its own.
April 2007 Version 1.0
Table of contents
Important information
Unpacking 3
Installation
Assembly instructions 4
Appendix
Whiteboard Use 6
Warranty Information 7
To the owner
Congratulations on purchasing an Australian made LP Morgan Screenboard
Projection Screen.
Please take a moment to review this manual, as it will ensure you many years of
trouble-free service from your new LP Morgan Screenboard.

installation instructions | 3
Unpacking the Screenboard
1 x 4mm Allen Key 4 x Hanging Tabs
Required
Supplied
At least 3 x Screws to
suit Wall type.
Spirit Level
Electric drill Screw Driver
4 x M6 Cage Nuts with BH
bolts (nuts pre installed) 1 x Ezymount Rail
1 x Pre-Assembled Screenboard Frame with Acrylic Screen.

4| installation instructions
Important
information
Assembly Instructions
Ezy-mount Installation
23
Ensure height of mounting holes are 23mm below the height at which the top
edge of the frame will be. Using spirit level, secure ezy-mount to wall or mounting
surface.
Ezy-mount
Ezymount installation using spirit level.
Profile view detail
of ezy-mount
installation
3 x Screws to Suit
mounting surface type
(not supplied) Ezy-mount
Spirit Level
Mounting Surface
Ensure that the mounting surface
is reinforced and can support the
weight of the frame, e.g. use wall
studs. Do not simply mount onto
a plaster wall.
Placing the frame onto the ezy-mount rail
Tilt Screen at 15º
Hook the screen on to the top edge of the Ezy-Mount at a 15º angle from the
vertical. Carefully tilt frame towards wall and slowly release.
You can slide screen sideways until it lines up with the image horizontally.
Make sure the projector sits perpendicular to the screen.
Now sit back and enjoy the
big screen experience!
mounting detail
15º
see detail

installation instructions | 5
Mechanical
Installation
Assembly Instructions
Installing and using hanging tabs
Hanging tabs can be used to secure the Screenboard in a fixed position.
This can be done either in conjunction with the ezy-mount in place or with
the hanging tabs on their own.
We recommend that each hanging tab be placed at or near the corner of
the frame. This is to ensure maximum stability of the frame.
To mounting surface.
Hanging tab attachment to frame detail.
Note: Fastners from hanging tab to mounting
surface are not included.
If using hanging tabs in conjunction with ezy-
mount, be sure to use 6mm spacers between
the mounting surface and each hanging tab.
Once hanging
tab has been
secured,
it can be
moved along
the frame as
shown.
Secure hanging
tab to cage nut
as shown.

6| installation instructions
Appendix
Cleaning your screen surface
Screenboards are only suitable for use with dry erase or wipe dry markers
To clean the surface when using as a whiteboard there are several options-
• A clean dry cloth will remove the dry eraser mark
• Dampening your clean cloth will also remove the dry eraser mark
• For stubborn marks use methylated spirits and a clean dry cloth
Important note: Never use scourers or abrasives to clean your screen.
To avoid damage to your projection and whiteboard surface do not use
cleaning agents that -
• Are abrasive! You can damage the A/R coatings.
• Contain acetone or dichlormethan
Cleaning your frame
• If your frame is powder-coated or anodised, use water with a mild detergent
or methylated spirits and a soft cloth to wash off any marks. Rinse and dry
with a clean cloth or towel. Take care not to wet the screen surface.
• If your frame features a flocked velour finish, use a lint brush to remove any
dust on the frame.
Whiteboard Use and Screen Care

installation instructions | 7
Appendix
Warranty Information
IMPORTANT NOTE: You must keep your original receipt for warranty.
Customers must fill out the online warranty form, or the warranty card included with the
product and post it back to Herma at the reply paid address shown on the back cover in
order to qualify for the manufacturer’s warranty.
www.herma.com.au/warranty
The warranty covers defects in workmanship and materials, provided this product
has been installed in a normal environment and maintained according to the written
instructions. Herma warrants the product against loss of usefulness, discolouration or
deterioration of optical quality within the warranty period as a result of manufacturing or
material defects. This warranty applies only within Australia.
CONDITIONS –
Herma will repair or replace, with the least possible delay, any defective equipment. Any
equipment replaced pursuant to the terms of this warranty shall be retained by Herma
All costs related to installation and re-installation of the Herma Technologies equipment
covered by this warranty are not the responsibility of Herma Technologies. Herma will
not be responsible for any consequential damages during or following installation
procedures.
The user is responsible for any freight costs relating to repair or replacement. Equipment
must be returned to Herma in suitable packing to prevent damage in transit. Herma
will not accept any responsibility for damage to the equipment caused by inadequate
or unsuitable packing, or for any damage howsoever caused whilst the goods are in
transit.
Herma Technologies shall not be liable for any injury, loss or damage, direct or
consequential, arising out of the use of, misuse of, or inability to use, the equipment.
This Warranty does not cover any equipment which has been subjected to misuse,
abuse, neglect, accidental or intentional damage, improper voltage or any alteration
which affects the reliability or performance of the equipment not attributable to faulty
manufacture, parts or labour and without limiting the generality of the foregoing shall not
apply where the defect arose as the result of the following circumstances:
This Warranty does not cover any equipment where usage, adaptation or installation
(including wiring of electrical connections) are not in accordance with our written
installation and operating instructions.
Warranty Periods:
• Galleria Frame and Assembly Hardware: 2 years from date of purchase.
• Screen Surface: 1 year from date of purchase.

Your LP Morgan Retailer is able
to provide information on your
product. If we can be of any further
help, please contact us.
Factory 4a, 6 Albert Street Preston Vic 3072
Phone: [phone] Fax: [phone]
Email: [email protected] Web: www.herma.com.au | www.lpmorgan.com.au
